User Guide

SW800 with Bluetooth

Battery Powered PA System

Thank you for choosing the SW800 PA System from Am-

pliVox Portable Sound Systems.

We are excited in introducing this truly unique system. Our

system combines ﬂexibility with functionality. Please refer to

this user guide as you enjoy the unique capabilities of an-

other quality product from AmpliVox Portable Sound Sys-

tems.

We encourage you to visit our website www.ampli.com to

receive our newsletter, download our catalog, and learn

more about the complete line of audio visual AmpliVox

products, including portable PA systems, and lecterns.

AmpliVox • 650 Anthony Trail Suite D, Northbrook, IL 60062 Phone: (800)267-5486 • • Fax: (800)267-5489 www.ampli.com

READ FIRST ABOUT BATTERY OPERATIONS!

BY OBSERVING A FEW SIMPLE RULES, YOU CAN EXTEND THE

LIFESPAN OF THE SEALED LEAD ACID (SLA) BATTERIES THAT

OPERATE YOUR AMPLIVOX BATTERY POWERED PORTABLE

PA SYSTEM OR ACCESSORY:

•ALWAYS KEEP YOUR AMPLIVOX PORTABLE PA SYSTEM

PLUGGED IN AND CHARGING WHEN NOT IN USE.

•FOR LONG TERM STORAGE (OVER 1 MONTH) WE RECOM-

MEND DISCONNECTING THE SLA BATTERIES TO AVOID

GRADUAL, CONTINUOUS DISCHARGE.

•ALWAYS STORE SLA BATTERIES IN A CHARGED CONDITION

WHEN REMOVED FROM SERVICE.

•NEVER LET THE BATTERY VOLTAGE DROP BELOW 10V.

•FOR SLA BATTERIES IN STORAGE, APPLY A TOPPING

CHARGE EVERY SIX MONTHS.

•AVOID REPEATED DEEP DISCHARGES. THIS PRACTICE WILL

CUT THE LIFE OF THE BATTERY SIGNIFICANTLY.

•AVOID OPERATING SLA BATTERIES AT ELEVATED AMBIENT

TEMPERATURES.

•BATT STAT INDICATOR - RED = NO BATTERY POWER,

YELLOW = 1 HOUR LEFT. CHARGE BATTERY OVERNIGHT

FOR BEST RESULTS.

TABLE OF CONTENTS

GETTING STARTED/QUICK SETUP.................................... 3

CONTROLS / BACK PANEL .............................................. 4

AUDIO FUNCTIONS & ADJUSTMENT................................ 5

UHF WIRELESS BODYPACK .............................................. 5

WIRELESS HANDHELD MICROPHONE ............................. 6

BLUETOOTH MODULE ....................................................... 6

CD / MEDIA PLAYER ................................................... 7 ……

REMOTE CONTROL .............................. 8 ……………………

TROUBLESHOOTING ........................................................ 9

WARRANTY ......................................................... 10 …………

IMPORTANT SAFETY INSTRUCTIONS

Before using this product, read the instruction manual for important safety information. Please retain this manual for

future reference and warranty information.

Troubleshooting & Servicing

Do not attempt to service or repair the device yourself. Refer all servicing to qualiﬁed service personnel. Do not at-

tempt to modify the device in anyway. Doing so could invalidate your warranty.

Cleaning

When cleaning the device, please use a soft, dry cloth. Never use benzene, paint-thinner, or other chemicals on the

device.

Location

Place the device in stable location, so it will not fall causing damage to the device or bodily harm.

Intended use

The product may only be used with the original parts intended for it. The intended use includes adherence to the speci-

ﬁed installation instructions. The manufacturer accepts no liability for damage arising due to improper use.

WARNING: Changes or modiﬁcations to this unit not expressly approved by the party responsible for compliance

could void the user s authority to operate the equipment. ’

IMPORTANT

This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions:

(1) This device may not cause harmful interference, and (2) this device must accept any interference received, includ-

ing interference that may cause undesired operation.

The unit s circuitry may cause interference to nearby radios. To prevent interference, either switch the unit oﬀ or move ’

away from the aﬀected radio.

NOTE: This equipment complies within the limits for a class B digital device, pursuant to Part 15 of the FCC Rules.

These limits are designed to provide reasonable protection against harmful interference in a residential installation.

This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance

with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that

interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or tele-

vision reception, which can be determined by turning the equipment oﬀ and on, the user is encouraged to try to correct

the interference by one or more of the following measures:

· Increase the separation between the equipment and receiver.

· Connect the equipment into an outlet on a circuit diﬀerent from that to which the receiver is connected.

· Consult the dealer or an experienced radio / TV technician for help.

NOTE: Shielded cables may be required to be used with this unit to en-sure compliance with the Class B FCC limits.

1. Power unit on with rocker switch.

2. The WIRELESS RECEIVER has its own POWER / VOLUME

Control. Turn Receiver Power . A Frequency Channel will On

appear in the Channel Display. Press UP/DOWN Buttons to

select a channel. Channel number must match channel num-

ber on wireless transmitter.

3. Wireless Bodypack Transmitter- Before turning on the

transmitter, set the transmitter channel selector switch to the

same number that is displayed on the receiver. Select chan-

nels 1-16. Install 2 - AA“ ” batteries into battery compartment

of wireless transmitter pack.

4. MAIN BATTERY STATUS indicator - Red = no battery

power, If four GREEN LED’s are glowing, means fully

charged. Charge batteries overnight for best results.

If you need further assistance, please call

1-800-267-5486, 8am-6pm M-F CST .

Getting Started/Quick Setup

SW800 SPECIFICATIONS

Rated Power Output 100W RMS

Speaker 8" Full Range

Battery (2) 12 volt rechargeable SLA, 5 AH,

User accessible and replaceable

AC Power 100-240 V Auto sensing, 50/60 Hz,

Wireless Range Up to 300 Feet

UHF Wireless Frequency 678—697 MHz

Frequency Response: 40Hz to 20Khz

Sensitivity 96dB

Equalization (tone) Separate Bass and Treble

Line output: Buﬀered, 600 ohm, 1/4in.jack (pre fader)

Microphone Input: 1/4" and Balanced Combo

XLR / 1/4"

Weight: 35 lbs.

Dimensions (HWD ): 20" H x 13" W x 11" D

Extension Handle: 21 1/2"

Warranty 1 year Limited Warranty;

Remote Control, Wireless

Microphones, Wireless Receiver,

Bluetooth Module, CD / Media

Player, Rechargeable SLA

Batteries.

PLEASE NOTE: THE REMOTE DOES NOT

TURN THE UNIT ON OR OFF. YOU MUST

DO THAT ON THE CONTROL PANEL
