CONDENSING WALL-HUNG GAS BOILER

Country of Destination: GB/IE

CLAS HE R

HOT WATER HEATING RENEWABLE AIR CONDITIONINGI I I

G.C.N.: (24 kW)41-116-46

USER’S MANUAL

2 /

USER’S MANUAL

Dear Customer,

Thank you for choosing an ARISTON boiler.

We guarantee that your boiler is a reliable and technically

sound product.

This manual provides detailed instructions and

recommendations for proper installation, use and

maintenance.

Remember to keep this manual in a safe place for future

reference i.e. by the gas meter.

Your local ARISTON Servicing Centre is at your complete

disposal for all requirements.

GUARANTEE

The appliance is guaranteed for from the date of 2 years

purchase.

Aristons only obligation under the guarantee will be to repair

or replace the faulty appliance at Aristons discretion. This will

be carried out where the fault arises from within defects in the

appliance, caused either by material or workmanship of the

manufacturer.

This guarantee does not protect malfunction or damage

arising from incorrect installation, commissioning or

maintenance procedures as laid out in the installation and

servicing manual, inefficient flue system, poor or incorrect

electricicty, wrong gas supply or pressure, tampering by

inexperienced persons and any other cause not directly due

to manufacture.

Ariston Thermo UK Ltd cannot accept responsibility for any

cost arising from repair or maintenance carried out by any

third party.

Service under the guarantee does not affect the expiry date of

the guarantee. The guarantee on parts and appliances which

are exchanged ends when the guarantee on the original

appliance expires.

This guarantee does not affect your statutory rights.

The boiler must be registered with Ariston within 30 days from

date of installation.

Registration is online at www.ariston.co.uk.

/ 3

USER’S MANUAL

The installation and ﬁrst ignition of the boiler

must be performed by qualiﬁed personnel in

compliance with current national regulations

regarding installation, and in conformity

with any requirements established by local

authorities and public health organisations.

After the boiler has been installed, the installer

must ensure that the end user receives the

declaration of conformity and the operating

manual, and should provide all necessary

information as to how the boiler and the safety

devices should be handled.

This appliance is designed to produce hot water for domestic use

(combi version).

It should be connected to a heating system and a distribution

network for domestic hot water, both of which must be compatible

with its performance and power levels.

The use of the appliance for purposes other than those speciﬁed is

strictly forbidden. The manufacturer cannot be held responsible for

any damage caused by improper, incorrect and unreasonable use

of the appliance or by the failure to comply with the instructions

given in this manual.

Installation, maintenance and all other interventions must be

carried out in full conformity with the governing legal regulations

and the instructions provided by the manufacturer. Incorrect

installation can harm persons, animals and possessions; the

manufacturing company shall not be held responsible for any

damage caused as a result.

In the event of any maintenance or other structural work in the

immediate vicinity of the ducts or ﬂue gas exhaust devices and

their accessories, switch the appliance oﬀ by switching the external

bipolar switch to the “OFF” position and shutting oﬀ the gas valve.

When the work has been completed, ask a qualiﬁed technician to

check the eﬃciency of the ducting and the devices.

If the boiler should be out of use for a prolonged period, it is

recommended that the electrical power supply be disconnected

and that the external gas cock be closed. If low temperatures are

expected, the boiler and system pipe work should be drained in

order to prevent frost damage.

Turn the boiler oﬀ and turn the external switch “OFF” to clean the

exterior parts of the appliance.

Do not allow children or inexperienced persons to use the

appliance without supervision.

CE labelling

The CE mark guarantees that the appliance conforms to the

following directives:

- 2009/142/CEE

relating to gas appliances

- 2004/108/CEE

relating to electromagnetic compatibility

- 92/42/CEE

relating to energy eﬃciency

- 2006/95/CEE

relating to electrical safety

- 2009/125/CE

Energy related Products

- 813/2013

Commission regulation (EU)
