PREDATOR PRO
TACTICAL FLASHLIGHT
2 ENG USER MANUAL
6 GER BENUTZERANLEITUNG
10 FRA MANUEL D’UTILISATEUR
14 RUS РУКОВОДСТВО ПОЛЬЗОВАТЕЛЯ
18 FIN KÄYTTÖOHJE
22 SWE ANVÄNDARMANUAL
26 NOR BRUKSANVISNING
30 POL INSTRUKCJA OBSŁUGI REV_00-0000
2 ENG USER MANUAL PREDATOR PRO REV_000000
• Special precisely calculated reflector for High Intensity LED modifi-
cation, which provides 1.5 times the light range compared to a usual
LED, and tempered glass with anti-reflective coating for maximum
throw create clear central spot with minimal side spill at 1500 lumens
brightness. Spill diameter is 9 meters at 100 meters distance
• Powerful electronics provides constant brightness even at a tem-
perature of -40 °C and not fully charged battery
• Two types of operation: hunting and tactical. Tactical operation for
quick access to maximum brightness mode and Strobe mode
• Withstands any recoil due to improved springs and installation of the
driver inside a reinforced capsule filled with protective compound
• Standard 1 inch body is compatible with any accessories, including
original magnetic remote switch and magnetic mount for quick
one-motion attachment and removal
• Two-phase electronic button retained two levels of pressing similar to
mechanical switch, but became noiseless and 20 times more durable
• Non-flat button allows to easily switch the flashlight with a palm
Specifications
• Innovative technology allows using any standard 18650 Li-Ion bat-
teries with 10A discharge current and provides full protection against
short circuit even in case of contact between magnetic connector and
metal objects
• Solid body made from aircraft-grade aluminium, special matt anti-
abrasive finish without rough knurling
• Steel striking bezel with matt non-reflective black titanium coating,
which prevents location disclosure, is used for additional protection of
the optical system in the event of a fall and as a shock-crushing tool
• Active real-time temperature control to prevent overheating above
+58 °C and warning indication of low battery level
• Total protection from water, dirt and dust in accordance with IP68
standard — flashlight continues to work even at 25 meters depth up
to 5 hours. Withstands fallings from the 10th floor
• Robust and water resistant magnetic connector
ENG USER MANUAL
Thank you for choosing the products of Armytek.
Please read this manual carefully before using the flashlight.
Model Predator Pro (White)
LED/Optics Cree XHP35HI/Smooth reflector
Brightness stabilization type FULL (constant light)
Light output 1500 lm
Peak beam intensity 62800 cd
Hotspot : Spill 5°:40°
Beam distance 501 m
Modes, light output and runtimes (measured
with 18650 Li-Ion 3500 mAh battery until the
light output drops to 10% of the initial value)
Turbo 1500 lm/1 h 33 min (700 lm after 3 min)
Main3 300 lm/5 h 13 min
Main2 120 lm/12 h 20 min
Main1 40 lm/32 h
Strobe2 1500 lm/15 Hz/3 h (700 lm after 3 min)
Strobe1 120 lm/15 Hz/23 h
Power source 1x18650 Li-Ion
Length/Body diameter/Head diameter 160 mm/25.4 mm/41 mm
Weight without/with battery 136 g/186 g
Dust, water and impact resistance IP68. Submersion at 25 m up to 5 h. Fallings from 25 m
XLight output for flashlights with Warm light is about 7% less, beam distance is about 3% less. All the above specifications are test results based on ANSI/NEMA FL1-2009 Standard. The tests are
performed using the battery included in the set. The data may vary due to environment, heat dissipation and other factors.
3PREDATOR PRO USER MANUAL ENGREV_000000
Set description
Flashlight, 18650 Li-Ion 3500 mAh battery, magnetic USB charger, clip,
lanyard, holster, silicone grip, 2 spare O-rings, user manual.
The producer reserves the right to change the package at his own
discretion without modifying this manual. Specifications are sub-
ject to change without notice.
Initial Service
TO SET/REPLACE BATTERY
1. Unscrew the tailcap.
2. Place the battery with the positive contact (+) facing the head of the
flashlight.
3. Adjust the tailcap and tighten it as far as it can go.
The flashlight is ready for operation.
HOW TO CONNECT THE MAGNETIC CHARGER
Tighten the head of the flashlight as far as it can go and adjust the
magnetic charger to the tailcap.
CHARGER COLOR INDICATION
Charger not plugged in:
• Green — device is in waiting mode.
Charger plugged in:
• Green blinking — evaluation of battery voltage.
• Red blinking — clean the external and internal contacts of the tailcap,
as well as the contact areas of the charger.
• Orange blinking — USB power source voltage is too low for correct
continuation of charging or bad contact between charger and battery.
Clean the tailcap and the threads of the flashlight parts, use a dier-
ent power source.
• Red — charging with rated charging current is going on.
• Orange — USB power source voltage is too low, charging current is
reduced.
• Green — charging is finished.
Operation
Before use: Tighten the tailcap as far as it can go.
IN ANY MODE
Permanent on. First full click of the button turns the flashlight on.
Second full click turns it o.
Momentary on. Switched on by half-pressing of the button (no click)
and active till the button is released.
To switch between types of operation unscrew and tighten up the
head of the flashlight at least 10 times (during rotation the modes will
be changing). The pause between the moves must be less than 1 sec.
The flashlight blinks once, confirming the action.
HUNTING TYPE (BY DEFAULT)
Turbo. Before switching on the flashlight in Turbo mode, tighten the
head of the flashlight if it is unscrewed.
Additional modes. Before switching on the flashlight in Additional
mode, unscrew the head to 1/8 if it is tightened. Full click switches on
the last used Additional mode.
Cycling through Additional modes. To switch the mode turn the
flashlight o and on (by full click or half-pressing). The flashlight must
not be turned o for more than 2 sec. The modes switch cyclically:
Main1 – Main2 – Main3 – Strobe2 (if enabled).
Add/Remove Strobe2 in Additional modes. Switch on the flashlight
by half-pressing at least 20 times. The flashlight must not be turned on
for more than 1 sec. Last switch must be full click. The flashlight blinks
once, confirming the action.
Remote switch must be used in Turbo mode.
TACTICAL TYPE
Constant light. Before switching on the flashlight in Constant light
mode, tighten the head if it is unscrewed.
Changing Constant light modes. The head is tightened: unscrew it to
1/8 and tighten again in 1 sec. Turbo and Main2 will switch cyclically.
