WIZARD C2
PRO MAX
MULTI FLASHLIGHT
2 ENG USER MANUAL
6 GER BENUTZERANLEITUNG
10 FRA MANUEL D’UTILISATEUR
14 RUS РУКОВОДСТВО ПОЛЬЗОВАТЕЛЯ
18 FIN KÄYTTÖOHJE
22 SWE ANVÄNDARMANUAL
26 NOR BRUKSANVISNING
30 POL INSTRUKCJA OBSŁUGI REV_00-0003
2 ENG USER MANUAL WIZARD C2 PRO MAX REV_00-0003
Specifications
Headlamp: simple one-hand operation, reliable headmount. Solid body
without long wires, weak rubber connectors and unnecessary boxes.
The flashlight is easily installed, removed and 180° rotatable in the
mount. Quick-release rubber ring provides additional fixation
Every Day Carry light: compact design, convenient side button, spe-
cial matt anti-abrasive finish without rough knurling, strong built-in tail
magnet and robust removable steel clip
Bicycle light: body made from durable and lightweight aircraft-grade
aluminium, improved shock resistance, new springs for better battery
and driver protection. Constant light without flickering, quick-release
mount in the set
• New generation electronics provides impressive light output of 4000
lumens. Constant brightness even at low ambient temperatures and
not fully charged battery
• Multicolor temperature, battery level and state indication with the
ability to turn it o
• Convenient wide beam of fully upgraded optical system, TIR-lense
is protected from scratches by tempered glass with anti-reflective
coating
• Innovative technology allows using any 21700 or 18650 Li-Ion bat-
teries with 15A discharge current and provides full protection against
short circuit even in case of contact between magnetic connector and
metal objects
• Active real-time temperature control to prevent overheating above
+58 °C
• Total protection from water, dirt and dust in accordance with IP68
standard — flashlight continues to work even at 10 meters depth.
Withstands fallings from up to 10 meters
• Robust and water resistant magnetic connector
ENG USER MANUAL
Thank you for choosing the products of Armytek.
Please read this manual carefully before using the flashlight.
Model Wizard C2 Pro Max (White)
LED/Optics Cree XHP70.2/TIR
Brightness stabilization type FULL (constant light)
Light output 4000 lm
Peak beam intensity 3300 cd
Hotspot : Spill 110°:150°
Beam distance 114 m
Modes, light output and runtimes (measured
with 21700 Li-Ion 5000 mAh battery until the
light output drops to 10% of the initial value)
Turbo2 4000 lm/3 h 15 min (900 lm after 50 sec)
Turbo1 1300 lm/3 h 20 min (900 lm after 12 min)
Main3 450 lm/7 h
Main2 150 lm/21 h
Main1 45 lm/64 h
Firefly2 4.6 lm/2 weeks
Firefly1 0.35 lm/2 months
Strobe3 4000 lm/10 Hz/6 h 50 min (900 lm after 2 min)
Strobe2 4000 lm/1 Hz/14 h (900 lm after 10 min)
Strobe1 150 lm/1 Hz/90 h
Power source 1x21700 Li-Ion, 1x18650 Li-Ion
Length/Body diameter/Head diameter 121.5 mm/23.6 mm/34.4 mm
Weight without/with battery 79 g/149 g
Submersion and Impact resistance IP68, 10 m for 2 h. Height up to 10 m
XLight output for flashlights with Warm light is about 7% less, beam distance is about 3% less.
All the above specifications are test results based on ANSI/NEMA FL1-2009 Standard. The tests are performed using the battery included in the set.
The data may vary due to environment, heat dissipation and other factors.
3WIZARD C2 PRO MAX USER MANUAL ENG
REV_00-0003
Set description
Flashlight, 21700 Li-Ion 5000 mAh battery, 18650 battery adapter,
magnetic USB charger, clip, headmount, bicycle mount ABM-01, 2 spare
O-rings, user manual.
The producer reserves the right to change the package at his own
discretion without modifying this manual. Specifications are sub-
ject to change without notice.
Initial Service
TO SET/REPLACE BATTERY
1. Unscrew the tailcap.
2. Place the battery with the positive contact (+) facing the head of the
flashlight.
3. Adjust the tailcap and tighten it as far as it can go.
The flashlight is ready for operation.
HOW TO CONNECT THE MAGNETIC CHARGER
Unscrew the tailcap for 1/4 of a circle and adjust the magnetic charger
to the tailcap.
CHARGER COLOR INDICATION
Charger not plugged in:
• Green — device is in waiting mode.
Charger plugged in:
• Green blinking — evaluation of battery voltage.
• Red blinking — unscrew the tailcap for 1/4 for charging.
• Orange blinking — USB power source voltage is too low for correct
continuation of charging or bad contact between charger and battery.
Clean the tailcap and the threads of the flashlight parts, use a die-
rent power source.
• Red — charging with rated charging current is going on.
• Orange — USB power source voltage is too low, charging current may
be reduced.
• Green — charging is finished.
Operation
Before use: Tighten the tailcap as far as it can go.
GENERAL TYPE
Modes: Firefly1, Firefly2, Main modes, Turbo mode (last used in
Advanced, Turbo2 by default).
In OFF state
1 click: To turn on the last used mode.
Press and hold: To start cycling through Firefly modes. Release to
select. Keeping button pressed will start cycling through Main modes.
In ON state
1 click: To turn o the flashlight.
Press and hold: To start cycling through Main modes from any mode. In
Firefly1 cycling through Main modes starts after cycling through Firefly
modes. Release to select.
2 clicks: To turn on Turbo mode from any mode. The second double click
brings back last used mode.
ADVANCED TYPE
To switch between types of operation unscrew the tailcap to 1/4 while
the flashlight is o, press the button and tighten the tailcap while
keeping the button pressed.
Sections of modes:
[1] – Firefly modes, [2] – Main modes, [3] – Turbo modes,
[4] – Strobe modes
In OFF state:
1 click: To turn on the last used mode.
Press and hold: To turn on Firefly1 mode [Section 1]. Keeping button
pressed will start cycling through modes: Firefly1 - Firefly2 - Main1 -
Main2 - Main3 - Turbo1.
