Specifications

Thank you for choosing the products of Armytek Optoelectronics Inc., Canada.

Please read this manual carefully before using the flashlight.

USER MANUAL

THE MOST TECHNICALLY ADVANCED

Warnings

Care and Storage

Service and Warranty

Specifications are subject to change without notice.

Model

Tiara A1 Pro

Tiara C1 Pro

LED / Optics

Cree / TIRXP-L or XM-L2

Brightness stabilization type

FULL (constant light)

Light output, LED / OTF lumens*

600 / 450

800 / 610

Peak beam intensity, candelas

1840

2160

Hotspot / spill

70 ° / 1 0°2

Beam distance*

86 meters

93 meters

Modes, light output (OTF

lumens*) and runtimes

(measured with Sanyo

Eneloop AA 2000 mAh /

Armytek CR123A 1500 mAh

until the light output drops to

10% of the initial value)

Turbo2

450 lm / 0.8h

610 lm / 0.7h

Turbo1

250 lm / 1.2h

250 lm / 1.8h

Main3

90 lm / 4.2h

90 lm / 6.2h

Main2

30 lm / 11.7h

30 lm / 18h

Main1

9 lm / 35h

9 lm / 55h

Firefly2

1.9 lm / 8d

1.9 lm / 13d

Firefly1

0.15 lm / 90d

0.15 lm / 140d

Strobe3

1Hz / 30 /lm 60h

1Hz / 30 /lm 90h

Strobe2

1Hz / /450lm 6h

1Hz / /610lm 3.3h

Strobe1

10Hz / /450lm 1.7h

10Hz / /610lm 1.7h

Power source

1xAA / x14500 Li-Ion1

1x18350 Li-Ion / xR123 Li-Ion / 1x R123A1 С

Size and weight (without batteries)

Length 93mm, body diameter 24.5mm,

head diameter 29mm, weight 59g

Length 79mm, body diameter 24.5mm,

head diameter 29mm, weight 56g

Armytek Optoelectronics Inc.

Web: www.armytek.com Email: service@armytek.com

Address: 13-85 West Wilmot St, Richmond Hill, Ontario, L4B 1K7, Canada

Tiara

Armytek Optoelectronics Inc. is a Canadian manufacturer that produces powerful and reliable flashlights designed especially for your

needs. The components made in the USA and Japan. .10 years no-hassle warranty

§Superb light of amazing constant brightness due to powerful electronics.

§Multi-flashlight “10 in 1" is for many activities: car, fishing, hunting, home, work, city, picnic, bike, outdoor, travel.

§Efficient TIR-optics and no “tunnel vision” effect even after continuous use.

§Multicolor Warning Indication of low battery level.

§Side switch for comfortable one-hand operation and easy modes switching with advanced operation.

§Multicolor State Indication and ultra low current drain in OFF-state more than 25 years.–

§Comfortable headband for reliable fixation of the flashlight – it won’t slip even while you’re running.

§Solid body without long wires, weak rubber connectors and unnecessary boxes.

§Removable magnet in the tailcap, removable clip, strong lanyard and possibility of tail-stand for multipurpose use.

§Compact and light-weight flashlight of guaranteed durability stands up harsh impacts and falling from 10 meters.

§–Total protection from water, dirt and dust penetration flashlight continues to work even at the depth of 10 meters.

We DO NOT RECOMMEND to use low-quality CR123A batteries, because they can explode.

* Light output for flashlights with Warm light are about 7% less, beam distances are about 3% less.

Armytek provides free warranty repair for 10 years from the purchase.date of

Warranty doesn't cover damage caused by:

1. Improper usage.

2. Attempts to modify or repair the flashlight by nonqualified specialists.

3. Longtime application in chlorinated or polluted water, or other liquids (other than water).

4. High temperatures and chemicals' exposure (including the exposure of liquid from defected batteries).

5. Usage of low-quality batteries.

1. Always follow the instructions from this manual and recommendations on battery usage.

2. Apply only the recommended power sources.

3. Do not reverse battery polarity.

4. Do not use different power sources together, i.e. old ones with new ones, charged with

discharged. Do not use different types of batteries combined as the element with less

capacity can be damaged.

5. Do not modify or recast the flashlight and its components as it will deprive you of the

warranty.

6. Do not allow water or any other liquid to leak into the flashlight.

7. Do not aim a switched-on flashlight at people's or animals' eyes – it can cause temporary

blindness.

8. Do not allow children to use the flashlight without your assistance.

The producer will not be liable for any harm done to the user if it was caused by

improper use of the product.

It is recommended to clean the threads and O-ring off dirt and old greases once or twice per year. Remember that protection reliable

from water and dust cannot be provided by worn out sealing. The fouling as well as lack of lubricant cause fast wear-out of threads and

sealing rings.

To clean the threads do the following:

1. Unscrew the tailcap and remove the sealing ring carefully with a toothpick (do not use sharp metal things as they can damage the ring).

2. Wipe the sealing ring thoroughly with a soft cloth (or tissue). Do not use solvents. If the sealing ring is worn out or damaged

replace it by a new one.

3. Clean the metal threads with a brush using ethanol. Be careful not to allow the applied liquid to get inside the flashlight or tailcap as

it can cause fails in functionality of the flashlight.

After cleaning lubricate the thread and the sealing ring with polyalphaolefin-based silica grease, e.g. Nyogel 760G.The application of

automotive and other improper grease can cause swelling and damage of the sealing rings.

In case of active operation and exploitation in dusty environments, it is recommended to perform cleaning and lubricating of the parts

as often as required.

The flashlight will get hot in Turbo mode quickly and discharge the battery by high current. Don't leave it without your attention as very

bright light can heat objects and be a cause of the fire.

We DO NOT RECOMMEND to leave power sources inside the flashlight for a long storage period, as batteries (especially, non-rechargeable) can

leak for various reasons and damage the inner parts of the flashlight. If you want to keep your flashlight in a stand-by state with batteries in use then

new and quality batteries store the flashlight in acceptable for batteries operational temperature and revise the batteries' state at least high- and

once a month. If you have noticed any signs of batteries' defects withdraw them from the flashlight and utilize. It is also recommended to then

replace discharged batteries with new ones before the storage as the chance of leakage is higher with discharged batteries.

Downloaded from manuals search enginewww.Manualslib.com

Set description

ьDepending on the model, your flashlight can inconsiderably differ from the pictures in the manual.

ьThe producer reserves the right to change the package at his own discretion without modifying this manual.

Operation

Items included in the package:

1 - Flashlight 6 - 2 spare O-rings

2 - Clip 7 - Magnet

3 - Lanyard 8 - Plastic holder

4 - Headband 9 - User manual

5 - Hand band

Tiara

Initial Service

To set/replace batteries:

1. Unscrew the tailcap.

2. Place the batteries with the positive contact (+) facing the

head of the flashlight.

3. Adjust the tailcap and tighten it as far as it can go.

The flashlight is ready for operation.

The removable magnet in the tailcap.

With its help you can easily attach the flashlight to an electric service panel, a bike handlebar ,

above a car wheel . , etc

The magnet can be taken out the tailcap. To do this unscrew the small cover at the end of the of

tailcap and put the magnet out.

Main

Press & HoldClick x2

Main Fireflyв

Any State Main

Main1 Main2в

ез

Main3

Click x2 Press & Hold Firefly

Firefly

гд

Main

OFF Firefly1в

Turbo1

гд

Turbo2

Press & Hold Turbo

Click x3

вTurbo

Any State

Strobe

Press & HoldClick x4

Any State вStrobe Strobe Strobe1 в2

ез

3Strobe

Multicolor Voltage Indication

5sec

The flashlight has 4 Sections of modes:

[Section1] – Firefly modes

[Section2] – Main modes

[Section3] – Turbo modes

[Section4] – Special modes

In OFF state:

Click: To turn on the last used mode.

Press and hold: To turn on Firefly1 mode in [Section 1].

In ON state:

Click: To turn off the flashlight.

Press and hold: To start cycling through the modes of actual

Section.

The same in OFF & ON states:

2 clicks: To turn on the Main mode . Then double [Section 2]

clicks will switch modes between chosen modes in

[Section 1] and [Section 2].

3 clicks: To turn on Turbo mode [Section 3].

4 clicks: To turn on Strobe mode [Section 4].

Automemorizing. After switching off the last used Mode is

memorized for quick 1-click access at next switching on.

Lock-out function. Unscrew the tailcap to 1/4 for the

protection from accidental switching on. State Indication will

be turned off.

Constant light. Powerful electronics provide constant

brightness even in the Turbo1 mode, using all energy of the

battery. And the Turbo2 mode gives the maximum

brightness as the Overboost technology in cars, but until

discharge current of the battery don't exceed critical values.

Digital Light Stabilization &Safe Soft-Start System monitors

battery voltage, starts the flashlight at an admissible

brightness or decreases it by steps when the voltage

dramatically fall down. These actions increase runtime, use

all available energy, get longer lifetime of rechargeable

battery and protect it from overdischarge or overheating.

Multicolor Voltage Indication. Shows the battery level by

short flashes every 5 seconds. There is no Voltage Indication

in OFF state and Firefly modes.

Warning Indication – Low Battery Level.

When it is < 25%, the color LED will show the warning level –

flashing in orange color once in 2 second. With a further

voltage reducing brightness will start to decrease in steps for

safety of the battery and user. If brightness will be <25%

from nominal value, the main LED will flash 2 times. Critical

battery level <10% is red indicated once a second.

OFF

Firefly1

Firefly2Main3

Main1Main2

Turbo1

Press & Hold Release while blinking 3 times/sec Click p2-x1 or x2

Specifying the battery type for correct voltage indication.

1xAA (for Tiara A1 Pro) 1xCR123A for Tiara C1 Pro Do not specify the type of power source manually unless you battery is by default. / ( )

use unprotected Li-Ion batteries different from those that are stated by default.

To access the Menu press and hold the switch button (when the flashlight is switched off). It will switch on, go through 6 , then modes

after 2sec in Turbo1 mode – enter to Menu and flash about 3 times a second.

Now you can specify the battery type:

§1 click for AA (Tiara A1 Pro) / CR123A (Tiara C1 Pro).

§2 clicks for 14500 Li-Ion (Tiara A1 Pro) / 18350 Li-Ion or RCR123 Li-Ion (Tiara C1 Pro).

After the choice is made the light will flash 1 or 2 times to show the battery type chosen.

To use the head mount with the flashlight:

1xAA or

1xCR123A

1x14500 Li-Ion or

1x 18350 Li-Ion /

1x CRR 123 Li-Ion

1sec

Warning Indication

Warning Critical

< %25 < %10

2sec

< 100%

< 5%7

Firefly1

гд

Firefly2

Put in the band in the first clasp. Put in the band through the slots in the plastic holder

and fix the flashlight. Adjust elastic band to the size

of your head.

1.3.

Pass the end of the band through the second clasp and fix it.

Downloaded from manuals search enginewww.Manualslib.com
