Sida 1/4
TWO CHANNEL LINE OUTPUT CONVERTER &
LINE DRIVER WITH IMPEDANCE MATCHING
FACTO RY S YST E M U P G R A D E
TWO CHANNEL LINE OUTPUT CONVERTER &
LINE DRIVER WITH IMPEDANCE MATCHING
Power
As awesome as it is that the LC1i can be turned
on 3 dierent ways, you still very much need to
connect the LC1i to constant +12V power and
ground.
Maybe one day science will invent a way to
electrically power devices via the sweet guitar solo of Jimi
Hendrix, but until then, we need +12V power and ground.
GTO Signal Sense
DC oset is a high falutin technical term that means
the LC1i can sense when the head unit is on, not
necessarily when audio is being sent to the LC1i.
Use GTO Signal Sense mode when your factory
sound system outputs a DC oset when it is on.
Audio Sense
When this mode is selected, the LC1i will ONLY
turn on when you start playing a source from the
head unit. Whether it be the radio, CD player or
streaming via Bluetooth from a mobile device. If
you turn the head unit on, but DON’T play audio,
the LC1i will not turn on.
Remote Input
This is the traditional way to turn on the LC1i and
gives you more control of exactly when the unit
will turn on. Most common places to connect the
remote input are from the ignition of the vehicle,
fuse box, or some other 12V source (such as a
cigarette lighter).
Quick Start
1. LC1i is active and REQUIRES CONSTANT +12V POWER
2. Pick a suitable mounting location that will provide access
to the controls and connections. Protect the LC1i from heat,
moisture, and dirt.
3. Use the integrated mounting brackets to mount the LC1i.
4. Before drilling holes, take every precaution to prevent
damage to fuel lines, power and other electrical wiring,
hydraulic brake lines, and other systems that might
compromise vehicle safety.
5. When making connections, designate red RCA plugs as
right, and designate white, black, or gray plugs as left.
6. Connect the +12V input terminal of the unit to the +12V
terminal on the vehicle battery (or distribution block) using
16 to 14 AWG.
7. Connect the Ground terminal of the unit to the Ground/
Negative terminal of the battery (or distribution block) using
the same gauge wire as the +12V power wire.
8. For +12V remote turn on the Trigger Mode switch must be
set to “Rmt In”. Connect the Remote In (Rmt In) terminal of
the unit to a remote turn-on switch. Alternately, use GTO™
Signal Sense or Audio Sense to trigger the unit on without a
remote wire.
9. Connect the Speaker Level Inputs to the output of your
factory head unit or amplier. Alternately, connect the Line
Level inputs to the output of your aftermarket source.
10. Adjust the input gain using the Output Level knob.
11. Connect the Output RCAs to your aftermarket amplier.
12. Enjoy the drive!
Ground Isolation Switch
This handy switch allows the user to change
how the LC1i is grounded. Sometimes when
installing car audio equipment, “ground
buzz” or “alternator whine” will creep into the
audio path, wreaking havoc on your listening
experience. There are 3 positions. GND, ISO, and 200 ohms. The
unit ships from the factory in the ISO position.
GND - Power ground and audio ground are tied together.
ISO - Power ground and audio ground are separate.
200Ω - There is 200 ohms of resistance between power ground
and audio ground.
Load Selection Switch
The LC1i is designed to present NO load to the
output of the factory amp, which can make some
factory amps upset and stop passing audio. The
Load Selection feature tricks the factory amp in
to detecting a speaker load so it will continue to
pass audio. Set the Load Selection Switch set to 20 kΩ if you are
using the Line Level Inputs.
20 Ω - Best suited for late model Dodge/Chrysler/Jeep/Ram/Fiat
vehicles equipped with OEM base sound system. (no separate
factory amplier)
60 Ω - Best suited for late model Dodge/Chrysler/Jeep/Ram/Fiat
vehicles equipped with a separately amplied OEM “premium”
sound system.
20 kΩ - Best suited for all other applications. Required setting for
Line Level Inputs.
Line Level Inputs
To use the LC1i as a line driver, connect the Line Level inputs
to the outputs of your after market source and set the Load
Selection Switch to 20 kΩ. Signal from the Speaker Level and Line
Level inputs will be mixed when used concurrently.
Setting Levels
Use the Output Level knob to adjust the output
level. We would say more here, but it doesn’t get
much simpler than that.
Maximized Light
The Maximized Light can be used to help
achieve optimal output level and will let you
know if you are getting close to clipping the
output of the LC1i.
With the factory system set to its maximum
undistorted volume, match the output level of the LC1i to
the input maximum of your after market amplier. If the
Maximized Light turns on, the LC1i output is distorting. Turn
the output level down until the Maximized Light turns o. IF
THE MAXIMIZED LIGHT NEVER TURNS ON, don’t panic. This just
means the output of the LC1i is not clipping/distorting.
Remote Output
Use the Remote Output (Rmt Out) to trigger on your
aftermarket amplier. When the LC1i turns on (regardless of
method) the Remote Output will always be active. Do not
connect more than two ampliers to the LC1i Remote Output.
Connecting more than two ampliers may damage the LC1i.
