Sida 1/8
ANT1400
Flat Multi-Directional Indoor Antenna
Antena multidireccional plana para interiores
User’s Guide
Guía del Usuario
Congratulations on your purchase of the ANT1400 Flat Multi-Directional Indoor Antenna.
With this contemporary antenna, rabbit ears are a thing of the past. This sleek, attractive
antenna features the most advanced technology, including a patented engineering design that
provides excellent reception for both analog and digital TV broadcasts.
Multi-Directional Antennas
A multi-directional antenna is able to receive signals from any direction. Useful for both
analog and digital reception, the ANT1400 looks great, facilitates optimal reception,
and requires very little space. The patented multi-directional technology ensures that the
antenna does not need to be adjusted according to the location of the transmitting signal.
The Switch from Analog to Digital
Because of the February 2009 switch to digital signals, the ANT1400 has been designed for
great reception of both analog and digital signals. Regardless of your reception needs, analog
or digital, the ANT1400 provides high-quality reception.
ANT1400 Features
The ANT1400 Flat Multi-Directional Indoor Antenna is packed with features that make it
as functional as it is attractive. Because the ANT1400 is multi-directional, there is no need
to constantly turn the antenna to improve reception. And, with its compact footprint, the
ANT1400 is so unobtrusive, you can hang it on the wall or lay it flat. Its attractive design
complements any décor. The ANT1400:
• Outperformstraditionalantennasduetopatenteddesign
• Eliminatesconstantadjustmentswithmulti-directionalreceptionpattern
• Getsgreatreceptioninanyposition—layingatorhanging
• Takesupminimalspace
• Featuresamodern,contemporarylook
2
English
ANT1400 Hardware
Before attempting to use your antenna, please remove all parts from the box and read the
instructions carefully The ANT1400 antenna package includes the following items:.
1 ANT1400 Flat Multi-Directional Antenna with Built-In 6’ Coaxial Cable
Setting Up the ANT1400
Find the best location for the antenna
Before you connect the antenna, determine the best spot in your home for optimum
reception. Visit www.antennaweb.org to see where your local broadcasts are coming from.
Then, try as much as possible to avoid obstructions between these transmitters and your
antenna.
Because of its multi-directional capabilities, the ANT1400 receives UHF, VHF, and local
high-definition broadcasts, providing quality reception from most locations.
Note: The ANT1400 may work well sitting on your TV or other components. However, because
electronic components can sometimes interfere with the antenna’s reception, you might notice an effect
on the antenna’s performance. Likewise, placing the antenna on a metal surface may interfere with
reception. If the antenna isn’t performing as well as expected, try moving it away from the component
or placing it on another surface. Then, re-scan for channels on your TV or converter box.
Positioning the Antenna
After locating the optimal position for your antenna, choose from one of two options:
• Lay the ANT1400 flat The ANT1400 has raised feet on its bottom to prevent
scratching of furniture. Make sure you place the antenna on a flat, level surface.
Note: This is the position that usually gives optimal performance.
• Hang the ANT1400 The back of the ANT1400 antenna has two mounting holes that
can be used for hanging. Place both holes over screws inserted in your wall.
Connecting the ANT1400
You can connect the ANT1400 directly to your TV or use it with a converter box.
3
English
1. Make sure your TV is turned off.
2. Connect the ANT1400’s built-in coaxial
cable to the antenna input on your TV.
3. Re-scan for channels on your TV.
Built-In
Coaxial Cable
ANT1400
TV
2
3
1. Make sure your TV is turned off.
2. Connect the ANT1400’s built-in coaxial
cable to the antenna input on your
converter box.
3. Connect the converter box to your TV
using either audio/video cables or a
coaxial cable:
a. Audio/Video cable connection:
Connect the video (yellow) and stereo
audio (red and white) cables to the
video and audio outputs on your
converter box. Connect the other ends
to the video and audio inputs on your
TV. Make sure you match the colors
ofthejacksoneach—yellowplugto
yellow jack, red plug to red jack, and
white plug to white jack.
Converter Box
Coaxial
Cable
Audio/Video
Cables
Built-In
Coaxial Cable
ANT1400
TV
–or–
3a
2
3b
4
To connect the ANT1400 to a converter box:
To connect the ANT1400 directly to your TV:
b. Connect a coaxial cable to the antenna input on your Coaxial cable connection:
converter box. Connect the other end of the coaxial cable to the antenna input on your
T V.
4. Re-scan for channels on your converter box.
Notes: See your converter box’s owner’s manual for more detailed connection instructions. For
additional information about setting up your converter box, visit www.keepmytv.com
