Sida 1/16
ANT800
Outdoor Antenna
User’s Guide
Getting Started
Remove the antenna and the hardware bag from package. Make sure the
following parts are in the package:
• Antenna
• AmplierInsert •PowerAdapter
• MountingBase •MountingArm
• Hardwarebag:
(2) Screws (4) Screw Covers
(2)U-Bolts (2) Clamps
(4) Wing Nuts (4) Wood Screws
(1)RubberBootforAntennaConnector/CoaxialCable
Finding the Right Location
BeforeyoumounttheANT800,considerthefollowingfactorsinreception
performance:
• TheANT800usuallyperformsbestwhenmountedhorizontally
• TheANT800shouldbemountedonthesideofyourhousethatfaces
mostofyourlocalbroadcasttowers(Seeillustrationbelow)Visit
www.antennaweb.orgtoseethelocationsofyourlocalbroadcast
towers.
• Thehighertheelevationoftheantenna,thebetterthereception
performance will be.
BEFORE YOU START!!!
PleasereadtheIMPORTANTSAFETYINFORMATIONsheetincludedin
this package.
ENGLISH
2
Mounting the Antenna
TheANT800mountingbracketgivesyouexibilityinmountingtheantenna.
TheANT800canbemounted:
• To a surface, such as a rooftop, eaves, siding, or rafters in
an attic
— OR —
• To a standard mast (not included)
WARNING: Never hang anything from the ANT800; never attach foreign
objects to the ANT800.
NOTES: Do not install the ANT800 on any metal surface, including
aluminum siding. Mounting on a metal surface will seriously degrade
reception quality.
In most cases, the ANT800 provides the best performance when mounted
outdoors in a high location (such as on the roof or high up on the side of
your house). The ANT800 can also be mounted in an attic.
3
ENGLISH
Mounting to a Surface
1. Orient the antenna base.
Makesurethebaseisorientedcorrectlyfor
thedirectionyouwanttopointtheantenna.
Use the illustration on the left as a guide.
Mounting
Well
Antenna points this way...
...or this way.
Wood
screw
Mounting base
2. Mount the base to the surface.
Findthefourwoodscrewsincludedinthis
package.Usingthesescrews,attachthe
base to the surface as shown here.
3. Attach the arm to the base.
Findoneofthescrews,washers,andnuts
included in the package.
First,setthewasherandnutinthe
mountingwell.Thenpositionthearmover
theothersideofthewell.Attachthearmto
the base as shown here.
4. Attach the antenna to the arm.
Findtheotherscrew,washer,andnut.
First,setthewasherandnutinthe
antenna’smountingwell.Thenpositionthe
armovertheothersideofthewell.Attach
the arm to the antenna as shown here.
continues on next page...
