Sida 1/11

8“/20 CM

ACTIVE SUBWOOFER

ACTIVE SUB

Installation & Operation Manual / Einbau- & Bedienungsanleitung

ATB120A

– 2 –

SAFETY INSTRUCTIONS

1. This unit is designed to be used in a vehicle with a 12V battery and negative ground.

2. Before any wiring, always remove the negative terminal of the battery to prevent short- circuiting.

This is also the last lead to be (re-)connected.

3. Do not disassemble or alter the unit in any way, because that will void your warranty. Do not

attempt to repair or to service the unit yourself, but contact an authorized AXTON dealer

instead.

4. Use only original accessories which are designed and manufactured for the unit, otherwise you

will risk damage. Install the unit according to the mounting manual and use only the supplied

mounting accessories. The forces of acceleration for accidents are sometimes huge. Heavy

objects may pose a risk for the driver and the passengers of the car, during an accident.

5. Protect the unit from water and other liquids, which can enter the casing. A short circuit or

even fire could be the result.

6. Before you replace a defective fuse, try to find the cause for the short circuit. Please pay

attention to the cables of the power supply! If the short circuit doesn‘t result from a failure of the

power supply or wiring, you can replace the defective fuse with a new one of identical value.

If the short-circuit still exists, please contact an authorized AXTON dealer.

7. Be careful not to drain the car battery while using the unit when the car engine is turned off.

Because the unit uses a considerable amount of energy and the battery will be charged only

while the engine is running, it might happen that the battery will discharge to a point where it‘s

not longer possible to start the engine.

8. If your car is parked in direct sunlight and there is a considerable rise in temperature inside the

car, allow the unit to cool off before operation.

9. The amplifier module employs a protection circuit to protect the transistors and the woofer if

the amplifier malfunctions. The amplifier’s protection circuitry will shut-off the amplifier in case

of short-circuit, overload or DC offset at the speaker outputs or in case of overheat. In case

the cause for protection shut-off has been eliminated, the amplifier will operate normally again

(green LED ON/ Red LED OFF). Otherwise the amplifier will continue to remain in protection

mode.

10. Do not use the unit with a weak or old battery as its optimum performance depends on a normal

battery supply voltage.

11. Please pay attention to the music playback volume inside your vehicle, because you are obliged

to notice exterior sounds like a police siren or you might face penalties in case of an accident

or even loose your insurance cover.

12. Do not operate the unit in no other way than described in this manual. Failure to follow the

instructions within this manual will void your warranty.

– 4 –

Dear Customer

Thank you and congratulations on your purchase of the AXTON ATB120A. This active subwoofer

system exclusively uses very high quality parts and components. As with all high-quality car audio

components, professional installation is highly recommended.

If you plan on installing this active subwoofer by yourself, please read the following installation

guide carefully, before you attempt the installation. You should retain this manual, the packaging

and the purchasing receipt for future reference. For any further additional information about

mounting, connecting or adjusting this subwoofer system, please contact your AXTON dealer.

UNPACKING THE SYSTEM

Carefully remove all parts from the giftbox and check whether they are in good undamaged condi-

tion, and match with the set contents listed below:

nATB120A active subwoofer

nConnector

nOwner‘s manual

Please contact your authorized AXTON dealer, if the content of this set is incomplete,

or parts of it show signs of transport damage.

SPECIFICATIONS

• 8” / 20 cm active subwoofer

• Frequency response: 60 – 220 Hz

• 100 W rms x 1 @ 4 ohms (< 1.0 % THD / 14.4V)

• Variable lowpass filter: 50 – 150Hz / 12 dB/oct.

• Bass-Boost: 0 dB - 12 dB

• Phase-Shift: 0 / 180 degrees

• RCA, adjustable input sensitivity: 150 mV – 5 V

• High-Level, adjustable input sensitivity: 1.0 V – 16 V

• Signal to noise ratio: > 90 dB

• Dimensions H x W x D: 135 x 485 x 345 mm
