INSTALLATION & OPERATION MANUAL /

EINBAU- & BEDIENUNGSANLEITUNG

ATW16 ATW20 ISUBWOOFERS

Thank you and congratulations! You have purchased one of the nest subwoofers available in its respec tive price class. This AXTON

ATW subwoofer will give you great bass performance and true audiophile sound quality. To maximize the performance of your sub,

it is recommended to follow the enclos ure suggestions given in this manual. lf for some reason, the provided system/enclosure data

can not be applied within your specic vehicle or car audio installation, please contact your authorized AXTON dealer to ask for

further assistance.

LIMITED WARRANTY

AXTON warrants any ATW woofer to be free of defects in material and workmanship for a period of TWO YEARS from the original

date of purchase at retail, contingent upon installation being performed or ap proved by an authorized AXTON dealer. Should ser-

vice be necessary during the afore mentioned period, AXTON will at its own discretion repair or replace the defective speaker at

no charge. Damage caused by the following is NOT covered under warranty: Abuse of speaker due to excessive amplier power,

clipping, inappropriate enclosure design, or any further physical damage (during transportation).

CABINET CONSTRUCTION & DAMPING

For best results, use 19 mm to 22 mm MDF or birch plywood

to build the enclosure. All enclos ure volumes given are precise

internal chamber volumes, where displacement of driver and

port(s) have been included already.

Each enclosure, no matter what tuning prin ciple, needs internal

damping: The sealed and ported cabinets should be lined out

internally with "eggcrate" PU-foam.

KEY FEATURES ATW WOOFERS

6.5" / 8" BACK VENTED STEEL BASKET

120 MM HIGH EFFICIENT SINGLE MAGNET

HIGH STRENGTH FIBERGLASS/FOAM/PAPER CONE

LONG-THROW CONEX™ SPIDER

LONG-LASTING RUBBER SURROUND

TSL VOICE-COIL FORMER

1.5” COPPER WIRE DOUBLE VOICE COIL

HYPER-EXTENDED CENTER POLE

WOVEN TINSEL WIRES

RUBBER MAGNET BOOT

GOLD PLATED TERMINAL

Exclusive Distributor for Europe: ACR AG ∙ Bohrturmweg 1 ∙ CH-5330 Bad Zurzach ∙ Switzerland

EU Legal Representative:

ACR S & V GmbH ∙ Industriestr. 35 ∙ D-79787 Lauchringen ∙ Germany Rev. A

TECHNICAL SPECIFICATIONS ATW16 ATW20

Usable Frequency Response 65 ‒ 400 Hz 55 ‒ 300 Hz

Continuous Power Handling 75 W RMS 75 W RMS

Peak Power Handling 150 W max 150 W max

Nominal lmpedance 2 x 2 ohms 2 x 2 ohms

Voice Coil Diameter 38 mm 38 mm

Sensitivity 84 86.7dB dB

Mounting Diameter 145 mm 184 mm

Mounting Depth 79 mm 80 mm

THIELE-SMALL PARAMETERS

Free-Air Resonance (Fs) 47.1 Hz 36.34 Hz

DC Resistance (Re) 4.5 ohms 4.4 ohms

Electrical Damping (Oes) 0.63 0.35

Mechanical Damping (Qms) 6.23 7.98

Total Damping (Ots) 0.34 0.33

Equivalent Volume of Compliance (Vas) 7.15 21.49liter liter

Moving Mass incl. Air Load (Mms) 42.4 57.86g g

Electrically Limited Cone Excursion (Xmax p-p) 6.7 mm 6.7 mm

Effective Cone Surface (Sd) 136.8 cm² 213.8 cm²

RECOMMENDED ENCLOSURES

SEALED ENCLOSURE

Internal Volume 10 15l l

PORTED ENCLOSURE

Internal Volume 18 20l l

Port Diameter/Length 1 x 7 cm ‒ 20 cm 1 x 7 cm ‒ 25 cm
