Sida 1/14
Aero
G a m i n g c a s e
Installation Instructions
1. Specifications
2. Chassis Parts
3. Control Panel Functions
4. 3.5”/2.5” HDD/SSD Installation
5. Remove the Front Panel Instructions
6. Cooling System Installation
7. Master Fan & Sub-fan Installation
8. PSU Fans Installation
9. Fan Installation
10. RGB Lighting Switching
Specifications
Model
Model Name: Aero
Model Number: CSAZ-480
Specifications
Type: ATX Mid Tower
Color: Black/Black(interior)
Side Panel Window: Left side panel: slidable iron mesh side panel
Max CPU Cooler Height: UP to 170mm
Max Video Card Length: Up to 400 mm long video card
Power Supply: Not included
Motherboard Compatibility:
E-ATX ATX Micro ATX ITX、 、 、
External 5.25" Drive Bays: 0
Internal 2.5" Drive Bays:
Internal 3.5" Drive Bays: Up to 2
Expansion Slots:
Top Ports:
Physical Specifications
Case Dimension (HxWxD) 483x220x445mm/19x8.7x17.5 inches
Weight:
Mesh side panel:
Addressable RGB Light Effects: ARGB fans are controlled using the LED button. All addressable RGB devices can sync with the
motherboard,allowing the motherboard software to control lighting directly.
Available Fan Ports:
3x120mm or 3x140mm fan ports in the front (3x120mm LFO-3812D addressable ARGB fan included)
3x120mm or 2x140mm fan ports on the top
1x120mm fan port in the rear (1x120mm LFO-3812D addressable ARGB PWM fan included)
Water Cooling: Supports radiators up to280/360mm in the Front
Supports radiators up to280/360mm in the Top
Dust Filters: Removable (magnetic) dustproof net on the top, dust filter on bottom of chassis.
Power Supply Support: Bottom mounted ATX Power Supply
Expansion
Features
The full mesh side windows allow for clear visuals to inner components and increased air intake,
having maximum airflow performance.
Up to 4
2x120mm fan ports on the Power Supply Shroud
7
Power button, LED button, HD Audio, USB 3.0 x 2
6.1Kg /13.5lbs
