Sida 1/4
1
2
3
4
5
6
7
8
9
10
11
12
Iron front panel
LED lens
Lamp mylar film
Rear panel of the front
Left side tempered glass panel
Screws for side glass panel X4
Left side metal panel
2.5"SSD brackets X2
3.5"HDD brackets X2
Screws for the iron front panel X2
PCI slot cover
Right side metal panel
1
2
5
7
8
9
10
6
11
3
4
12
APOLLO 430
M I D - T O W E R T E M P E R E D G L A S S G A M I N G C A S E
ARGB Control Board
8.
All ARGB light sync. devices connected to the ARGB control board,
allowing the reset button or the motherboard software to directly control
the ARGB lighting.
※PWM Fan:The model comes with PWM fans and will run at top speed unless connected to
a motherboard or controller.
2.5"SSD brackets X2
Screws X2
Install 120mm fans:
Disassemble the front panel A to
install 120mm fans.
Install 140mm fans:
Disassemble the front panel A and the screws of front panel B,
then push up the front panel B to disassemble completely to
install 140mm fans.
PUSH UP
Addressable RGB fan installation for Motherboard
※Press the Reset button to cycle through different RGB lighting modes,
controlled by the Reset button though the ARGB control board.
※Hold the Reset button for 3 seconds to switch the RGB control function
between motherboard RGB software and Reset button.
Reset SW
ARGB Control Board
