Sida 1/13
Installation Instructions
1. Specifications
2. Chassis Parts
3. Control Panel Functions
4. Removing Panels / SSD Tray
5. Power Supply / 2.5" SSD Installation
6. Mounting Stand
7. Cooling System Installation
8. AZZA Hurricane II Digital RGB Fan Installation For Motherboard
Specifications
Model
Model Name CUBE MINI 805
Model Number CSAZ-805
Specifications
Type
Color
Side Panel Window
Max CPU Cooler Height UP to 130mm
Max Video Card Length Up to 200mm long Video card
Power Supply Not included
Motherboard Compa bilityMini ITX
External 5.25" Drive Bays
Internal 2.5" Drive Bays
Internal 3.5" Drive Bays
Expansion Slots
Physical Specifications
Metal Chassis Dimensions (HxWxD) 260x260x260mm/10.2x10.2x10.2 inch
Dimension with Case Stand(HxWxD) 472x371x372mm / 18.6x14.6x14.6 inch
Weight 5.4kg /11.9lbs
Addressable RGB Light E ectsAddressable RGB fan on the front. All addressable RGB light devices controlled
by motherboard.
Tempered Glass Side Window
Available Fan Ports
Water Cooling:
Isolated Chamber
Easy Installa on Cooler
0
3
USB3.0 x 2, HD Audio
Mini ITX Tower
Silver aluminum(exterior/interior)
Expansion
0
Up to 2
Dual-chamber design. Power Supply is housed in one of the chamber bo oms,
preven ng its heat from a ec ng other components.
A pre-cut hole for easy installa on of CPU Cooler,
elimina ng the need to remove the motherboard
Features
High-quality tempered glass side window allows for clear visuals
to innercomponents
1x120mm or 1x140mm fan port on the front (1x140mm AZZA Hurricane II
Digital RGB fan included)
1x80mm fan port in the rear (1x80mm black fan included)
Supports radiators up to 120/140mm in the Front
Front Ports
※PWM Fan:The model comes with PWM fans and will run at top speed unless connected to a motherboard or controller.
