Sida 1/2

WHAT’S IN THE BOX

CONNECT

INPUT DEVICE AND ETHERNET CABLE

IMPORTANT

• Download the latest B400S Owner’s manual from the Manuals/Downloads tab of www.bluesoundprofessional.com/product/B400S

• Visit support.bluesound.com for further assistance and information about getting the most out of the B400S.

Signal block

connector x 1

12V Trigger/

IR IN

connector

x 1

Analog IN

connector

x 1

Line OUT

connector

x 4

Feet x 4

B400S 4 Zone Network Music Player

Quick Setup Guide

Power connector x 2

DIGITAL AUDIO OUT

COAXIAL

External DeviceExternal Device

LAN

LAN 3LAN 2LAN 1

No part of this publication may be reproduced, stored or transmitted in any form without the written permission of Bluesound Professional.

B400SQSENV06185  JUL 2019

POWER UP!

DOWNLOAD

BluOS CONTROLLER APP

CONNECT

OUTPUT DEVICES

The BluOS Controller App for Apple iOS devices (iPhone, iPad, iPod), Android devices, Kindle Fire and Windows or Mac desktops are available for download from their

respective App stores.

Launch the BluOS Controller App to congure your B400S as well as explore everything from your streaming music services, internet radio stations, networked music

collections and favorites with quick and easy single-search discovery.

EXAMPLE CONFIGURATIONS

1 x multi-channel

amplier

2 x multi-channel

ampliers

4 x 2 channel ampliers

NOTE

Preamplier and digital preamplier output ports can be connected to a device with corresponding number and type of input ports or to individual devices with

appropriate type of input ports.

DIGITA

OPTICAL COAXIAL

DIGITAL AUDIO IN

COAXIAL

External Device

x1/x2/x3/x4

External Device

x1/x2/x3/x4

External Device

x1/x2/x3/x4

LINE / MIC IN
