Owner’s Manual

Welcome to Bluesound, Hi-Fi for the Wi-Fi generation.

Bluesound transforms your local digital music library by putting the music of your life right at your ngertips.

The clutter of CDs is relegated to a previous era! Your smartphone, desktop or tablet running the Bluesound App

now controls your music.

Your Bluesound music system is also a sophisticated Internet streaming device that allows you to listen to a

wide range of Internet music service providers. Bluesound also provides access to music subscription services

featuring extensive catalogs of millions of songs streamed to you over the internet in real time. TuneIn Radio

makes every radio station in the world a local station via the magic of the internet.

To take full advantage of all these Bluesound capabilities requires a robust wired or wireless home network and a reliable

high speed Internet connection, provided by a DSL or Cable modem. Internet access must be contracted and installed

by your local Internet Service Provider. For remote areas there are satellite options for high speed internet access.

Before signing on to a music subscription or cloud service we suggest that you review your Internet service plan

and be sure you have enough internet speed and bandwidth to provide uninterrupted streaming. Most internet

service providers offer multiple plans and can help you make the best choice.

For detailed instructions on how to control your Bluesound player, visit our website at: www.bluesound.com.

Included Accessories

Wireless Music

Streamer

Stereo RCA to RCA Cable 230V AC Power Cord

3.5mm Stereo mini Plug to RCA Cable Ethernet Cable

120V AC Power Cord Mini Jack to Toslink Adaptor

STATUS INDICATOR:

Below is a table of the LED blink codes and their corresponding descriptions.

LED BLINK CODE DESCRIPTION

Short blue ﬂash, then red Powering up, rebooting the unit

Solid green Hotspot Mode

Flashing green Connecting to Network shares

Solid red Cannot boot; drive error

Red pulse No internet gateway

White pulse Software update available

Solid red Upgrade mode

Alternate ﬂashing red and green Upgrading…

Flashing blue Mute mode

Solid white Indexing

Solid blue Connected to Network – ready to use with Bluesound App

Flashing red Factory reset in progress

Solid purple Hotspot timed out

5 6 7 8 13 14

109 12 1511

NODE 2i

WIRELES S MUSIC ST REAMER

PLAY/PAUSE BUTTON: This button has multiple functions – a visual indicator of network connectivity and a PLAY

PAUSE button. For a full listing of LED Blink Codes, please see #1 – Blink Codes. For an ungrouped Player, press

the button to Play and Pause the stream. If listening to an internet radio stream, the Pause function will work for 30

seconds. At this point, the buffer is full and the stream will Stop. When a Player is grouped, pressing the PLAY/PAUSE

button will Mute that Player while other Players continue the stream. The Player’s LED will ﬂash blue when muted.

+, - (VOLUME): Toggle either button to vary volume level. Volume level will not change if you press and hold either

button.

(+): Increase volume level

(-): Decrease volume level

PREVIOUS TRACK/NEXT TRACK: These buttons can be used to go back to the previous track or skip to the ◄◄

next track in your current playlist.►►

AUDIO OUT: Connect to the corresponding analog audio input of an amplier, receiver or stereo system.

SUBW (SUBWOOFER) OUT: A Subwoofer can also be connected directly to the NODE 2i. Connect SUBW OUT to a

powered (“active”) subwoofer.

COAX OUT: Using a coax cable (not provided), connect one end to the COAX OUT of the NODE 2i and the other end to

the corresponding coax input of compatible devices such as receivers, computer soundcards or other digital processors.

OPTICAL OUT: Using a Digital Optical cable (not provided), connect one end to the OPTICAL OUT of the NODE 2i and

the other end to the corresponding digital audio input of compatible devices such as receivers, computer soundcards or

other digital processors.

OPTICAL IN/ANALOG IN: Using a 3.5mm Stereo Audio Cable (provided), connect one end to the Analog In of the NODE

2i and the other end to the corresponding analog output of other compatible devices. The source will show as an Analog

Input in the Navigation Drawer of the Bluesound app. Using the 3.5mm Mini Jack to Toslink adaptor (included with the

NODE 2i), a digital optical source can also be added. This will appear as Optical Input in the Navigation Drawer.

TRIGGER OUT: A 12V DC signal is available using TRIGGER OUT. The 12V DC signal can be used to control or activate

other external devices equipped with a corresponding 12V trigger input using a 3.5mm mono audio cable.

IR IN: An infrared extender can be connected to allow for programmable learning remotes to control volume and source

selection when a NODE 2i is stored in a way that the front panel IR sensor is not visible.

LAN PORT: The LAN PORT connection can be used with the Ethernet cable provided. This is an optional connection

since the NODE 2i can be connected to the network through a Wi-Fi connection to your router. To setup the NODE 2i

using the LAN Port a Wired Ethernet connection is required. Using the Ethernet cable provided, connect one end of the

Ethernet cable to the LAN port of your wired Ethernet broadband router and the other end to the NODE 2i’s LAN port.

USB (TYPE A): Connect a USB mass storage device to the USB input. Typical USB mass storage devices compatible

with the NODE 2i include portable ﬂash memory devices and external hard drives (FAT32 formatted).

SERVICE: Use the SERVICE port in conjunction with USB (Type B Mini) to initially load ﬁrmware on the Player. This is

not for consumer use. Only Authorized Bluesound Service personnel can access this USB port and SERVICE control

button.

AC MAINS INPUT: The NODE 2i comes supplied with two separate AC power cords. Select the AC power cord

appropriate for your region. Before connecting the plug to the wall outlet, connect ﬁrmly the other end of the AC power

cord to NODE 2i’s AC Mains input socket. Never force the plug into a wall outlet. An adaptor may be necessary in certain

regions. Always disconnect the plug from the wall outlet ﬁrst, before disconnecting the cable from the NODE 2i’s AC

Mains input socket.

FRONT PANEL HEADPHONE JACK: A 3.5mm headphone jack is located on the front of the NODE 2i.
