Läs nedan 📖 manual på svenska för Bluesound Node Nano (5 sidor) i kategorin Audiostreamer. Denna guide var användbar för 7 personer och betygsatt med 4.5 stjärnor i genomsnitt av 2 användare
Sida 1/5
NODE NANO
WIRELESS MUSIC STREAMER
OWNER’S MANUAL
v. N030
2
Welcome to Bluesound
Thank you for purchasing your NODE NANO. The NODE NANO is designed with a truly high-
performance mindset, focusing on the absolute core functionality of a HiFi streamer.
BluOS
The BluOS multi-room music streaming platform, the world’s leading ecosystem for hi-res streaming
audio, is the backbone of Bluesound product performance. The NODE NANO has music services built
right in, so listening to your favorite artist or playlist is simple. Connect the NODE NANO to any audio
system by using its class-leading analog RCA output or pass the digital signals along with Coax, Optical
or USB. Using the BluOS Controller App, group your NODE NANO with other Bluesound players for
a whole home listening experience, or simply let it do all the work itself to add hi-res streaming to
your stereo. Either way, it’s easier than ever to enjoy the pleasures of hi-res listening – on any existing
amplifier or powered speakers– with the NODE NANO.
This Owner’s Manual will provide you with a more detailed overview of your NODE NANO and its
features. It also includes some troubleshooting tips and tricks and networking best practices. The Quick
Setup Guide included with your NODE NANO will help you get it on the network and ready to listen to
your music.
Included Accessories
Stereo RCA ConnectorUSB Power Adapter
International Plug Adapter
x4
USB-C Power Cable
Ethernet Cable
4
PRESETS The NODE NANO has 2 programmable preset buttons. These are configured using the Presets menu in the
BluOS App.
STATUS INDICATOR Below is a table of the LED blink codes and their corresponding descriptions.
LED BLINK CODE DESCRIPTION
Short blue flash, then red Powering up rebooting the unit
Solid green Hotspot Mode
Flashing green Connecting to Network
White pulse Software update available
Solid red Upgrade Mode
Alternate flashing red and green Upgrading
Flashing blue Mute Mode
Solid white Indexing
Solid blue Connected to Network - ready to use with BluOS App
Flashing red Factory Reset in process
Solid Purple Hotspot Mode timed out
PLAY/PAUSE BUTTON This button has multiple functions – a visual indicator of network connectivity and a PLAY/PAUSE
button. For a full listing of LED Blink Codes, please see #2 – Status Indicator. For an ungrouped Player, press the button to
Play or Pause the stream. If listening to an internet radio stream, the Pause- function will work for 30 seconds. At this point,
the buffer is full and the stream will Stop. When a Player is grouped, pressing the PLAY/PAUSE button will Mute the Player
while other Players continue the stream. The Player’s LED will flash blue when muted. This button is also used for Factory
Rest functions. See steps for Factory Reset later in the manual.
IR RECEIVER The IR receiver is hidden behind the glass.
VOLUME Use the “-“ and “+” buttons to adjust the volume level. Tapping the buttons will adjust the level by 1dB intervals.
AUDIO OUT Connect to the corresponding analog audio input of an amplifier, receiver, stereo system or active speakers.
Connecting via the AUDIO OUT will use the NODE NANO’s internal DAC.
COAX OUT Using a coax cable (not provided), connect one end to the COAX OUT of the NODE NANO and the other end
to the corresponding coax input of a compatible devices such as receivers, digital-to-analog converters or other digital
processors. Connecting via the COAX OUT will bypass the NODE NANO’S internal DAC.
OPTICAL OUT Using a digital optical cable (not provided), connect one end to the OPTICAL OUT of the NODE NANO and
the other end to the corresponding coax input of a compatible devices such as receivers, digital-to-analog converters or
other digital processors. Connecting via the OPTICAL OUT will bypass the NODE NANO’S internal DAC.
LAN PORT The LAN PORT connection can be used with the Ethernet cable provided. This is an optional connection since
the NODE NANO can be connected to the network through a Wi-Fi connection to your router. To setup the NODE NANO
using the LAN Port a Wired Ethernet connection is required. Connect one end of the Ethernet cable to the LAN port of your
wired Ethernet Broadband router and the other end to the NODE NANO’s LAN port.
USB INPUT (TYPE A) Connect a USB mass storage device to the USB input. Typical USB mass storage devices compatible
with the NODE NANO include portable flash memory devices and external hard drives (FAT32 formatted). [Read about
Server Mode in Settings]
USB OUTPUT (TYPE A) The NODE NANO can transfer digital audio (USB Audio 2.0) through to an external DAC via the
USB Type-A slot. Using a USB cable (not provided), connect one end to the USB output of the NODE NANO and the
other end to the corresponding USB input on a separate DAC device. Select your USB DAC from the NODE NANO’s Audio
settings page in the BluOS App to bypass the NODE NANO’s internal DAC via USB audio out. Note: when USB Output is
selected, all other outputs (Analog and Digital) are dormant.
1
2
3
4
5
6
7
8
9
10
11
Produktspecifikationer
| Varumärke: | Bluesound |
| Kategori: | Audiostreamer |
| Modell: | Node Nano |
