Sida 1/11
MODEL • L300KMG
Pa
!
LOSONE SELECT®
VENTILATOR
Ceiling/Wall Mount 120V
READ AND SAVE THESE INSTRUCTIONS
TABLE OF CONTENTS
“TYPICAL INSTALLATION”
“MOUNTING OPTIONS”
“WIRING OPTIONS”
“DUCTING OPTIONS”
“USE AND CARE”
“SERVICE PARTS”
“WARRANTY”
Installer: Leave this manual with
the homeowner.
Homeowner: Use and Care
information on page 3.
Page 1
CAUTION
WARNING
TO REDUCE THE RISK OF FIRE, ELECTRIC SHOCK, OR INJURY
TO PERSONS, OBSERVE THE FOLLOWING:
TO REDUCE THE RISK OF A RANGE TOP GREASE FIRE:
TO REDUCE THE RISK OF INJURY TO PERSONS IN THE EVENT
OF A RANGE TOP GREASE FIRE, OBSERVE THE FOLLOW-
ING:*
MODEL • L300KMG
Page 2
TYPICAL INSTALLATION
MOUNTING (New Frame Construction)
Factory-shipped unit installed in new construction.
MOUNTING (Existing Frame Construction)
Factory-shipped unit installed in existing construction.
TYPICAL INSTALLATION
WIRING
DUCTING (Horizontal blower discharge)
Two ways to connect ductwork to a factory-shipped unit.
Ventilator can be wired from outside of housing.
Use UL approved connectors to wire per local codes.
IMPORTANT:
Remove shipping tape from damper
Remove shipping ring from blower inlet
MODEL • L300KMG
Page 3
12¼"
9
1
/
2
"
to
10
1
/
2
"
12¼"
1½"
to
2½"
MOUNTING OPTIONS
WIRING OPTIONS
DUCTING OPTIONS
12¼"
1
1
/
8
"
MAX.
Mounting brackets in
factory-shipped position.
12¼"
10
3
/
4
"
to
11
3
/
4
"
12¼"
Mounting brackets fl ipped
over and mounted to outlet
sides of housing.
Mounting brackets mounted
to outlet sides of housing.
Mounting brackets fl ipped
over and mounted to top of
sides of housing.
12¼"
1
1
/
2
"
to
2
1
/
2
"
Mounting brackets fl ipped
over to give approx. 1”
more clearance.
Mounting brackets mounted
to top of sides of housing.
BLOWER DISCHARGE POSITIONS
WIRING PLATE
POSITION
Wiring plate mounts to side or top of housing.
Blower and duct connec-
tor in horizontal discharge
position. (Factory shipped)
Blower and duct connec-
tor in vertical discharge
position.
DUCTING (Vertical blower discharge)
Typical ductwork connection to a ventilator converted to
vertical discharge.
WARNING: To reduce the risk of electric shock,
disconnect from power supply before servicing.
To clean grille:
To clean blower assembly:
USE AND CARE
