FDS-318
User Manual
2
This equipment has been tested and found to comply with the following European and
international Standards for Electromagnetic Compatibility and Electrical Safety:
Radiated Emissions (EU): EN55013 (1990) Associated Equipment
RF Immunity (EU): EN50082/1 (1992) RF Immunity, Fast Transients ESD
Mains Disturbance (EU): EN61000/3/2 (1995)
Electrical Safety (EU): EN60065 (1993)
Radiated Emissions (USA): FCC part 15 Class B
Electrical Safety (USA): UL813/ETL (1996) Commercial Audio Equipment
Electrical Safety (CAN): UL813/ETLc (1996) Commercial Audio Equipment
IMPORTANT SAFETY INFORMATION
DO NOT REMOVE COVERS. NO USER SERVICEABLE PARTS INSIDE, REFER SERVICING TO QUALIFIED
SERVICE PERSONNEL. THIS EQUIPMENT MUST BE EARTHED.
IT SHOULD NOT BE NECESSARY TO REMOVE ANY PROTECTIVE EARTH OR SIGNAL CABLE SHIELD
CONNECTIONS TO PREVENT GROUND LOOPS. ANY SUCH DISCONNECTIONS ARE OUTSIDE THE
RECOMMENDED PRACTICE OF BSS AUDIO AND WILL RENDER ANY EMC OR SAFETY CERTIFICATION
VOID.
For continued compliance with international EMC legislation ensure that all input and output cables are wired
with the cable screen connected to Pin 1 of the XLR connectors and/or the jack plug sleeve. The input XLR Pin 1
and the side-chain input jack socket sleeve are connected to the chassis via a low value capacitor, providing
high immunity from ground loops whilst ensuring good EMC performance.
V 2.1 JMK 21st December 1999
Please read
We have written this manual with the aim of helping installers, sound engineers and musicians alike to get the
most out of the FDS-318. We recommend that you read this manual, particularly the section on installation,
before attempting to operate the unit.
The manual is split into two main sections. The first deals with quick reference information, regarding the
functions and operation of the unit, while the second covers a more general background to use and application
of the FDS-318.
We welcome any comments or questions regarding the FDS-318 or other BSS products, and you may contact us
at the address or World Wide Web site given in the warranty section.
3
Contents
Contents
1.0 What is a Crossover? 5
2.0 The difference between Active and
Passive Crossovers 6
3.0 Other advantages 7
4.0 The Linkwitz-Riley advantage 8
5.0 What is special about BSS
Crossovers? 9
6.0 Unpacking 9
7.0 Mechanical Installation 12
8.0 Mains Power Connection 13
8.1 Mains Power 13
8.2 Voltage Setting 13
8.3 AC Power Fusing 14
8.4 Powering up 14
9.0 Audio Connections 15
9.1 Wiring convention 15
9.2 Balanced wiring 15
9.3 Unbalanced wiring 15
9.4 Ground loop control 16
10.0 Controls and connections 17
10.1 Crossover frequency adjustment
control 17
10.2 Output level control 17
10.3 Polarity reverse switch 17
10.4 Mute switch 17
10.5 Signal level indicators 18
10.6 Select mode LED 18
10.7 Rear panel switch LEDs 18
10.8 Mains power fuse 18
10.9 Main power switch 19
