Welcome to the FCS-930/960 Users Manual
Welcome
V2.2 8 December 1995
This Manual is the COPYRIGHT of BSS Audio. All reproduction and copying, other than for the legal
owner's personal use, or disclosure of part or whole to a third party, without prior written authorisa-
tion, is in violation of the European Copyright Convention. BSS Audio 1995
FCS-930 FCS-960
User's Manual
DUAL MODE GRAPHIC EQUALISER
DUAL MODE TWO CHANNEL GRAPHIC EQUALISER
The aim of this manual is to assist sound engineers, installers and
consultants to fully understand the FCS-930/960; and to benefit from its
maximum capability. As opposed to most manuals, the contents can be
read like a book.
At the same time, the information is structured under a series of broad
headings for easy access. So where possible within each section:
. The most immediate information appears at the head of each section
under the main title.
. As you read further into each subsequent section, more
detailed,specific information is given.
Should you have any comments or questions about applying the FCS-
930/960 series within your application, please write to us at the address
in the warranty section.
FCS-960
FCS-930
2
FCS-930/960
This equipment has been tested and found to comply with the
following European Standards for Electromagnetic Compatibility.
Emission Specification EN55013 1990 (Associated equipment)
Immunity Specification EN50082/1 1992 (RF Immunity, Fast
Transients and ESD)
Mains Disturbance EN61000/3/2 1995
For continued compliance ensure that all input and output cables are
wired with cable screen connected to pin 1 of the XLR. The input XLR pin
1 on BSS equipment is generally connected to chassis via a capacitor to
prevent ground loops whilst ensuring good emc compatibility.
3
Table Of Contents
Table Of Contents
1.0 Introduction 4
2.0 Unpacking 5
3.0 Mechanical Installation 6
4.0 Connections 7
4.1 AC Voltage Setting 8
4.2 Safety Earthing 8
4.3 AC Power Fusing 8
4.4 Audio Connections 9
4.5 Ground Loop Control 10
4.6 Powering Up 10
5.0 Control Descriptions 11
5.1 Front Panel 11
5.2 Rear Panel 12
6.0 Using the FCS-930/960 13
7.0 Filter Shapes and Interaction Effects 15
8.0 Appendix 18
8.1 Chassis/0v Link Removal 18
8.2 Transient Suppressor Replacement 18
8.3 Optional Transformer Fitting 19
8.4 Optional Security Cover 19
9.0 Technical Specifications 20
10.0 Warranty 22
User Notes 23
Front Panel Recall Sheet 26
