BG-UHD-VW24
Ultra Video Wall ProcessorHD
Thank you for purchasing -UHD-VW24the BG
Please read the instructions carefully before connecting, operating, or conguring this product.
Please save this manual for future reference.
Surge Protection Recommendation
This contains sensitive components product electrical that may be damaged by electrical
spikes, surges, electric shock, lighting strikes, etc. Use of surge protection systems is highly
recommended to protect and extend the life of your equipment.
Table Contentsof
1. Introduction. ....................................................................................................................
1
2. Features. ...........................................................................................................................
1
3. Package Contents. .........................................................................................................
1
4. Specifications. .................................................................................................................
2
5. Operation Controls and Functions. ...............................................................................
3
6. RS232/LAN Control Connection .....................................................................................
4
6.1 RS232 Connector Connection. ................................................................................
4
6.2 Network Control Connection. ..................................................................................
4
7. PC Tool User Guide. ........................................................................................................
5
8. Safety Instructions. ..........................................................................................................
12
9. Connection Diagram. .....................................................................................................
13
10. Tech Support……………………………………………………………………………………13
11. Warranty…………………………………………………………………………………………14
12. Mission Statement…………………………………………………………………………......14
1
1. Introduction
The - - controller with 2 HDMI inputsBG UHD VW24 is a HDMI 2.0 Video Wall , 2 HDMI loop
out and 4 outputs processing. pin phoenix connector s scaling HDMI video for wall The 5-
provides balanced L/R audio output also . The product features PC Tool or RS232
commands control to the product for different wall displays.
2. Features
☆ HDMI 2.0 and HDCP 2.2 compliant
☆ Supports resolutions video video up to 3840x2160@60Hz output for wall
☆ 2 channels HDMI loop out
☆ Bezel Compensation with two modes
☆ 180 display° rotation
☆ PIP on video wall
☆ RS- 232 and TCP/IP control
☆ CEC control of displays via PC Tool commandsor
3. Package Contents
① 1 x Ultra HD Video Wall Processor
② 1 x 12V/3A Power Adapter
③ 1 x 5- pin Phoenix Connector
④ 2 x 3- pin Phoenix Connector
⑤ 1× RS232 to Phoenix Cable
⑥ CAT6 cable1×
⑦ 1× USB to RS232 Cable
⑧ 1× User Manual
