BG-UHD-VW29
Ultra Video Wall ProcessorHD
Thank you for purchasing the BG-UHD-VW29
Please read the instructions carefully before connecting, operating, or conguring this product.
Please save this manual for future reference.
Surge Protection Recommendation
This contains sensitive components product electrical that may be damaged by electrical
spikes, surges, electric shock, lighting strikes, etc. Use of surge protection systems is highly
recommended to protect and extend the life of your equipment.
Table Contentsof
1. Introduction. ....................................................................................................................
1
2. Features. ...........................................................................................................................
1
3. Package Contents. .........................................................................................................
1
4. Specifications. .................................................................................................................
2
5. Operation Controls and Functions. ...............................................................................
2
6. RS-232/LAN Control Connection. ..................................................................................
4
6.1. - Control Connection. RS 232 ....................................................................................
4
6.2. Network Control Connection. .................................................................................
4
7. PC Tool User Guide. ........................................................................................................
5
8. Safety Instructions. ..........................................................................................................
11
9. Connection Diagram. .....................................................................................................
12
10. Tech Support……………………………………………………………………………………12
11. Warranty…………………………………………………………………………………………13
12. Mission Statement……………………………………………………………………………...13
1
1. Introduction
The BG- -UHD VW29 is an HDMI 2.0 Video Wall controller with 2 HDMI inputs, 2 HDMI loop
outs and 9 HDMI scaling outputs for video wall processing. The 5 pin phoenix connector -
provide 232 bypass feature for s balanced L/R audio output. The product also features an RS-
daisy chain and cascade connections with different units.
2. Features
☆HDMI 2.0 and HDCP 2.2 compliant
☆Supports s resolution up to video for video 3840x2160@60Hz output wall
☆Bezel Compensation with two modes
☆2 channel HDMI loop out
☆PIP on video wall
☆180º display rotation
☆RS- control232 and TCP/IP
☆CEC control for displays via Tool PC or commands
3. Package Contents
①1 x Ultra HD Video Wall Processor
②1 x AC Power Cord
③1 x 5- pin Phoenix Connector
④2 x 3- pin Phoenix Connector
⑤1× RS232 to Phoenix Cable
⑥1× CAT6 cable
⑦1× USB to RS232 Cable
⑧1× User Manual
