4K 1x4 Video Wall Processor
User Manual
BG- -VWP-1X4 UHD
Safety and Notice
The BG UHD- -VWP-1X4 4K 1x4 Video Wall Processor has been tested for conformance to safety
regulations and requirements, and has been certied for international use. However, like all
electronic equipment, the should be used with care. Please read and follow the BG-UHD-VWP-1X4
safety instructions to protect yourself from possible injury and to minimize the risk of damage to the
unit.
● Follow all instructions and warnings marked on this unit.
● Do not attempt to service this unit yourself, except where explained in this manual.
● Provide proper ventilation and air circulation and do not use near water.
● Keep objects that might damage the device and assure that the placement of this unit is on a
stable surface.
● Use only the power adapter and power cords and connection cables designed for this unit.
● Do not use liquid or aerosol cleaners to clean this unit. Always unplug the power to the device
before cleaning.
TABLE OF CONTENTS
INTRODUCTION 1.....................................................................................................................
FEATURES ............................................................................................................................. 1
PACKAGE CONTENTS .......................................................................................................... 1
SPECIFICATIONS .................................................................................................................. 2
HARDWARE INSTALLATION ................................................................................................ 3
CONNECTION DIAGRAM ...................................................................................................... 3
PANEL DESCRIPTIONS ........................................................................................................ 4
SUPPORTED RESOLUTION ................................................................................................. 5
OPERATION APPROACH 6.....................................................................................................
EDID LEARNING .................................................................................................................. 19
WARRANTY .......................................................................................................................... 20
EDID LEARNING .................................................................................................................. 19
WARRANTY .......................................................................................................................... 20
1
INTR UCTI OD ON
The BG UHD- -VWP-1X4 4K 1x4 Video Wall Processor is a powerful, cost eective, and fully real time
data/video processor for multiple at panel displays or projectors. Virtually any setups for the display
layout can be possible by the control software. The BG-UHD-VWP-1X4 allows user to input HDMI/
DisplayPort up to 4K2K@ 4:4:4. And the embedded scaler converts signals from HDMI/ DisplayPort 60Hz
source to match the native resolution of monitors, at panel displays, projectors as well as user-selectable
output settings up to WUXGA (1920x1200). The BG- -VWP-1X4 UHD sends the resulting processed video
thru HDMI interface to the connected monitors/projectors based on the setup display layout. The layout
can be readily modied to t your applications in digital signage, broadcasting, education and surveillance
systems and optimize visual eects.
FEATURES
⚫ Four HDMI outputs from 640x480 to 1920x1200
⚫ Supports HDMI and DisplayPort input from 640x480 to 4K2K@60 (YUV 4:4:4), interlaced or
progressive
⚫ HDCP compliant
⚫ DisplayPort 1.2a & HDMI 2.0a compliant
⚫ Image parameters and layouts are automatically saved in ash memory of the device and can be
recalled for later use
⚫ Several image parameters and layouts can be saved in computers and can be loaded for later use
⚫ Firmware upgradable for new features and technology enhancements
⚫ The video wall processor can control by USB, push button, Ethernet, IR remote control and cloud
control*
⚫ Resize, position, zoom for each HDMI output video
⚫ User-selectable output settings, up to 1920x1200
⚫ Supports remote control to switch 1x1, 2x2, 1x3 rotate, and 1x4 rotate mode
⚫ Supports independent input rotation at the resolution up to 1080p
⚫ 4K2K60 (YUV 4:4:4) can be divided and displayed onto four 1080p60 TV (2x2 layout only)
⚫ Supports individual propagation delay on each display to have the best visual perception
PACKAGE CONTENTS
⚫ 1x - -VWP-1X4 BG UHD
⚫ 1x User Manual
⚫ 1x 1U rack-mounting ear set
⚫ 1x 12V power supply
⚫ 1x Installation software CD
⚫ 1x IR Remote control (15 keys)
*Cloud support is thru an encrypted communication to provide the best private protection when
using BG-UHD-VWP-1X4
