Café™ 1.7 Cu. Ft. Convection Over-the-Range
Microwave Oven with Air Fry
CVM517P4RW2 / CVM517P3RD1 / CVM517P2RS1
CVM517P3RD1
Matte Black
with Brushed
Stainless handle
CVM517P2RS1
Stainless Steel
with Brushed
Stainless handle
FEATURES & BENEFITS
Air Fry - Make your favorite “fried” foods healthy, thanks to a mode that
crisps without using oil for frying
Create a streamlined cooking experience - Simplify your cooking steps
by using Chef Connect to automatically activate vents and surface lights
when a range element is turned on, as well as sync your microwave and
range clocks
A simple and smart addition to your culinary repertoire - Fresh vegetables
and rice are perfectly prepared with a steam cook button that simplifies
the entire process
Say goodbye to guesswork - Enjoy consistently delicious results with
sensor cooking controls that automatically adjust the time and power
Delicious results in no time at all - Enjoy oven-quality results in mere
minutes with a fast cook setting that combines convection and microwave
cooking technology
A microwave that’s as versatile as you are - Achieve crisp, golden brown
results with a convection cooking setting and a special rack that allows air
to circulate around foods for even heat distribution
Brighten up the room - Illuminate the entire cooking surface with crisp, clear
LED cooktop lighting that can also save on energy costs
Sparkling clean with just a wipe - Focus on the food and forget the mess
knowing that the stainless steel interior with steam clean lets you swiftly
wipe away spills and splatters
Like a breath of fresh air - Keep your kitchen ready for guests with a
three-speed, 300-CFM venting system that removes smoke, grease,
odors and moisture
A subtle reminder for filter replacement - Keep your kitchen smelling fresh
and clean with an upfront charcoal filter with indicator light that lets you
know when the filter needs to be replaced
Cook more at once - Prepare plenty of food with full-width removable
oven rack that allow for multi-level cooking at the same time
Cook your way with just one touch of a button - Enjoy the convenience
of one-touch cooking with My Cycle, a custom cycle that remembers the
exact time and temperature settings of your favorite foods
FEATURES
Control Type
Glass Touch
Dial
Display On/O Yes
Electronic Digital Display with Clock Yes (LED)
Cooking Modes
Microwave
Air Fry
Convection Bake
Fast Cook
Cooking Technology Convection
Style Over-The-Range
Cooktop Lighting LED; High/Low/O
Exhaust Fan 3-Speed; 300-CFM
Interior Oven Light Halogen
Power Levels 10
Rack Type
1 Square Rack
1 Round Rack
2 Fixed Positions
Turntable Glass
Turntable On / O Yes
Turntable Size 13.6 in
Convection Cooking Controls
Bake
Roast
Fast Cook
Microwave Sensor Cooking Controls
Popcorn
Reheat
Cook (5 Foods)
Beverage
Steam Cook
Defrost: Weight/Time
Control Features
Start/Pause
Cancel/O
Power Level; Add 30 Sec
Cook Time
Steam Clean
Air Fry
Chef Connect On/O
Timer On/O
Turntable On/O
Mute On/O
Settings
Vent Fan
Surface Light; My Cycle
Microwave Oven Interior Stainless Steel
Microwave Watts (IEC-705) 950W
CAPACITY
Total Capacity (cubic feet) 1.7 cu ft
Vent CFM 300
Exhaust Capacity 300 cu ft/min
ECONOMICAL/QUIET
Venting Type Externally Vented
TECHNICAL DETAILS
Electrical Input - 120V Watts 1700
Input Volts/Hertz 120/60
ACCESSORIES
Optional Side Filler Panel Kit JX36BSS/BDS
Recirculating Charcoal Filter Kit WB02X35607 (included)
WEIGHTS & DIMENSIONS
Approximate Shipping Weight 81.3 lb
Cabinet Width 30 in
Cavity (W x H x D) 21-5/8” x 9-3/4” x 14-1/4”
Net Weight 72.8 lb
Overall Depth 15-9/16 in, 17-15/16 in (including handle)
Overall Height 16-5/16 in
Overall Width 29-7/8 in
ALSO
AVAILABLE IN
Café
™
1.7 Cu. Ft. Convection Over-the-Range
Microwave Oven with Air Fry
CVM517P4RW2 / CVM517P3RD1 / CVM517P2RS1
DIMENSIONS AND INSTALLATION INFORMATION (IN INCHES)
For answers to your Café™ product questions, visit our website at cafeappliances.com.
Note: Requires 120V grounded outlet. Electrical receptacle must be located in
cabinet above microwave oven. No additional wiring, venting or cabinet rebuilding
necessary in many cases. Complete detailed, easy-to-follow installation instructions
and convenient full-size templates are packed with the microwave oven.
Important Information: When installing the microwave oven over a range, allow
minimum of 2" from bottom of microwave oven to top of range backguard to
allow for removal of light covers.
Ventilation Options: The microwave ovens are designed for adaptation to
the following three types of ventilation:
-Outside exhaust (vertical – as shown)
-Outside exhaust (horizontal)
-Recirculating (non-vented ductless – see Filter Kit drawing)
Installation Information: This information is not intended to be used for installing
unit described. Before installing, consult installation instructions packed with
product/kit for current dimensional data.
Hood Exhaust Duct: Outside ventilation requires a HOOD EXHAUST DUCT.
Read the following carefully.
Exhaust Connection: The hood exhaust has been designed to mate with a
standard 3-1/4" x 10" rectangular duct. If a round duct is required, a rectangular-
to-round transition adaptor must be used. Do not use less than a 6" diameter duct.
Rear Exhaust: If a rear or horizontal exhaust is to be used, care should be taken to
align exhaust with space between studs, or wall should be prepared at the time it is
constructed by leaving enough space between the wall studs to accommodate exhaust.
Maximum Duct Length: For satisfactory air movement, the total duct length of 3-1/4" x 10"
rectangular or 6" diameter round duct should not exceed 140 equivalent feet.
Elbows, Transitions, Wall and Roof Caps, etc., present additional resistance to airflow
and are equivalent to a section of straight duct which is longer than their actual physical
size. When calculating the total duct length, add the equivalent length of all transitions
and adaptors plus the lengths of all straight duct sections. The chart below shows the
approximate feet of equivalent length of some typical ducts.
98°
Door open
(without obstruction)
25-1/16"
29-7/8"
13"
MAX.
12"
MIN.*
66" MIN.
Mounting
height from
floor
Minimum distance from
door hinge side to
adjacent wall should
equal 1/2"
30" MIN.
width
required Exhaust outlet
connects to
3-1/4"x 10" duct
*Maximum depth
with JX15
Bump Out Kit is 16"
Bump Out Kit
sold separately.
15-11/16"
(rear)
15-9/16"
16-5/16"
Filler Panel Kits JX36BSS/BDS
When replacing a 36" range hood, this kit fills in the additional width to provide a custom built-in
appearance. For installation between cabinets only; not for end-of-cabinet installation. Each kit
contains two 3"-wide filler panels. This is included, not optional accessory at additional cost.
DUCT EQUIVALENT FEET
A. Rectangular-To-round
Transition Adaptor 5 ft.
B. Wall Cap 40 ft.
C. 90° Elbow 10 ft.
D. 45° Elbow 5 ft.
E. 90° Elbow 25 ft.
F. 45° Elbow 5 ft.
G. Roof Cap 24 ft.
OPTIONAL ACCESSORIES
(AVAILABLE AT ADDITIONAL COST)
CXOTRHKPMBZ
Brushed Bronze
1 handle
(Standard on Matte White)
CXOTRHKPMCU
Brushed Copper
1 handle
CXOTRHKPMBT
Brushed Black
1 handle
CXOTRHKPMSS
Brushed Stainless
1 handle
(Standard on Matte Black & Stainless)
ADDITIONAL ACCESSORIES
WARRANTY
Parts warranty
Limited 1-year entire appliance
Limited 5-Year Magnetron
Labor warranty Limited 1-year entire appliance
Warranty notes See written warranty for full details
CXOTRHKPMCG
Brushed Brass
1 handle
CXOTRHKPMFB
Flat Black
1 handle
© 2022 GE Appliances 8/22
