Sida 1/2
Transmitter Receiver
CAT6 60m
HDMI Display
Macbook
 

RJ45 signal output
Type-C signal input Connect with the source device
Connect with CAT6/6A/7 network


CHE-UHDC60K
The Pro's Connectivity Since 1974 ®
Pro AV/IT Integrator Series™ 4K 60Hz USB-C to HDMI Extender Kit

Comprehensive’s CHE-UHDC60K is a USB-C to HDMI extender with a

4K @60Hz video signals from a source to a display which can be remotely




extension for modern day USB-C devices such as mobile devices, tablets,
laptops, and notebooks that support DP Alt mode or Thunderbolt™ 3 and 4





• 4K @60Hz AV transmission

• Supports DP Alt Mode
• Zero latency AV transmission



• 3 Year Warranty





3) Using the micro-USB cable to power on the receiver, plug into a power
brick or use an extra USB port located behind your display, the extender

23
C o n n e c t i v i t y C o m p a n y

sales@comprehensiveco.com l 800.526.0242 l www.ComprehensiveCo.com
The Pro's Connectivity Since 1974
C o n n e c t i v i t y C o m p a n y

① ②
③

4
①
Power input
HDMI signal output Connect with the display device
Connect to the USB port with the Micro USB cable.
In case of unstable transmission, connect the Micro
USB cable to the DC5V power adapter
③
RJ45 signal input Connect with CAT6/6A/7 network
②
I/O Conn ctions
Transmitter (Local)
Inputs:
1x USB [Type-C male cable]
Outputs:
1x CAT OUT [RJ45, -pin female]8
Receiver (Remote)
Inputs:
1x CAT OUT [RJ45, -pin female]8
1x Power Port [Micro USB female]
Outputs:
1x HDMI Type A [19-pin female]
T chnica 
HDMI Compliance
HDMI v2 0.
HDCP Compliance
HDCP v2 2.
Video Bandwidth
1 Gbps8
Max Transmission Distance
Up to 196ft Cat6/6A/7
Max Transmission Resolution
4K @60Hz 4:4:4
End-To-End Latency
Zero
Audio Formats
PCM, DTS, Dolby
HDR10
Supported
EDID Pass-Through
Supported
Scaler Function
Automatic Downscaling
Pow r & u atory  
Power Input
DC 5V 500mA (Rx only)
Power Consumption
Tx <3W, <3W
ESD Protection
Human body model:
± kV (Air-gap discharge)8
±4kV (Contact discharge)
Regulatory
FCC (Class B), CE (Class B), RoHS2 Compliant
Prop 65 Compliant
No
Chassis and En ironm nta  
Construction
Metal
Color
Black
Dimensions (W*H*D)
67 (W) x 21.25 (H) x 38 (D) mm
Operating Temperature
-20°C to 55°C
Storage Temperature
-30°C to 60°C (+14°F to +140°F)
Humidity
0% to 90% Relative Humidity
Shipping weight
4 lbs.
Packa Cont nts 
What is in the box
1x CHE-UHDC60K Extender Kit (Transmitter &
Receiver)
1x Power Adapter (5V DC 500mA)
4x Mounting Ears
8x Screws
1x User Manual
Oth r
Diagnostic Indicators
Power and Status
UPC
8 8 80 4470 5969
Product Part umberN
CHE-UHDC60K
Warranty
3 years
