Sida 1/2

● DesignDiseño ergonómico de bordes curvos y esquinas redondeadas.

● Wing Ala lateral doble: RGB efectos de retroiluminación.

● Soporte para conexiones de placa madre de 5V RGB (ASUS, ASRock, Gigabyte o MSI).

● USB pass-through p1-x2 y conectores de audio.

● DesignDiseño de textura de fibra de carbono.

● Frame Bastidor de acero soldado de alta resistencia para una máxima estabilidad.

ESPAÑOL

● Edges Design de bordas curvas ergonómicas e cantos arredondados.

● SideA asa lateral dupla: RGB efeitos de luz de fundo.

● Suporte para conexões de placa-mãe de 5V RGB (ASUS, ASRock, Gigabyte ou MSI).

● USB pass-through p1-x2 e tomadas de áudio.

● DesignDesign de textura de fibra de carbono.

● Estrutura de aço soldada de alta resistência para máxima estabilidade.

PORTUGUÊS

● Design ergonomico dei bordi curvi e angoli arrotondati.

● Ala laterale doppia: RGB effetti di retroilluminazione.

● Supporto per connessioni della scheda madre RGB 5V (ASUS, ASRock, Gigabyte o MSI).

● USB pass-through p1-x2 e prese audio.

● Design della trama in fibra di carbonio.

● Telaio in acciaio saldato ad alta resistenza per la massima stabilità.

ITALIANO

● Ergonomic curved edges design and rounded corners.

● Dual side wing: RGB backlight effects.

● Support for 5V RGB motherboard connections (ASUS,ASRock,Gigabyte or MSI).

● USB pass-through p1-x2 & Audio Jacks.

● Carbon fiber texture design.

● High-strength welded steel frame for maximum stability.

ENGLISH

год и месяц изготовления продукции указаны в серийном номере продукта.

(существует 2 способа определения даты изготовления, оба способа описаны ниже)

После S/N: первые две цифры означают год, вторые две – месяц изготовления.

Например, S/N: H 000001 означает, что товар был произведен в феврале 2017 года.1702

После S/N: если указаны буквы, то две буквы представляют цифры из таблицы ниже,

и означают год, последующие две цифры – месяц изготовления.

Например, S/N: D REVI000001 означает, что товар был произведен в феврале 2017 года.AG02

ДАТА ИЗГОТОВЛЕНИЯ ПРОДУКЦИИ

● Например, AG = 17 = 2017 год

A B C D E F G H I J

1 2 3 4 5 6 8 9 07

Desk Dimension

Desk Height

I/O Panel

Model No.

Product Name COUGAR MARS 120 Gaming Desk

CGR-MARS 120

125 (W) x 74 (D) mm / 49.2 (W) x 29.1 (D) inch

81 (H) cm / 31.9 (H) inch

USB 3.0 x 1 / USB 2.0 x 1 / Audio Jacks x 2 / RGB button

БЪЛГАРИЯ

• Подробни инструкции за употреба изтеглете от: https://cougargaming.com/bg България QR код

COUGAR MARS 120 gaming desk provides ergonomic design with dazzling

RGB lighting effects for enhancing your superior gaming experiences.

It’s how we make your gaming dreams come true and present a unique gaming

desk for you!

● 更舒适的人体工学造型桌面设计

● 可调控式RGB侧翼灯效设计

● 支持主机板RGB灯效同步功能 (ASUS,ASRock,Gigabyte 或 MSI)

● 桌面具有USB/Audio接口设计

● 类碳纤维表面防刮处理

● 高强度与高耐用度钢制桌脚设计

中文

WARRANTY PERIODS OF COUGAR GAMING DEVICES

Product : COUGAR MARS 120

Warranty : 1 Year

This warranty gives you specific legal rights. You may also have other rights granted under local law. These rights may vary.

x12

Make sure the 12 screws are positioned

and then lock solidly truly.

Please make sure the side is right

while mounting Part C

12 Screws

When the control stands are uneven on the gaming desk,

they will be automatically corrected when locking the screws.

To avoid the screw bosses are damaged,please do not lock

the screws too tight.

DISCLAIMERS

● COUGAR products should not be used as critical components in life support devices.

● COUGAR is not liable for any damage of life and limb or damage or loss of property caused by or during

COUGAR products’ use as or with medical equipment, military equipment, traffic equipment and disaster

prevention systems.

● COUGAR's warranty liability is limited to repair or replacement. The decision on whether to repair

or replace belongs exclusively to COUGAR.

● COUGAR is, to the extent not prohibited by law, not liable for any damages; expenses; lost data,

revenues, savings or profits; or any incidental or consequential damages happened while the use

of a defective product from COUGAR or due to its use.

WARRANTY AGREEMENT

● If the product has defects in material or manufacture, COUGAR will provide product repair and

replacement service within the warranty period.

● Our warranty service is based on the date of the invoice or warranty card.

CONDITIONS WHERE FREE MAINTENANCE IS NOT PROVIDED

● Any fault or damage caused by natural disasters (including storm, fire, flood, thunder, earthquake, etc).

● Any fault or damage caused by accidental factors and man-made reasons (including hit, scrape, crash,

moving, compression, stain, corrosion, riot, misuse, malicious damage, etc).

● Use in an improper operating environment (including high temperature, high humidity, water inflow, etc).

● Inability to provide the product warranty card, purchase receipt or invoice to prove the product is still

within the warranty period and the shipping date of the product is out of warranty.

● The warranty card has been altered or its number is hard to identify.

● The warranty period has expired.

● Any fault or damage caused by non-compliance with regulations stated on the user manual or improper,

rough and careless treatment.

● Any fault or damage caused by use of parts not certified by COUGAR original manufacturer.

● The problem is caused by improper repair or adjustment by the buyer or any manufacturer without

authorization from COUGAR.

● The product is not acquired from an authorized distributor of the company or is acquired from illicit sources.

● Paper carton, instruction and other accessories are not warranted.

facebook.com/cougargaming

youtube.com/user/COUGARGLOBAL

Side wing connector RGB connector

Left wing RGB connector

Controller connector

USB 2.0

Power supply

USB 3.0

Right wing RGB connector

nnector

Mic connector

Spk connector

Controller Function

Mars Gaming Desk Connector

Connecting Controller to PC

DISTRIBUTOR

Expand other devices

5V Addressable RGB Header:

for Compatible ASUS, MSI ,

Gigabyte or ASRock Motherboards

STEP .1 STEP .2 STEP .3

Default : RGB Button Switch Mode

Flow >Swift >Breathing >Red >Orange >Light orange > Yellow >Green >

Yellow-green >Sky-blue >Purple >Fuchsia >Pink >White >Lighting OffBlue >

Press and hold the RGB button for three seconds inth Motherboard Driver RGB Control mode, and the RGB button’s LED

will be turn off.

If you need to return to defalt mode, just press the RGB button for one second.

Default: Control by RGB button

Motherboard Driver RGB Control

Press the RGB button for

one second

Press and hold the RGB button for

three seconds

RGB button Audio Jacks USB 2.0 USB 3.0

This manual was created by Compucase Enterprise and may not be completely or partially

copied, passed on, distributed or stored without written consent by Compucase Enterprise.

COUGAR® is a registered brand of Compucase Enterprise Other product and company names

mentioned in this documentation may be brands or trademarks of their respective owners.

Compucase Enterprise reserves the right to make changes concerning the contents of the

manual and the technical data of the product without previous announcement.

Compucase Enterprise Co.,Ltd.

No. 225, Lane 54, An Ho Road Sec. 2 Tainan, Taiwan, R.O.C

Tel:+886-6-356-0606

COUGAR USA Technical Service

Tel: (833) 256-3778

Mail: rma@compucaseusa.com

Service email : https://cougargaming.com/support/contact/upload/

●

Please wear protective gloves when assembling the Desk. It is your own responsibility to use

appropriate protection to prevent any physical damage.

●

Do not use abrasive products or scrub energetically when cleaning. Please stick to gentle products

suitable for delicate materials.

●

All parts should be checked monthly to conﬁrm their integrity and to make sure that the screws

are not loose.

●

If any part of the product is or appears to be damaged, missing or loose, please contact the local

distributor and do not use the product. WARNING
