FOLLOWED BY COUGAR MARS, COUGAR MARS PRO 150 STANDS ON THE SHOULDERS OF GIANTS.

NOT ONLY MARS PRO 150 RETAINS FEATURES OF MARS BUT EVOLVES WITH MUCH MORE HANDY

FUNCTIONS, SUCH AS A USB-C PORT FOR DATA TRANSFERS AND HDMI MONITOR EXTENSION.

IT’S NOT JUST A GAMING DESK, IT’S THE DESK HOW IT MAKES YOUR DREAM COME TRUE.

ADVANCED AND HIGH-SPEED LINKS

With a control unit, you can easily extend USB-C, USB 3.0, and audio devices conveniently.

By HDMI extension through Type-c connector, you can have the extra monitor to maximize your work.

It is extremely helpful for streamers or content creators.

ENORMOUS AND ERGONOMIC GAMING SPACE

The spacious gaming surface up to 150cm width with carbon fiber texture brings you plenty of space for your

gaming monitors, gaming keyboards, and other gaming gears. Highly ergonomic designs like curved edges

and rounded corners give you a better and more comfortable gaming experience.

DUAL-SIDED RGB LIGHTING EFFECTS

To increase more immersive feeling in your gaming atmosphere. Mars Pro 150 provides various RGB lighting

effects. It is also compatible with motherboards’ 5V connection with Asus Aura Sync, Gigabyte RGB Fusion,

MSI Mystic Light Sync, and ASRock Polychrome Sync for system-wide lighting synchronization.

HIGH-STRENGTH WELDED STEEL FRAME FOR MAXIMUM STABILITY

COUGAR Mars Pro 150 is made of high-strength steel frame for ulitmate stability. The height of the gaming

desk is manually adjustable between three levels (750/800/850mm) for the most comfortable position.

•Extensión de monitor HDMI mediante cable tipo C, puertos USB-C,conexión de paso de dos puertos

USB 3.0, conector de audio de 3,5 mm.

•DesignDiseño ergonómico de bordes curvos y esquinas redondeadas.

•Wing Ala lateral doble: RGB efectos de retroiluminación.

•Soporte para conexiones de placa madre de 5V RGB(ASUS, ASRock, Gigabyte o MSI).

•Adjustment Ajuste de altura de la mesa (75/80 / 85CM).

•DesignDiseño de textura de fibra de carbono.

•Frame Bastidor de acero soldado de alta resistencia para una máxima estabilidad.

ESPAÑOL

•Extensão de monitor HDMI via cabo Tipo C, portas USB-C, conexão de passagem de

duas portas USB 3.0, conector de áudio de 3,5 mm.

•Edges Design de bordas curvas ergonómicas e cantos arredondados.

•SideA asa lateral dupla: RGB efeitos de luz de fundo.

•Suporte para conexões de placa-mãe de 5V RGB (ASUS, ASRock, Gigabyte ou MSI).

•Adjustment Ajuste de altura do desktop (75/80 / 85CM).

•DesignDesign de textura de fibra de carbono.

•Estrutura de aço soldada de alta resistência para máxima estabilidade.

PORTUGUÊS

•Estensione monitor HDMI tramite cavo Type-C, porte USB-C,

connessione pass-through per due porte USB 3.0, jack audio da 3,5 mm.

•Design ergonomico dei bordi curvi e angoli arrotondati.

•Ala laterale doppia: RGB effetti di retroilluminazione.

•Supporto per connessioni della scheda madre RGB 5V(ASUS, ASRock, Gigabyte o MSI).

•Regolazione altezza del frontalino (75/80 / 85CM).

•Design della trama in fibra di carbonio.

•Telaio in acciaio saldato ad alta resistenza per la massima stabilità.

ITALIANO

•HDMI monitor extension via Type-C cable, USB-C ports,

two USB 3.0 ports pass-through connection, 3.5mm audio jack.

•Ergonomic curved edges design and rounded corners.

•Dual side wing: RGB backlight effects.

•Support for 5V RGB motherboard connections(ASUS,ASRock,Gigabyte or MSI).

•Desktop height adjustment (75/80/85CM).

•Carbon fiber texture design.

•High-strength welded steel frame for maximum stability.

ENGLISH

• Height Adjustment:

MARS gaming desk has three adjustment options: 75cm – 80cm – 85cm

(desktop to ground).

To strengthen the stability, please fasten TWO screws on each side.

80cm 85cm

75cm

• Please follow this step to assemble two sets.

год и месяц изготовления продукции указаны в серийном номере продукта.

(существует 2 способа определения даты изготовления, оба способа описаны ниже)

После S/N: первые две цифры означают год, вторые две – месяц изготовления.

Например, S/N: H 000001 означает, что товар был произведен в феврале 2017 года.1702

После S/N: если указаны буквы, то две буквы представляют цифры из таблицы ниже,

и означают год, последующие две цифры – месяц изготовления.

Например, S/N: D REVI000001 означает, что товар был произведен в феврале 2017 года.AG02

ДАТА ИЗГОТОВЛЕНИЯ ПРОДУКЦИИ

● Например, AG = 17 = 2017 год

A B C D E F G H I J

1 3 4 5 6 7 8 9 02

Position and do not tighten

the screws.

Position and do not tighten

the screws.

When the control stands are uneven on the gaming desk,

they will be automatically corrected when locking the screws.

To avoid the screw bosses are damaged,please do not lock

the screws too tight.

Make sure the 16 screws are positioned

and then lock solidly truly.

!x4

16 Screws

x4x8

Desk Dimension

Desk Height

I/O Panel

Model No.

Product Name COUGAR MARS Pro 150 Gaming Desk

CGR-MARS PRO 150

153.3 (W) x 77.1 (D) mm / 60.4 (W) x 30.4 (D) inch

Three Height Options : 75 / 80 / 85 (H) cm ; 29.5 / 31.5 / 33.5 (H) inch

LED Switch / USB-C p1-x1 / USB 3.0 p1-x2 / Audio Jack p1-x2 /

HDMI Monitor Extension Via Type-c cable

БЪЛГАРИЯ

• Подробни инструкции за употреба изтеглете от: https://cougargaming.com/bg България QR код

Spare parts : x 2/

x44

While adjusting the height of the desk, please lower

your head and body and clear the desk in case of a

sudden drop of the desktop.

Exclusive Monitor Extension Cable

DISCLAIMERS

● COUGAR products should not be used as critical components in life support devices.

● COUGAR is not liable for any damage of life and limb or damage or loss of property caused by or during

COUGAR products’ use as or with medical equipment, military equipment, traffic equipment and disaster

prevention systems.

● COUGAR's warranty liability is limited to repair or replacement. The decision on whether to repair

or replace belongs exclusively to COUGAR.

● COUGAR is, to the extent not prohibited by law, not liable for any damages; expenses; lost data,

revenues, savings or profits; or any incidental or consequential damages happened while the use

of a defective product from COUGAR or due to its use.

WARRANTY AGREEMENT

● If the product has defects in material or manufacture, COUGAR will provide product repair and

replacement service within the warranty period.

● Our warranty service is based on the date of the invoice or warranty card.

WARRANTY PERIODS OF COUGAR GAMING DEVICES

Product : COUGAR MARS PRO 150 GAMING DESK

Warranty : 1 Year

This warranty gives you specific legal rights. You may also have other rights granted under local law.

These rights may vary.

CONDITIONS WHERE FREE MAINTENANCE IS NOT PROVIDED

●

Any fault or damage caused by natural disasters (including storm, fire, flood, thunder, earthquake, etc).

●

Any fault or damage caused by accidental factors and man-made reasons (including hit, scrape, crash,

moving, compression, stain, corrosion, riot, misuse, malicious damage, etc).

●

Use in an improper operating environment (including high temperature, high humidity, water inflow, etc).

●

Inability to provide the product warranty card, purchase receipt or invoice to prove the product is still

within the warranty period and the shipping date of the product is out of warranty.

●

The warranty card has been altered or its number is hard to identify.

●

The warranty period has expired.

●

Any fault or damage caused by non-compliance with regulations stated on the user manual or improper,

rough and careless treatment.

●

Any fault or damage caused by use of parts not certified by COUGAR original manufacturer.

●

The problem is caused by improper repair or adjustment by the buyer or any manufacturer without

authorization from COUGAR.

●

The product is not acquired from an authorized distributor of the company or is acquired from illicit sources.

●

Paper carton, instruction and other accessories are not warranted.

This manual was created by Compucase Enterprise and may not be completely or partially

copied, passed on, distributed or stored without written consent by Compucase Enterprise.

COUGAR® is a registered brand of Compucase Enterprise Other product and company names

mentioned in this documentation may be brands or trademarks of their respective owners.

Compucase Enterprise reserves the right to make changes concerning the contents of the

manual and the technical data of the product without previous announcement.

Compucase Enterprise Co.,Ltd.

No. 225, Lane 54, An Ho Road Sec. 2 Tainan, Taiwan, R.O.C

Tel:+886-6-356-0606

COUGAR USA Technical Service

Tel: (833) 256-3778

Mail: rma@compucaseusa.com

Service email : https://cougargaming.com/support/contact/upload/

● Please wear protective gloves when assembling the Desk. It is your own responsibility to use

appropriate protection to prevent any physical damage.

● Do not use abrasive products or scrub energetically when cleaning. Please stick to gentle products

suitable for delicate materials.

● All parts should be checked monthly to conﬁrm their integrity and to make sure that the screws

are not loose.

● If any part of the product is or appears to be damaged, missing or loose, please contact the local

distributor and do not use the product. WARNING

facebook.com/cougargaming

youtube.com/user/COUGARGLOBAL

Right wing RGB connector

Mic connector

Speaker Connector

USB 3.0

Audio Extension to PC

USB 3.0 Extension to PC USB 3.1 TYPE-C Extension to PC

Connecting Monitor Extension Cable to Notebook

Controller connector to PC

Screwed on the back panel of PC

Connect the USB for RGB wing power

Expand

other devices

5V Addressable RGB Header:

for Compatible ASUS, MSI ,

Gigabyte or ASRock Motherboards

STEP .1

STEP .2

Mars Pro 150 Gaming Desk I/O

Left wing RGB connector

Side wing connector

Connecteur d'aile latérale

Male ConnectorFemale

RGB connector

Connecteur RGB

Right wing RGB connector

Controller

Connecting dual side wing to controller

Left wing RGB

connector

Controller connector

RGB switch button

iMonitor extension

USB Power for Left

& Right RGB Wings

USB 3.1

TYPE-C

Exclusive Monitor Extension Cable

Notebook

Monitor

HDMI

Monitor Extension

HOW TO SYNCHRONIZE BETWEEN RGB CONTROL MODES

Press and hold the RGB button for 3 seconds to Motherboard Driver RGB Control

mode, and the RGB button’s LED will be turned off. Adjust LED options from the

software of Motherboard and the synchronization will start.

If you need to return to default mode, just press the RGB button for 1 second.
