Sida 1/5
CFD-15KL Tailgate Handle Camera CFD-15KM Tailgate Handle Camera with
Moving Parking Lines
RFM-FD8
Multi View Integration Interface with
Side Mirror Mounted Cameras for Ford F-150 with 8” Sync 3 Screen
R
INTERFACING SOLUTIONS
Sightline
Multi View Integration
- Adds front, le & right camera inputs plus 4 more video inputs on vehicle with factory installed backup camera.
- Uses the steering wheel control buons to toggle between the sources.
- Turn signals automacally trigger the corresponding side camera.
- Turn signal camera trigger can be turned on or o by using the SWC buon.
PRODUCT FEATURES:
PARTS INCLUDED:
RFM-FD8 Module CSV-FD-15 F150 Side Mirror CameraRFM-FD8 Harness
OPTIONAL ADD-ON CAMERAS:
Oponal add on cameras are available to complete the mul-view capability of the RFM-FD8. Cameras available
and sold separately include: (More cameras can be found at www.cruxinterfacing.com)
CFF-01 Bullet Type Front Camera
(Recommended)
CFF-02 Square Body Front Camera CFF-03 Grille Mount Front Camera
Crux Interfacing Solutions • Chatsworth, CA 91311
phone: (818) 609-9299 • fax: (818) 996-8188 • www.cruxinterfacing.com
1 of 5 rev.12032021
INSTALLATION DIAGRAM:
R
INTERFACING SOLUTIONS
Sightline
Multi View Integration
DIP SWITCH SETTINGS:
DIP# ON OFF
1No Funcon – Leave OFF
2Front Camera ON Front Camera OFF
3 Le Camera ON Le Camera OFF
4Right Camera ON Right Camera OFF
5 Cargo Camera ON Cargo Camera OFF
6 Trailer Camera ON Trailer Camera OFF
7 Camera #7 ON Camera #7 OFF
8Set to ON
RFM-FD8
Multi View Integration Interface with
Side Mirror Mounted Cameras for Ford F-150 with 8” Sync 3 Screen
Front Camera Input
Right Camera Input
Left Camera Input
Cargo Camera Input
Aftermarket Backup Camera Input
Trailer Camera Input
Camera #7 Input
Front and Rear Camera Power Output +12V (purple/white)
Left and Right Camera Power Output +12V (green/white)
Cargo and Trailer Camera Power Output +12V (orange/white)
Camera #7 Power Output +12V (red/white)
Right Turn Signal Input (grey/red)
Left Turn Signal Iput (pink/black)
To Vehicle Harness
Connect this 6-pin plug if OEM
backup camera is being used
To factory screen
Crux Interfacing Solutions • Chatsworth, CA 91311
phone: (818) 609-9299 • fax: (818) 996-8188 • www.cruxinterfacing.com
2 of 5 rev.12032021
R
INTERFACING SOLUTIONS
Sightline
Multi View Integration
OPERATION:
RFM-FD8
Multi View Integration Interface with
Side Mirror Mounted Cameras for Ford F-150 with 8” Sync 3 Screen
1. Remove the felt liner inside the door pull and remove
the screw.
2. Remove the door unlock handle cover and remove the
screw.
3. Use a plasc pry bar to remove the window sail. Remove
the trim panel clips
4. Unhook the door panel by pulling it upward. Unplug
the speaker and doorlock harness.
5. Use a ne hooked pick tool to remove the OEM side
mirror cover. Fish the camera cable through the hole.
6. Tuck in the camera cable inside the cavity and snap in
the CSV-FD15 side mirror cover with camera.
Sample Side Mirror Mounted Camera Installaon:
Crux Interfacing Solutions • Chatsworth, CA 91311
phone: (818) 609-9299 • fax: (818) 996-8188 • www.cruxinterfacing.com
3 of 5 rev.12032021
