MERCEDES BENZ
2013 - Up B-class (W246)
2012 - Up C-class (W204)
2012 - Up C-class (C204)
Late 2014 CLA 250
2012 - Up CLS (C218)
2012 - Up E-class (W212)
2012 - Up E-class (C207)
2014 - Up GLA (X156)
2011 - Up GLK (W204)
2012 - Up ML (W166)
2012 - Up SLK (R172)
2013 - Up SL (R231)
With OE type parking Dynamic Guide Lines
On-screen display and setup
2 trigger outputs (+12V max. 1A), separately adjustable switching events (CAN, ACC rear-view camera, ,
reverse gear)
Rear-view camera input
Front camera input
Front camera input can also be used as an Auxiliary Video Input (Crux part# AUX- , OBD2 Audio Aux MB1
coding, may be required to cre Auxiliary Audio Input).( Sold separately) ate an
Automac switching to rear-view camera input on engagement of reverse gear from all operaon modes
Forced rear-view camera opon
Manual return from rear-view and front camera (cancellaon of automac switching)
Compable with all factory video accessories (e.g. rear-view camera, -changer, TV-tuner) DVD
Plug & Play installaon
6” / 7“ monitor and 4pin HSD LVDS connector
COMAND Online NTG4.5, Audio20 NTG4.5
1 / 10
Rev.041116
Interface Box
MB-78A Harness
LVDS1 Cable (24“)
LVDS Cable (32“)
Seng the DIP switches of the Interface B . ox
DIP on the back of the interface-b used to set the monitor type. DIP 2 and 3 must be set to OFF.1 ox is
Device
DIP 1
COMAND Online NTG4.5*
ON
7 inch Display
Audio20 NTG4.5 (1CD)*
OFF
6 inch Display
*Please see page 11 for radio pictures.
Aer each change of the DIP switch sengs you have to execute a power reset of the interface box!
2 / 10
Rev.041116
Connecng Interface box a harnesses nd
Remove the female Quadlock connector of the vehicle harness from the rear of the radio.
Remove opcal leads from the female Quadlock connector of the vehicle harness and insert them into
the female Quadlock connector of -78A harness at the same posion. MB
Remove the 12 pin Quadlock plug inserts from the female Quadlock connector of the
vehicle harness and insert them into the female Quadlock connector of harness
TV-NTG2 at the same posion
Connect the female Quadlock connector of vehicle harness to the male Quadlock connector of
MB-78A harness.
Connect the female Quadlock connector of - harness to the male Quadlock connector of the MB 78A
radio.
Connect the female 8 pin molex connector of the -78A harness to the male 8 pin molex connector of MB
the Power/CAN harness.
Connect the female 12 pin AMP connector of the Power/CAN harness to the front side of the VRFMB-
78A interface box.
3
4
5
6
7
1
3 / 10
Rev.041116
2
