Sida 1/5
R
INTERFACING SOLUTIONS
A/V
SERIES
WVI-H WiFi Module Extension AV Cable Power Harness
Dual Antennas WiFi AV Out Harness AV In / Video Out Harness
Crux Interfacing Solutions • Chatsworth, CA 91311
phone: (818) 609-9299 • fax: (818) 996-8188 • www.cruxinterfacing.com
rev.0312211 of 5
- Enables wireless (Wi-Fi) Audio/Video mirroring from mobile devices to the OEM screen.
- Provides an audio/video input which can also be used to add a camera.
- Includes a USB input to play audio and video les.
- Provides a virtual remote control via a smartphone wi connection.
- Dual band (5GHz and 2.4GHz) Wi capability for clear connection.
- Includes HMDI output for high quality video.
- Works with Facetime, Maps, Skype, YouTube, and other apps.
PRODUCT FEATURES:
PARTS INCLUDED:
WVICH-03B CAN Module WVICH-03B A/V Harness
WVICH-03B
Wi Connectivity Integration and Audio Video Interface
for Select Dodge, Jeep & RAM Vehicles 2013-2015
WORKS WITH:
iOS 7 and newer OS 4.2 and newer
R
INTERFACING SOLUTIONS
A/V
SERIES
Crux Interfacing Solutions • Chatsworth, CA 91311
phone: (818) 609-9299 • fax: (818) 996-8188 • www.cruxinterfacing.com
rev.0312212 of 5
INSTALLATION DIAGRAM:
INSTALLATION INSTRUCTIONS:
THE AV INTERFACE:
1. Remove the factory radio from the dashboard.
2. Unplug the factory connectors from behind the factory radio.
3. Mate the WVICH-03B T-Harness connecons to the factory connectors. (Make sure all connectors are
properly seated into the interface and into the radio.)
4. On the CAN Module, set DIP switch number 4 to ON to enable AV Input.
5. Switch to the new AV input by pressing the BACK buon on the radio. If the radio does not have a BACK
buon use the GREEN wire opon to toggle the AV source by connecng it to +12V. We recommend using a
toggle switch to use this feature. (See page 3)
TO FACTORY
RADIO
TO FACTORY
HARNESS
CAN
MODULE
A/V Module
GREEN Wire
(non permanent VIM)
See below step 5
Wi-Fi
INTERFACE
HDMI OUTPUT
A/V INPUT
BLUE = A/V TRIGGER*
RED = +12V ACC
BLACK = GROUND
*Connect BLUE A/V Trigger
to +12V to toggle A/V INPUT
A/V Extension
Cable
Video Out
(to extension monitors)
Video Input (or Camera)
Right Audio Input
Left Audio Input
USB Input
WVICH-03B
Wi Connectivity Integration and Audio Video Interface
for Select Dodge, Jeep & RAM Vehicles 2013-2015
1. Connect the 18-Pin power/video cable to the Wi-Fi Interface module.
2. Connect the antenna leads to the module.
3. Connect the RED power lead to +12V ACC and the BLACK wire to Ground.
4. Connect the BLUE A/V Input wire to +12V to trigger the oponal A/V input feature. The video input can
also be connected to a camera source instead. A toggle switch (not included), wired between the BLUE
wire and +12V can be used to switch ON or OFF the A/V input feature.
5. If the USB input feature will be used, you can use the virtual remote control on your smartphone to
control the USB funcons. See VIRTUAL REMOTE secon for details. Extended a USB cable to an easily
accessible locaon.
6. Plug in the Composite RCA output of the WVI-H harness to the WVICH-03B AV input.
7. Switch to the new AV input by pressing the BACK buon on the radio or the middle buon on the SWC.
(See below)
8. Test the interface and re-install the radio into the dash.
Crux Interfacing Solutions • Chatsworth, CA 91311
phone: (818) 609-9299 • fax: (818) 996-8188 • www.cruxinterfacing.com
rev.0312213 of 5
THE WIFI INTERFACE:
WVICH-03B
Wi Connectivity Integration and Audio Video Interface
for Select Dodge, Jeep & RAM Vehicles 2013-2015
R
INTERFACING SOLUTIONS
A/V
SERIES
DIP SWITCH SETTINGS ON THE MODULES:
Make sure the DIP#4 is set to the ON posion. This sets the programming to the vehicle.
1 2 3 4 5 6
ON DIP 1 ON VIM Enable OFF VIM Disable
DIP 2 OFF Not Used
DIP 3 OFF Not Used
DIP 4 ON AV Input Enable OFF AV Input Disable
DIP 5 OFF CAN Terminaon Car Side
DIP 6 OFF CAN Terminaon Radio Side
NOTE:
1. Set DIP#6 to ON if you experience the radio freezing or not responding properly.
SWITCHING TO THE A/V INPUT
Press the BACK buon once to switch to the AV source.
For vehicles without a BACK buon, user has the opon of
using a toggle switch between the GREEN wire and +12V to
switch to AV mode. Make sure to turn DIP# 1 to OFF.
NOTE: If there is no video signal owing through the
AV input, there will be a BLUE screen present. To exit,
simply press the BACK or turn o the toggle switch.
CAN
MODULE
A/V Module
GREEN Wire
(non permanent VIM)
+12V
