Electro-Voice | ND76
ND76
▪Excellent all-around vocal performance: crisp, clear
and balanced
▪Large diaphragm dynamic capsule creates a rich and
detailed frequency response
▪Shock-mounted capsule minimizes handling noise
▪Humbucking coil guards against line hum
▪Memraflex grille resists denting
The Electro-Voice ND76 is a robust, high-performance
dynamic cardioid vocal microphone.
Designed for excellent all-around voice applications,
the ND76 capsule is precisely tuned to deliver crisp,
clear and balanced vocal presence, as well as superior
isolation from sound on the stage.
The ND76 dynamic capsule contains a large Mylar
diaphragm which delivers a rich and detailed
frequency response by combining its large surface
area for tonal balance with its low-mass high-velocity
material for exceptionally fast transient response.
The ND76 features an innovative capsule shock-mount
system consisting of a 4-point suspension around the
circumference of the capsule combined with a tuned
pneumatic pump at the capsule base, offering superior
handling noise reduction to eliminate mechanical
vibrations and noise in the mix.
The ND76 capsule uses a humbucking coil that
attenuates AC hum and electromagnetic interference.
ND dynamic mics can be used with confidence near
speaker cabinets and EMF generating equipment
racks.
The ND76 Memraflex grille is made of a durable tight-
mesh grille wire that withstands extraordinarily-rough
treatment. Your microphone remains protected and
looking good gig-after-gig, year-after-year.
For additional protection, the ND76 capsule contains a
hydrophobic cloth membrane which prevents moisture
and debris from reaching the diaphragm.
Technical specifications
Element Type: Dynamic neodymium magnet structure
Frequency Response, Close: 30 Hz – 17 kHz
Frequency Response, Far: 70 Hz – 17 kHz
Polar Pattern: Cardioid
Sensitivity, Open Circuit
Voltage @ 1 kHz:
2.4 mV/Pascal
Maximum SPL: >140 dB
Polarity: Pin 2 positive, reference to pin 3 with
positive pressure on diaphragm
Impedance: 350 ohms balanced (low-z)
Microphone Connector: 3-pin, XLR-type
Finish: Black polyurethane paint
Material: Zinc die cast handle, Memraflex grille
screen
Dimensions, Length:
Diameter:
Shank:
7.2 in (182.5 mm)
2.0 in (50.5 mm)
0.96 in (24.3 mm)
Net Weight: 11.4 oz (323 g)
Shipping Weight: 21.1 oz (598 g)
Accessories Included: (1) Gig bag, (1) stand clip, and (1)
Euro thread adapter
Frequency Response:
-10
20 50
0 dB
+10
500
FREQUENCY IN HERTZ
100 1K 5K 10K 20K
Polar Response:
Dimensions:
Parts included
Qty. Item
1 Microphone
1 Gig bag
1 Stand clip
1 Euro thread adapter
1 Engineering data sheet
1 Warranty and Product Documentation Information card
Ordering information
ND76
Dynamic cardioid vocal microphone, black
Order number ND76
NDVOCCLIP
Replacement stand adapter, black
Order number NDVOCCLIP
ND76GRILLE
Replacement end grille, black
Order number ND76GRILLE
NDVOCRING
Replacement transition ring between grille sections,
silver
Order number NDVOCRING
Accessories
379-1
Foam windscreen/pop filter, black
Order number 379-1
2 | ND76
Represented by:
Bosch Security Systems, Inc.
12000 Portland Avenue South
Burnsville MN 55337
USA
Germany:
Bosch Sicherheitssysteme GmbH
Robert-Bosch-Ring 5
85630 Grasbrunn
Germany
www.electrovoice.com
© Bosch Security Systems 2016 | Data subject to change without notice
Document Number F.01U.319.492 | Vs1 | 24. Feb 2016
