Electro-Voice | RE520 Condenser supercardioid vocal
microphone
RE520 Condenser
supercardioid vocal
microphone
▪Premium condenser element delivers a highly-
detailed, full, and vivid sound
▪Supercardioid polar pattern provides excellent
acoustic isolation and feedback control
▪Multi-stage pop filter minimizes breath blasts and
plosives
▪Selectable high-pass filter reduces undesirable low
frequency content when engaged
▪Vibration-absorbing internal shock mount minimizes
handling noise
The RE520 is a premium-grade, high-performance,
condenser supercardioid vocal microphone. Designed
to reveal the exceptional detail and vivid clarity
synonymous with condenser elements, it elegantly
delivers the lyrical finesse required for expressive
vocal performances, while controlling off-axis sound
from near-by sources.
The sonic signature is detailed, full and vivid, with a
warm and clear low end, natural and present
midrange, and an open, crisp and detailed high end.
The supercardioid pattern provides excellent acoustic
isolation. Maximum feedback rejection occurs when a
stage monitor position is at either 225° or 125° off-
axis to the element. This pattern also allows for a
cleaner mix due to its rejection of off-axis sound.
The multi-stage pop filter consists of two layers of
dense foam separated by air, which attenuates wind
velocity caused by breath and windblasts.
The high-pass filter has two positions (see drawing).
The flat position delivers the full frequency band pass
of the capsule. The high-pass position attenuates
frequencies below 150 Hz.
The internal shock mount isolates the microphone
element from vibration and guards against handling
noise.
Technical specifications
Element type: Self-biased condenser
Frequency response: 40 Hz-20 kHz (see chart)
Polar pattern: Supercardioid
Sensitivity, open circuit
voltage, 1 kHz:
5.6 mV/Pascal
(-45 dBV/Pa)
Clipping (max SPL): 150 dB SPL (1% THD)
Self noise: 17 dB SPL "A" weighed (0 dB=20 μPa)
Dynamic range: 133 dB
Signal-to-Noise ratio: 77 dB
Output impedance: 200 ohms
Power requirements: 48 VDC phantom power
Polarity: Positive pressure on diaphragm
produces positive voltage on pin 2
relative to pin 3
Microphone connector: 3-pin, XLR-type
Finish: Black polyurethane paint
Materials: Zinc die cast, steel wire cloth grille
Dimensions, length:
diameter:
shank:
7.6 in. (192 mm)
1.95 in. (49.5 mm)
0.96 in. (24.3 mm)
Net weight: 11.7 oz (332 g)
Shipping weight: 1 lb 5.1 oz (598 g)
Frequency response:
High-Pass
-10
20 50
0 dB
+10
500
FREQUENCY IN HERTZ
100 1K 5K 10K 20K
HP 1cm
HP 5cm
HP 1m
Flat
-10
20 50
0 dB
+10
500
FREQUENCY IN HERTZ
100 1K 5K 10K 20K
1cm
5cm
1m
High-Pass filter:
High-Pass (A) Flat (B)
A High-Pass B Flat
Dimensions:
7.6" [192mm]
1.95" [24.3mm]
0.96"
[49.5mm]
Polar response:
500 Hz 1,000 Hz125 Hz 250 Hz
8000 Hz 16000 Hz
2000 Hz 4000 Hz
270°
300°
330° 30°
60°
90°
120°
150°210°
240°
-5dB
-10dB
-15dB
-20dB
0°
180°
270°
300°
330° 30°
60°
90°
120°
150°210°
240°
-5dB
-10dB
-15dB
-20dB
0°
180°
270°
300°
330° 30°
60°
90°
120°
150°
210°
240°
-5dB
-10dB
-15dB
-20dB
0°
180°
270°
300°
330° 30°
60°
90°
120°
150°210°
240°
-5dB
-10dB
-15dB
-20dB
0°
180°
Replacement
parts
Description
RE520GRILLE Replacement grille, black
NDVOCCLIP Replacement stand adapter, black
Parts included
Quantity Component
1 Microphone
1 Gig bag
1 Stand clip
1 Engineering datasheet
1 Warranty and product documentation information
card
Ordering information
RE520 Condenser supercardioid vocal microphone
Condenser supercardioid vocal microphone, black
Order number RE520
Accessories
379-1 379-1 WINDSCREEN, BLACK, PACKAGED
Foam windscreen/pop filter, black
Order number 379-1
2 | RE520 Condenser supercardioid vocal microphone
Represented by:
Germany:
Bosch Sicherheitssysteme GmbH
Robert-Bosch-Ring 5
85630 Grasbrunn
Germany
Bosch Security Systems, Inc.
12000 Portland Avenue South
Burnsville MN 55337
USA
www.electrovoice.com
© Bosch Security Systems 2018 | Data subject to change without notice
Document Number | Vs1 | 19. Jun 2018F.01U.354.343
