PL80c
Dynamic Supercardioid
Vocal Microphone
General Description:
Key Features:
• EQ-friendly sonic contour
• Highly detailed frequency response
• Supercardioid polar pattern
• Powerful Neodymium magnet structure
• Shock mounted capsule and low handling noise
• Fine mesh Memraflex™ grille
Thank you for purchasing the Electro-Voice® PL80c. This product is
a premium-grade supercardioid dynamic microphone designed to
elegantly capture the character of vocals in live sound applications.
The PL80c’s “EQ-friendly” sonic contour adapts well to any vocal
texture allowing vocals to sit nicely in the mix without being harsh.
The enhanced isolation provided by its supercardioid polar pattern is
an excellent defense against system feedback and cross-talk bleed
emanating from other nearby sound sources. The result is higher
gain before feedback and cleaner stage mixes. Although designed
to be a vocal microphone for music and spoken word, the PL80c will
also function well as an instrument or amplifier microphone where a
dynamic element capsule would be desired.
Application Notes:
As with most directional microphones, the low frequency response
of the PL80c microphone varies with the distance from the sound
source. Known as “proximity effect”, the bass response of the
microphone increases as the working distance to the microphone is
reduced. This “bass boost” is only audible when working at distances
closer than 6 inches. Using this microphone at distances greater
than 6 inches provides minimal coloration from proximity effect.
Proximity effect can be used to your advantage when a thin voice
is being recorded. As the vocalist decreases their working distance
to the microphone, the low frequency content is enhanced. Close-
up positioning of the microphone will also reduce the potential for
feedback from the sound reinforcement system. When close-talked,
the bass-boost provides an increase in overall microphone output
level. The mixer gain may be proportionately reduced, resulting in
a reduction of the system’s sensitivity to feedback caused by the
sound entering the microphone from the loudspeakers.
Warranty:
This Electro-Voice® PL80c product is guaranteed against malfunc-
tion due to defects in materials or workmanship for a period of three
(3) years from the date of original purchase. Please refer to the
Limited Warranty card included with your product for further warranty
information.
Technical Specifications:
Element Type: Dynamic, Neodymium Magnet
Structure
Frequency Response: 80 Hz - 16,000 Hz
Polar Pattern: Supercardioid
Sensitivity, Open Circuit
Voltage, 1 kHz:
2.2 mV/Pa (-53 dBV)
Polarity: Positive pressure on diaphragm
produces positive voltage on pin 2
relative to pin 3
Rated Impedance: 600 ohms
Microphone Connector: 3-pin, XLR-type
Finish: Textured satin handle with
MemraflexTM grille
Dimensions: Length = 7.44” (189.0 mm)
Width = 2.00” (50.7 mm)
Shank = 1.01” (25.6 mm)
Accessories Included: Stand adapter with Euro-thread
insert, Soft zippered gig bag
Net Weight: 11.8 oz (333 g)
Shipping Weight: 20.7 oz (587 g)
12000 Portland Avenue South, Burnsville, MN 55337
Phone: 952/884-4051, Fax: 952/884-0043
www.electrovoice.com
© Bosch Communications Systems 08/2008
Part Number LIT000255 Rev B
U.S.A. and Canada only. For customer orders, contact Customer Service at:
800/392-3497 Fax: 800/955-6831
Europe, Africa, and Middle East only. For customer orders, contact Customer Service at:
+ 49 9421-706 0 Fax: + 49 9421-706 265
Other Internatonal locations. For customer orders, Contact Customer Service at:
+ 1 952 884-4051 Fax: + 1 952 887-9212
For warranty repair or service information, contact the Service Repair department at:
800/685-2606
For technical assistance, contact Technical Support at: 866/78AUDIO
Specifications subject to change without notice.
Electro-Voice®
Dimension Drawing:
Frequency Response: Polar Response:
Microphone Use and Placement
Please note that micing techniques are a matter of personal preference. These are merely guidelines to assist in the placement of the
microphone to gain optimal performance.
Usage Optimal Placement
Vocals 0 to 6 inches away, aimed directly at the sound source.
Spoken Word 5 to 10 inches away, aimed directly at the sound source.
Standard Placement & Use Guidelines
1. Always point the microphone at the desired source of sound, and away from any unwanted sources.
2. The microphone should be located close to the sound source to minimize interference from other potential sound sources.
3. Use the 3-to-1 rule when using multiple microphones. Place each microphone three times farther from other microphones as from
the desired sound source.
4. Minimize over-handling of the microphone to reduce unwanted mechanical noise.
PL80c Part Numbers
PRD000162001 PL80c, Dynamic Supercardioid Vocal •
Microphone
ACC000045000 SAPL-1, Replacement Microphone Stand •
Adapter
ACC000048001 WSPL-1, Optional Foam Windscreen, Black•
