SP-688

Broadband 4-in-1 SOHO IAD

EnGenius Networks Singapore Pte Ltd

215 Henderson Road #01-04 Henderson Industrial Park Singapore 159554 Tel :(+65) 6227 1088 Fax:(+65 ) 6227 2766

Website: www.engeniustech.com.sg Email: inquiry@engeniustech.com.sg

The SP-688 is the first wireless SOHO router integrated with

Voce Over IP Soft Switch and advanced PBX features. It

enrich router features give SOHO users easy connection

either to internet or to another router on your network. SP-

688 has separate WAN and LAN Ethernet port. The WAN

connection can be connect through DHCP, PPPoE , PPPT

or a fixed IP address. The LAN port can assign IP address

to IP telephones and computers using NAT and DHCP.

SP-688 delivers the secure, reliable, high performance

WLAN workforce demands. Four products in one, the

multitalented firewall router, NAT/DHCP router, Wireless

802.11b/g Access Point delivers broadband and IP-PBX. It

access that’s continuously available for sharing with all user networked devices. Simple to use, just plugs directly into

your ADSL or Cable line for instant connectivity to network resources and the Internet. Easy setup, with our Smart

Wizard install assistant helps to guide user each step of the way and upgradeable enhancements are available via the

Web browser.

The SP-688 IP-PBX support common PBX features such as aut ree way conferencing, call o-attendant, voice mail, th

forwarding, call park, intercom, call transfer and much more. As well, SP-688 also support advanced PBX features such

as working day/holiday greeting, voice mail notification by e-mail and expandable voice mail memory by using USB

memory stick. With these various VoIP call features, SOHO users not only benefit with low cost long distance phone

service, mobility telephone extension but also data, voice integration in one network.

With Senao high power 802.11b/g Wi-Fi module, SP-688 also give a much better coverage and data access in any

SOHO environment. Office mobility can be easily achieved by using Senao Wi-Fi phone which support both WEP, WPA

of Security and WMM of QoS. SP-688’s highly integration of data and voice is the best solution for SOHO market.

SP-688

Broadband 4-in-1 SOHO IAD

EnGenius Networks Singapore Pte Ltd

215 Henderson Road #01-04 Henderson Industrial Park Singapore 159554 Tel :(+65) 6227 1088 Fax:(+65 ) 6227 2766

Website: www.engeniustech.com.sg Email: inquiry@engeniustech.com.sg

HARDWARE SPECIFICATION

USB Host VIA VT6212L USB 2.0 Host Controller.

Wireline Ethernet Single PHY RTL8201CP(WAN and LAN)

Expansion Slots Mini-PCI Slots

Battery Slot

For WLAN Module

For lithium/manganese coin battery Module

I/O Connector Multi ICE 2x16 PIN Header x 1

USB Host v2.0 Type A x 1

RS-232 2x5 PIN Header x 1

Telephone voice RJ11 FXS and FXO Port x 1

10/100Mbps Ethernet RJ-45 WAN and LAN

Port x 1

CPLD burn in 1X8 PIN Header x 1

Power and Reset Power Jack for DC 12V@1.25A input.

Reset Button A

Reset Button B

Reset to Factory Default

System Reset (Debug only)

SOFTWARE SPECIFICATIONS

FXS Port 1 FXS port for analog phone Telephony

FXS Port 1 FXO port for PSTN (Life Line)

Voice protocol SIP V2 (RFC3261, 3262, 3263, 3264)

SIP Features SIP application server

Proxy

Registry

Location server (RFC3263)

STUN client (Optional)

VOIP users

10 + 1 registrations

11 voicemail accounts

Meet Me conference room (3 user)

Up to 5 Out-bound SIP accounts

Account Setting User Setting

Group Setting

User and Group List

Voicemail (maximum internal capacity 30 minutes)

VoIP Setting Outbound SIP Setting

Dial Plan Setting

VoIP Information Call Monitor

SIP Registry

SIP Peers Info

Call Detail Record

Management Web based SIP Call manager

VoIP

Call routing Smart Routing Rule

SP-688

Broadband 4-in-1 SOHO IAD

EnGenius Networks Singapore Pte Ltd

215 Henderson Road #01-04 Henderson Industrial Park Singapore 159554 Tel :(+65) 6227 1088 Fax:(+65 ) 6227 2766

Website: www.engeniustech.com.sg Email: inquiry@engeniustech.com.sg

Route by called number

Codecs(Supported in FXS) G.711a law, G.711u law

G.729A

Codecs(Supported in IP phones) G.711a law, G.711u law

G.729A

Number 1

LAN port speeds 10/100 Mbps auto negotiation

LAN

DHCP servers

Three DHCP pools

Dedicated IP address for particular clients (MAC)

Connection list

Number 1

WAN port speeds 10/100 Mbps auto negotiation

Connection types Static IP

DHCP (Clone MAC address for WAN included

PPPoE

PPTP (Optional)

WAN

Dynamic DNS Support

NAT Many-to-one

ALG Supported (FTP, IRC, NNS, PPTP, SNMP, TFTP)

Port Forwarding with scheduling function

Port Triggering with scheduling function

Firewall Block PING from WAN

DMZ

Filtering MAC address filtering with scheduling function

IP Filtering with scheduling function

Application Filtering (P2P, MSN) with scheduling function

Block Sites

URL-Keyword blocking

VPN PPTP, IPSEC, L2TP pass through

Router

QoS Priority Queue (2 Queue, IP Port based)

Bandwidth Allocation (VOIP, and FTP)

Stateful Packet INSP Supported Firewall

IP Related LAND attack

zero length IP option

corrupted IP option

Unknown IP Protocol

Smurf attack

IP source route

IP unaligned time
