Sida 1/12
888-97-357-G-00 rev. A • 09/14
1/12
StyleView® SV43/44 Primary Drawer
12.5"
(315 mm)
10.5"
(267 mm) 10.5"
(267 mm)
3.75"
(96 mm)
2.5"
(64 mm)
<0.25 lbs (0.1 kg)< 2 lbs (1 kg)
or
User Guide
User's Guide - English
Guía del usuario - Español
Manuel de l’utilisateur - Français
Gebruikersgids - Deutsch
Benutzerhandbuch - Nederlands
Guida per l’utente - Italiano
Användarhandbok - svenska
ユーザーガイド : 日本語
用户指南 : 汉语
Total weight capacity per drawer. Total weight capacity per drawer.
For the latest User Installation Guide please visit: www.ergotron.com
888-97-357-G-00 rev. A • 09/14
2/12
A
1
2
3
4
1x
1x
1x
1x
14mm (9/16")
2x 2x
4x
M6 x 10mm
M3 x 14mm
1x 3x or
or
or
3x
1x 9x
1x 1x 1x
2x
M4 x 14mm
M6 x 43mm
CAUTION: Close worksurface before opening drawers. Open only one drawer at a time. Do Not
push cart when drawers or worksurface are open. Failure to follow these instructions may cause
the cart to be unstable.
WARNING
IMPACT HAZARD!
MOVING PARTS CAN CRUSH AND CUT.
Minimize Lift Tension BEFORE:
· Removing Mounted Equipment.
· Shipping Cart
· Storing Cart
To Minimize Lift Tension
1. Lower worksurface to lowest position.
2. Turn adjustment nut at top of riser
counterclockwise until it stops
(Adjustment may require 40-60 revolutions).
Failure to heed this warning may result in
serious personal injury or property damage!
For More information and instructions refer to product
guide at http://4support.ergotron.com or contact
Ergotron Customer Care at 1-800-888-8458.
822-052
14mm (9/16”)
LCD Carts
1 Drawer 3 Drawers
Laptop Carts
Battery Pack for
Non-Powered Carts Only
Powered Carts Non-Powered Carts
888-97-357-G-00 rev. A • 09/14
3/12
1
a b c
2
3
b
c
2x
2x
M6 x 43mm
M6 x 10mm
Turn power system o by
holding down the AC Outlet
Power button for 1 - 3 seconds.
Power light will shut o .
Turn o all mounted equipment. Disconnect Power System from power source.
Remove the
top cover.
Hang the drawer tabs
onto the brackets on
the cart.
WARNING! Disconnect all power to the cart and turn o all mounted equipment before
proceeding with this installation. Failure to follow this warning may result in serious injury and or
equipment damage.
