Sida 1/28

User’s Guide and Operator Instructions

CBS- 3 - 22 1 & CBS 2232 Next Generation Brewing System

FETCO Next Generation-NG® Commercial Beverage Equipment

CBS CBS- 322 1 - 32 22

( ) (Dispensers not included Plastic brew baskets are standard, with optional b rewers avalible stainless steel brew baskets)

CONTACT INFORMATION

FETCO® FOOD EQUIPMENT TECHNOLOGIES COMPANY

600 ROSE ROAD

LAKE ZURICH • IL • 60047 0429 • USA-

Product made in USA

INTERNET: www.fetco.com

PATENTS:https://www.fetco.com/pl,pages,patents,74.html

PHONE: (800) 338- 2699 (US & CANADA)

- ( ) (847) 719 3000 All Countries and International

- FAX:(847) 719 3001

EMAIL:sales@fetco.com

( orders@fetco.com to order parts and equipment)

techsupport@fetco.com (all service queries)

P 3 215 REV000 February 202

COFFEE BREWER CBS- 3022 NG Series

TABLE OF CONTENTS

Rough-In Drawings ...................................................... 2

Electrical and Output Specifications ............................ 3

Programming Menu ..................................................... 5

Brew Recipes ............................................................... 5

Inputs 7...........................................................................

Service ......................................................................... 7

Hot Water Portions ....................................................... 8

Calibration .................................................................... 9

Outputs ....................................................................... 10

Counters ..................................................................... 11

Brewer Setup .............................................................. 12

Installation Guide........................................................ 14

Operator Training ....................................................... 15

Parts diagrams ........................................................... 18

fetco.com

2 P 3 215 REV000 February 202

Specifications and Requirements

FETCO CBS- 2230 Brewers have unique construction only available for these models.

Water Requirements:

Coffee Filter Size:

CBS-2230 20- - 75 psig, (138 517kPa) 1½ gpm/(5.7 lpm)

13” X 5 or FETCO# F002”

Optimal water hardness between 125 13 grain)-250 -TDS (6

Important! Please use a water filter for all beverage equipment

Temperature, as set by factory:

200°F (93°C) inside water tank (at sea level)

Water inlet fitting: 3/8 inch male flare.

Brewer supplied with inlet valve adaptor for BSP to SAE

Electrical: 3. See electrical configuration chart Pg

Brew Volume: Full Batch

3.8 L/1.0 gal brew

Brew Capacity

(approximate)

CBS- 3 4- 22 1 8 brews per hour

CBS- 3 5- 22 2 16 brews per hour

Output is controlled by heater power and water temperature

Total Brew Cycle: Factory setting: minutes consisting of 4 min brew time and 6 . 2.0 . min drip delay

Individual menu brew- process parameters are user controllable for:

Basic user controls for brew volume, brew time units of measure, , recipe name

Advanced for programmable eneruser controls pulse count, prewet percent and prewet delay, drip delay, gy saving

See pages 4-5 for how to adjust controls for temperature, brew volume, units and all other settings -

Weights and Capacities

Model Height Depth Width

Water tank

capacity

Empty

Weight

Filled

Weight

Shipping

Weight

Shipping Dimensions

CBS-2231

Brewer

27 3/4 in

700 mm

11 3/4 in

300 mm

20 3/8 in

520 mm

3.3 gallon

12.4 L

29 lbs

13.2 kg

55 lbs

25.0 kg

41 lbs

18.6 kg

30” x 17” x 22”

76.2 x 43.2 x 55.9 cm

CBS-2232

Brewer

27 3/4 in

700 mm

19 ¾ in

500 mm

20 3/8 in

520 mm

6.0 gallon

22.4 L

47 lbs

21.3 kg

92 lbs

41.7 kg

55 lbs

25.0 kg

30” x 23” x 25”

76.2 x 58.4 x 63.5 cm

Calibrated for

3.8 L/1.0 gal brew

Brew Basket 13” X 5” Coffee Filter 13” X 5 or FETCO# F002”

1” legs standard

2.5” legs optional

Rough-In Drawings

CBS- 31 22 Front CBS- 32 22 Front CBS- 3 1 & 22 1 CBS- 322 2 Side Power cord plug

EXAMPLE: SKU E2 - -231US 1X117 PM001 SKU NUMBER IDENTIFICATION KEY

Product Line

Level Phase Family Region ID Voltage Range

# Heaters

Individual Heater

Wattage

Brew

Basket

Hot Water

Faucet

Bypass

Brew Basket

Locks

Power Cord

E=extractor

US =United

States

1 - 1 A = 100 120 1.5 P=plastic M=manual 1=Yes 1=Yes 0=Terminal Block

12=PLUS

Series

3 1=

single side

IN =

International

2 - 2 No No - B = 200 240 1.7 M=metal A=automatic 0= 0= 1= NEMA 5 15P

22=Next

Generation

3 2=

dual side

CE = C = 380IEC 3 - 3 415 2.3

C=metal

with clips

N=None

2=NEMA 5- 20P

NM = NOM

U = 1 or 3

D = 440- 480

3.0

3=NEMA 6- 15P

4.0

4=NEMA 6- 30P

X=120 or 240

Dual Voltage

5.0

5=CEE 7/7

Schuko

6=UK1- 13P

7= AUSTRALIAN

AS3112 (YP-35)

3 P 3 215 REV000 February 202

Electrical and Output Specifications

Customer options

BREW BASKET TYPE

) (P, M

HOT WATER FAUCET

(M, A OR N)

BYPASS

(1 OR 0)

Brew Basket Lock

(1 OR 0)

* is factory standard feature

Add all the following numbers

after all SKU numbers

*P=Plastic

M=Gourmet Metal

*M=Standard manual

A=Automatic electronic

N=No hot water faucet

*1=With

0=None

*1=With

0=None

CBS- - 2231Next Gen Single 3.0 4.0 Liter Coffee Brewers Field configurable Domestic

Electrical and Output Specifications Brewer has factory installed cord and plug & terminal block 50Hz or 60Hz

SKU Voltage

Heater

Configuration

Wires KW

Electrical

Connection

Phase Amp Draw

Brew-Volume

per hour

E2231US 1X117 PA011- -

120

1 X 1.7 kW

2+G

1.7

NEMA 15- 5P

14.7

3.9 gal/14.8 L

Domestic-Dual Voltage

208 240-

2 X 1.7 kW

2+G

2.6 3.4-

Terminal Block

12.8 14.7-

5.8 gal/22 L

Electrical Specifications, Domestic Single brewer

- single voltage 120 volt cord and plug single phase 50Hz or 60Hz

CBS- - 2231Next Gen Single 3.0 4.0 Liter Coffee Brewers Domestic models

Electrical and Output Specifications All brewers have factory installed cord and plug 50Hz or 60Hz

SKU Voltage

Heater

Configuration

Wires KW

Electrical

Connection

Phase Amp Draw

Brew-Volume

per hour

E2231US 1A115 PA011- -

120

1 X 1.5 kW

2+G

1.5

NEMA 15- 5P

13.0

4.0 gal/15.1 L

E2231US 1A123 PA012- -

120

1 X 2.3 kW

2+G

2.3

NEMA 5- 20P

19.7

5.8 gal/22 L

CBS- - 2231Next Gen Single 3.0 4.0 Liter Coffee Brewers Field configurable NOM (Mexico) In Spanish

Electrical and Output Specifications Brewer has factory installed cord and plug & terminal block 50Hz or 60Hz

SKU Voltage

Heater

Configuration

Wires KW

Electrical

Connection

Phase Amp Draw

Brew-Volume

per hour

E2231NM 1X123 PA012- -

120

1 X 2.3 kW

2+G

2.3

NEMA 5- 20P

19.7

6.1 gal/23.2 L

Dual Voltage

208 240-

2 X 2.3 kW

2+G

4.6

Terminal Block

17.1 19.7-

7.6 gal/30 L

NM in SKU suffix (above) denotes equipment with NOM certification, Spanish labeling for Mexico and Spanish language user guide

CBS- - 2231Next Gen Single 3.0 4.0 Liter Coffee Brewers International models

Electrical and Output Specifications All brewers have terminal block electrical utility connection 50Hz or 60Hz

SKU Voltage

Heater

Configuration

Wires KW

Electrical

Connection

Phase Amp Draw

Brew-Volume

per hour

E2231NM 1A123 PA012- -

120

1 X 2.3 kW

2+G

2.3

NEMA 5- 20P

19.7

5.8 gal/22 L

E2231NM 1A123 PA012- -

208 240-

1 X 3.0 kW 2+G 2.3 3.0 -

NEMA 6- 1 - 15P 11.3 13.0

7.9 gal/30.0 L

NM in SKU suffix

(above) denotes equipment with NOM certification, Spanish labeling for Mexico and Spanish language user guide

E2231IN- - 1B123 PA010

200 240-

1 X 2.3 kW

2+G

1.6 2.3-

Terminal Block

8.5 10.1-

5.8 gal/22 L

E2231IN- - 1B130 PA010

200 240-

1 X 3.0 kW 2+G 2.1 3.0 -

Terminal Block

1 - 10.9 13.0

7.7 gal/29.1 L

CBS-2 231Next Ge n 3.0- 4.0 Liter C offee Br ewers CE mo dels

Electric al and Output Specificat ions Sch uko cord an d pl ug 50Hz

SKU Voltage Hea ter Config uratio n - Wir es KW Elec tric al Conn ecti on Phas e Amp Draw Brew V olume per hour

E2231CE PA0 15- -1 B12 3

230

1 X 2 .3 kW

L/N/PE

2.1

CEE 7/7 Shuk o

9.7

5.8 gal/ 22 L

E2231CE PA0 15 230- -1 B13 0 1 X 3 .0 kW 1 L/N/PE 2.8 CEE 7/7Shuk o 12.5 7.7 g al/29. 1 L

CBS-22 - 32Next Gen Dual 3.0 4.0 Liter Coffee Brewers Domestic models

Electrical and Output Specifications All brewers have terminal block electrical utility connection 50Hz or 60Hz

SKU Voltage

Heater

Configuration

Wires KW

Electrical

Connection

Phase Amp Draw

Brew-Volume

per hour

E2232US 223 PA010-1B -

208 240-

2 X 2.3 kW

2+G

3.5 4.6-

Terminal Block

17.1 19.7-

11.0 gal/42.0 L

E2232US 223 MA110-1B -

208 240-

2 X 2.3 kW

2+G

3.5 4.6-

Terminal Block

17.1 19.7-

11.0 gal/42.0 L

E2232US 230 PA010-1B -

208 240-

2 X 3.0 kW

2+G

4.5 6.0-

Terminal Block

22.2 25.5-

14.3 gal/54 L

E2232US 230 PA110-1B -

208 240-

2 X 3.0 kW

2+G

4.5 6.0-

Terminal Block

22.2 25.5-

14.3 gal/54 L

E2232US 230 MA110-1B -

208 240-

2 X 3.0 kW

2+G

4.5 6.0-

Terminal Block

22.2 25.5-

14.3 gal/54 L

CBS- - 2232Next Gen Dual 3.0 4.0 Liter Coffee Brewers International models

Electrical and Output Specifications All brewers have terminal block electrical utility connection 50Hz or 60Hz

SKU Voltage

Heater

Configuration

Wires KW

Electrical

Connection

Phase Amp Draw

Brew-Volume

per hour

E2232IN- - 1B223 PA010

200 240-

2 X 2.3 kW

2+G

3.2 4.6-

Terminal Block

16.5 19.7-

12.2 gal/46.3L

E2232IN- - 1B230 PA010

200 240-

2 X 3.0 kW

2+G

4.2 6.0-

Terminal Block

21.3 25.5-

15.8 gal/60 L

E2232IN- -1B230 MA110

200 240-

2 X 3.0 kW

2+G

4.2 6.0-

Terminal Block

21.3 25.5-

15.8 gal/60 L

E2232NM 1B230 PA010- -

208 240-

2 X 3.0 kW

2+G

4.5 6.0-

Terminal Block

22.2 25.5-

15.8 gal/60 L

NM in SKU suffix (above) denotes equipment with NOM certification, Spanish labeling for Mexico and Spanish language user guide

CBS-1 232PLU S Dual 3. 0- 4.0 Liter Cof fee B rewers C E m odels

Electrical an d Outp ut Spe cifications Al l brewers have t erm in al bloc k el ectri cal uti lity co nnecti on 50Hz

SKU

Voltage

Hea ter Config uratio n

Wir es

Elec trical C onn ecti on

Phas e

Amp Draw

Brew-Volum e per ho ur

E2232CE PA0 10- -1 B22 3

230

2 X 2 .3 kW

L/N/PE

4.2

Terminal Bl ock

18.9

11. 0 gal/ 42.0 L

E2232CE PA0 10- -1 B23 0

230

2 X 3 .0 kW

L/N/PE

5.5

Terminal Bl ock

25.5

14. 9 gal/ 56 L

E2232CE PA0 10- -2 B22 3

230/400

2 X 2 .3 kW

2L/N/PE

4.2

Terminal Bl ock

9.7

11. 0 gal/ 42.0 L

E2232CE PA0 10- -2 B23 0

230/400

2 X 3 .0 kW

2L/N/PE

5.5

Terminal Bl ock

12.5

14. 9 gal/ 56 L

Produktspecifikationer

Varumärke:	Fetco
Kategori:	kaffebryggare
Modell:	CBS-2232

Behöver du hjälp?

Om du behöver hjälp med Fetco CBS-2232 ställ en fråga nedan och andra användare kommer att svara dig

Ditt namn*

Din e-post*

Skriv din fråga här

kaffebryggare Fetco Manualer

Fetco CBS-2251 Bruksanvisning

12 September 2024

Fetco CBS-2231 Bruksanvisning

12 September 2024

Fetco CBS-2241 Bruksanvisning

12 September 2024

Fetco CBS-2232 Bruksanvisning

12 September 2024

Fetco CBS-2242 Bruksanvisning

12 September 2024

Fetco CBS-2252 Bruksanvisning

12 September 2024

Fetco CBS-2151XTS Bruksanvisning

8 September 2024

Fetco Luxus L4D-10TLA Bruksanvisning

5 September 2024

Fetco CBS-1252 Bruksanvisning

4 September 2024

Fetco CBS-1151-XV+ Bruksanvisning

3 September 2024

kaffebryggare Manualer

Nyaste kaffebryggare Manualer

Quigg GT-TCM-03 - 5609 Bruksanvisning

16 Januari 2025

Krups F309 - PRO AROMA Bruksanvisning

16 Januari 2025

Kenwood CMM480 series Bruksanvisning

16 Januari 2025

Krups F2707199F Duothek Therm Bruksanvisning

16 Januari 2025

Krups EA85 serie Bruksanvisning

15 Januari 2025

Krups F30901 - PRO AROMA Bruksanvisning

15 Januari 2025

AEG Electrolux BTV 9900 M Bruksanvisning

15 Januari 2025

Krups KP 2005 Bruksanvisning

15 Januari 2025

Krups KM4682 - T8.2 Bruksanvisning

15 Januari 2025

Krups PROEDITION INOX FMD3 Bruksanvisning

15 Januari 2025
