PN 2414311 March 2005 Rev.1, 10/05
© 2005 Fluke Corporation. All rights reserved. Printed in U.S.A.
1
i400
AC Current Clamp
Calibration Information
Introduction
XWWarning
To avoid electric shock or injury, do not perform the performance tests or
calibration procedures unless you are qualified to do so.
The information provided in this manual is for the use of qualified personnel
only.
The i400 Calibration Information provides the information necessary to verify the performance of the
Fluke i400 AC Current Clamp, hereafter known as the Current Clamp.
The following information is included in this document:
• Safety Information and Electrical Symbols
• Specifications
• Maintenance
• Performance Tests
• User-Replaceable Parts
• Warranty Statement
See the i400 Instruction Sheet for complete operating instructions.
Contact Information
To contact Fluke, call:
USA: 1-888-44-FLUKE (1-888-443-5853)
Canada: 1-800-36-FLUKE (1-800-363-5853)
Europe: +31 402-675-200
Japan: +81-3-3434-0181
Singapore: +65-738-5655
Anywhere in the world: +1-425-446-5500
USA Service: 1-888-99-FLUKE (1-888-993-5853)
For additional information about Fluke, its products, and services, visit Fluke’s web site at:
www.fluke.com
To register this product, go to register.fluke.com
i400
Calibration Information
2
Safety Information
XW Read First: Safety Information
To ensure safe operation and service of the Current Clamp, follow these
instructions:
• Read the operating instructions before use and follow all safety
instructions.
• Use the Current Clamp only as specified in the operating instructions,
otherwise the clamp’s safety features may not protect you.
• Adhere to local and national safety codes. Individual protective equipment
must be used to prevent shock and arc-blast injury where hazardous-live
conductors are exposed.
• Only hold the Current Clamp below the tactile barrier, see Figure 1.
• Before each use, inspect the Current Clamp. Look for cracks or missing
portions of the clamp housing or output cable insulation. Also look for
loose or weakened components. Pay particular attention to the insulation
surrounding the jaws.
• Never use the Current Clamp on a circuit with voltages higher than 1000 V
CAT III or 600 V CAT IV.
• CAT III equipment is designed to protect against transients in
equipment in fixed-equipment installations, such as distribution
panels, feeders and short branch circuits, and lighting systems in
large buildings.
• CAT IV equipment is designed to protect against transients from the
primary supply level, such as an electricity meter or an overhead or
underground utility service.
• Use extreme caution when working around bare conductors or bus bars.
Contact with the conductor could result in electric shock.
• Use caution when working with voltages above 60 V dc or 30 V ac. Such
voltages pose a shock hazard.
Electrical Symbols
The symbols in Table 1 appear in this document or on the Current Clamp.
Table 1. Electrical Symbols
Symbol Explanation
, Application around and removal from hazardous live conductors is permitted.
T Product is protected by double insulation.
W Risk of Danger. Important information. See Instruction Sheet.
X Hazardous voltage.
) Conforms to relevant Canadian Standards Association directives.
P Conforms to relevant European Union directives.
AC Current Clamp
Safety Specifications
3
Tactile Barrier
bbs03f.eps
Figure 1. Tactile Barrier
Safety Specifications
Category Rating: CAT III 1000 V and CAT IV 600 V per EN/IEC61010-1, Pollution Degree 2
) : Tested to US and Canadian standards for compliance to UL 61010-1 and CAN/CSA C22.2
No. 61010-2-32
P : EN 61010-2-32, EN61010-1
EMC Specifications
EMC: EN 61326-1, FCC for emission and immunity
Electrical Specifications
Reference Conditions: 23 ± ° ± ° 5 C, 20 to 75 % RH (73 41 F, 20 to 75 % RH); conductor centered in jaw
opening; no dc component; no adjacent conductor
Measurement Range: 1 A to 400 A ac rms
Output: 1 mA/A
Accuracy: 2 % + 0.06 A, 45 Hz to 400 Hz
Typical Bandwidth: 5 Hz to 20 kHz
Working Voltage: 1000 V ac rms, in compliance with EN61010
Common Mode Voltage: 1000 V ac rms from earth ground, in compliance with EN61010
Load Impedance: < 10 Ω
Maximum Non-destructive Current: 1000 A
Duty Cycle: 1 A to 400 A continuous
Influence of Adjacent Conductor: < 7.5 mA/A
Influence of Conductor Position in Jaw Opening: ± 1.0 % of reading + 0.05 A
