Sida 1/34
®
Signature Series Subwoofer Installation Instructions ........................................................................2
Instructions d'installation du caisson de basse Signature Series ......................................................6
Subwoofer Signature Series Istruzioni di installazione ................................................................... 11
Subwoofer der Signature Series – Installationsanweisungen ......................................................... 15
Instrucciones de instalación del subwoofer de la Signature Series ................................................ 20
Signature Series da série esportiva da marca ................................................................................ 25
Signature Series subwooferinstallatie-instructies ........................................................................... 30
Garmin®, the Garmin logo, and the Fusion
™
logo are trademarks of Garmin Ltd. or its subsidiaries, registered in the USA and other countries. Fusion and True-Marine
™
are trademarks of Garmin Ltd. or its
subsidiaries. These trademarks may not be used without the express permission of Garmin.
December 2014 190-01845-90_0APrinted in China
Signature Series Subwoofer
Installation Instructions
Important Safety Information
WARNING
Failure to follow these warnings and cautions could result in
personal injury, damage to the vessel, or poor product
performance.
See the guide in the Important Safety and Product Information
product box for product warnings and other important
information.
This device must be installed according to these instructions.
Disconnect the vessel's power supply before beginning to install
this product.
CAUTION
Audio systems can produce sound pressure levels exceeding
135 dB. Continuous exposure to sound pressure levels over
100 dB may cause permanent hearing loss. The volume is
typically too loud if you cannot hear people speaking around
you. Limit the amount of time you listen at high volume. If you
experience ringing in your ears or muffled speech, stop listening
and have your hearing checked.
Always wear safety goggles, ear protection, and a dust mask
when drilling, cutting, or sanding.
NOTICE
When drilling or cutting, always check what is on the opposite
side of the surface.
It is strongly recommended that you have your audio system
installed by a professional installer to ensure optimum
performance.
You must read all installation instructions before beginning the
installation. If you experience difficulty during the installation, go
to for product support.www.fusionentertainment.com
After installing the subwoofer, you should run the subwoofer at
low to medium volumes for the first few hours of use. This helps
to improve the overall sound by gradually loosening up the
moving components of the subwoofer, such as the cone, spider,
and surround
What's In the Box
• 1 subwoofer
• 6 Phillips stainless steel, 4.8 mm x 50 mm (10 gauge x 2 in.)
mounting screws
• Mounting template
• Grille (Classic models only)
• 1 tinned LED connection cable (6 m) (Sports models only)
• Hex key (Sports models only)
Tools Needed
• Electric drill
• Drill bit (size varies based on surface material)
• Phillips screwdriver
• Wire strippers
• Crimping tool
• Electrical tape
• Appropriate saw or utility knife to cut surface material
• Suitable gauge speaker wire for the length required
NOTE: For customized installations, additional tools and
materials may be needed.
Mounting Considerations
Selecting the correct mounting location is critical to optimize the
performance of the audio system. Fusion
™ subwoofer is
designed to perform in the widest possible range of mounting
locations, but the more you plan the installation, the better the
subwoofer's sound will be.
• The audio system must be turned off before making any
connections. Failure to do so could result in permanent
damage to the audio system.
• You should protect all terminals and connections from
grounding and from each other. Failure to do so could result
in permanent damage to the audio system and voids the
product warranty.
• You should protect the wires from sharp objects and always
use rubber grommets when wiring through panels.
• The mounting location must avoid potential obstacles, such
as fuel and hydraulic lines and wiring.
• The mounting location must provide sufficient clearance for
the mounting depth of the subwoofer as specified in the side
view drawings and the specifications.
• When possible, the area behind each subwoofer should be
enclosed.
• To avoid interference with a magnetic compass, the
subwoofer should not be installed closer to a compass than
the compass-safe distance value listed in the product
specifications.
• You should select a flat mounting surface for the best seal.
• For better bass performance, the subwoofer should be
mounted in an area that provides just enough room behind
the subwoofer. Too small an area restricts bass, and too
large an area compromises bass performance. Placing a
subwoofer close to an open area produces the least bass.
• When a subwoofer is not exposed to the outside
environment, a better bass performance can be achieved
using an enclosure that has a ported design. See the
optimum enclosure design recommendations. Those
recommendations specify volume only, and for the ported
option, an optimum port size and length are also provided.
• If you intend to mount the subwoofer outside the boat, follow
these considerations.
◦ When mounted correctly, the subwoofer is rated IP65 for
protection in the harsh marine environment from the front
of the subwoofer. Water exposure and damage to the rear
of the subwoofer voids the warranty.
◦ The subwoofer must be mounted in a location well above
the waterline, where it is not submerged.
◦ The subwoofer must be mounted in a location where it
cannot be damaged by docks, pilings, or other pieces of
equipment.
◦ The subwoofer should be mounted in a sealed enclosure,
especially if it is exposed to wash down. A port or vent
may allow water to collect in the enclosure and damage
the subwoofer.
Mounting the Subwoofer
Before mounting the subwoofer, you must choose a location
where there is enough clearance behind the mounting surface.
Refer to the side view drawing and the specifications for
clearance information.
Before mounting the subwoofer, you must choose a location
following the mounting considerations.
If you are replacing a Fusion MS-SW10 10" subwoofer with the
Signature Series Classic model 10" subwoofer, see Replacing a
Fusion MS-SW10 10" Subwoofer.
1Route the wires from the source to the mounting location,
away from sources of electrical interference.
2
2Trim the template and make sure it fits in the selected
location.
3Orient the template with the Fusion logo at the bottom of the
template.
4Secure the template to the selected location.
5Using a drill bit appropriate for the mounting surface, drill a
hole inside the dashed line on the template to prepare the
mounting surface for cutting.
6Using a jigsaw or rotary tool, cut the mounting surface along
the inside of the line on the template.
7Place the subwoofer in the cutout to test the fit.
8If necessary, use a file and sandpaper to refine the size of
the cutout.
9After the subwoofer fits correctly in the cutout, ensure the
mounting holes on the subwoofer line up with the pilot holes
on the template.
10 If the mounting holes do not line up, mark the new hole
locations.
11 Using an appropriately sized drill bit for the mounting surface
and screw type, drill the holes.
12 Remove the template from the mounting surface.
13 Connect the subwoofer wires while observing polarity.
For more information on wiring polarity, see Subwoofer
Sound Optimization
14 If necessary, connect the LED wires to the Sports model
subwoofer (see ).Sports Model LED Wiring
15 Place the subwoofer in the cutout.
16 Secure the subwoofer to the mounting surface using the
included screws.
NOTE: Do not over tighten the screws, especially if the
mounting surface is not flat.
For the Classic model subwoofer, you should attach the grille to
the front (see Attaching the grille to the Classic Model
Subwoofer).
Replacing a Fusion MS-SW10 10" Subwoofer
You can replace a Fusion MS-SW10 10" subwoofer with the
Signature Series Classic model 10" subwoofer. You do not need
to cut or drill new holes.
1Remove the MS-SW10 from the mounting surface.
2Remove each oblong washer from the front of the subwoofer.
3Turn each washer À so the hole is oriented toward the center
of the subwoofer.
4Replace each washer.
5Continue mounting the subwoofer, starting at step 13 in
Mounting the Subwoofer.
Sports Model LED Wiring
Connecting the LED Wires to the Sports Model Subwoofer
NOTE: This feature is available only on the Sports model
subwoofer.
You can control the color of the LEDs by the polarity of the LED
wires.
1Using the hex key, loosen the screws on the wiring terminals
on the back of the subwoofer.
2Connect the black and red wires to the terminal according to
the preferred LED color.
Blue LED Black to negative (-)
Red to positive (+)
White LED Black to positive (+)
Red to negative (-)
3Using the hex key, tighten the screws on the wiring terminals.
Connecting the Sports Model Subwoofer LED Wires to
Power
NOTE: This feature is available only on the Sports model
subwoofer.
All 12 Vdc wiring to the LEDs must be fused at the power-source
end of your cable using a 3 A fuse. The red power (+) wire
should be connected to a 12 Vdc source through an isolator
switch or circuit breaker to turn the LEDs on and off. You can
use the same isolator or circuit breaker controlling the supply to
your stereo, which allows you to turn the LEDs and the stereo
on and off at the same time.
If it is necessary to extend the red and black wires, you should
use 20 AWG (0.5 mm2) or thicker wire.
1Route the red power (+) and black ground (-) wires to the
battery and subwoofer.
2Connect the black wire to the negative (-) battery terminal.
3Connect the red wire to the positive (+) battery terminal
through a 3 A fuse and isolator switch or circuit breaker.
Attaching the grille to the Classic Model Subwoofer
NOTE: This feature is available only on the Classic model
subwoofer.
1With the subwoofer mounted, hold the grille with the Fusion
logo at the bottom, at the 6 o'clock position.
2Turn the grille counter-clockwise about 10°, so the Fusion
logo is at the 5 o'clock position.
3Place the grille on the rim of the subwoofer.
4Twist the grille clockwise to secure it.
Subwoofer Sound Optimization
While installing the subwoofer, you can ensure the sound from
the subwoofer is optimized by running the subwoofer out of
phase. You can switch the positive and negative wires on the
subwoofer to run them out of phase.
Running the subwoofer out of phase from the speakers allows
you to hear if the perception of bass is more from the location of
3

Produktspecifikationer

Varumärke: Fusion
Kategori: högtalare
Modell: SG-F77W

Behöver du hjälp?

Om du behöver hjälp med Fusion SG-F77W ställ en fråga nedan och andra användare kommer att svara dig


högtalare Fusion Manualer

Fusion

Fusion MS-EL602 Bruksanvisning

6 September 2024
Fusion

Fusion XS-FL65SPGW Bruksanvisning

4 September 2024
Fusion

Fusion SG-F65W Bruksanvisning

4 September 2024
Fusion

Fusion FM-F65RW Bruksanvisning

4 September 2024
Fusion

Fusion SG-F772W Bruksanvisning

4 September 2024
Fusion

Fusion SG-FT88SPC Bruksanvisning

2 September 2024
Fusion

Fusion SG-F652W Bruksanvisning

2 September 2024
Fusion

Fusion SG-FL65SPC Bruksanvisning

1 September 2024
Fusion

Fusion FM-F77SW Bruksanvisning

1 September 2024
Fusion

Fusion CS-FR6930 Bruksanvisning

1 September 2024

högtalare Manualer

Nyaste högtalare Manualer

Continental Edison

Continental Edison CELED53HP20V2B4 Bruksanvisning

27 Oktober 2024
Canton

Canton Vento 830.2 Bruksanvisning

27 Oktober 2024
Jamo

Jamo S7-25C Bruksanvisning

27 Oktober 2024
Bowers Wilkins

Bowers Wilkins 707 S2 Bruksanvisning

27 Oktober 2024
Monitor Audio

Monitor Audio Silver C150 Bruksanvisning

26 Oktober 2024
FBT

FBT MITUS 210M Bruksanvisning

26 Oktober 2024
CyberData Systems

CyberData Systems SIP 011398 Bruksanvisning

26 Oktober 2024
Lamax

Lamax PartyGo1 Play Bruksanvisning

26 Oktober 2024
IKEA

IKEA SYMFONISK 405.847.50 Bruksanvisning

26 Oktober 2024
IKEA

IKEA SYMFONISK 804.923.34 Bruksanvisning

26 Oktober 2024
