Sida 1/10
®
XS Series Speakers Installation Instructions .................................................................................... 2
Instructions d'installation des haut-parleurs XS Series ..................................................................... 6
Altoparlanti XS Series Istruzioni di installazione ............................................................................. 11
Lautsprecher der XS Series – Installationsanweisungen ................................................................15
Instrucciones de instalación de los altavoces de la XS Series ....................................................... 19
Instruções de instalação dos alto-falantes XS Series ..................................................................... 23
XS Series luidsprekers installatie-instructies .................................................................................. 27
Garmin®, the Garmin logo, FUSION®, the Fusion logo, and True-Marine™ are trademarks of Garmin Ltd. or its subsidiaries, registered in the USA and other countries. These trademarks may not be used
without the express permission of Garmin.
October 2018
190-02481-90_0A
XS Series Speakers Installation
Instructions
Important Safety Information
WARNING
Failure to follow these warnings and cautions could result in
personal injury, damage to the vehicle or vessel, or poor product
performance.
This device must be installed according to these instructions.
Disconnect the vehicle's or vessel's power supply before
beginning to install this product.
CAUTION
Continuous exposure to sound pressure levels over 100 dBA
may cause permanent hearing loss. The volume is typically too
loud if you cannot hear people speaking around you. Limit the
amount of time you listen at high volume. If you experience
ringing in your ears or muffled speech, stop listening and have
your hearing checked.
Always wear safety goggles, ear protection, and a dust mask
when drilling, cutting, or sanding.
NOTICE
When drilling or cutting, always check what is on the opposite
side of the surface.
It is strongly recommended that you have your audio system
installed by a professional installer to ensure optimum
performance.
You must read all installation instructions before beginning the
installation. If you experience difficulty during the installation, go
to for product support.www.fusionentertainment.com
What's In the Box
• 2 speakers
• 12 Phillips stainless steel mounting screws
◦ 4 in. models: 3.5 mm x 25.4 mm (6 gauge x 1 in.)
◦ 6.5 in. and 7.7 in. models: 4.2 mm x 25.4 mm (8 gauge x 1
in.)
• Mounting template
• Speaker grilles
Tools Needed
• Electric drill
• Drill bit (size varies based on surface material)
• Phillips screwdriver
• Wire strippers
• Crimping tool
• Electrical tape
• Appropriate saw or utility knife to cut surface material
• Marine sealant (optional)
NOTE: For customized installations, additional tools and
materials may be needed.
Mounting Considerations
NOTICE
When mounting the speaker in an area exposed to weather or
water, you must mount the speaker on a vertical surface. If you
mount the speaker on a horizontal surface facing up, water can
gather in and around the speaker, causing damage over time.
Selecting the correct mounting location is critical to optimize the
performance of each speaker. FUSION® speakers are designed
to perform in the widest possible range of mounting locations,
but the more you plan the installation, the better the speakers'
sound will be.
• For the best performance, you should mount the speakers
higher in the boat. Sound travels in the direction in which the
speakers are facing, so if you mount them in a lower location,
the sound quality and volume may not be not ideal.
• If you intend to mount the speakers outside the boat, you
must mount them in a location well above the waterline,
where they are not submerged or damaged by docks, pilings,
or other pieces of equipment. When mounted correctly, these
speakers are rated IP65 for protection from the front of the
speaker. Water exposure and damage to the rear of the
speaker voids the warranty. This includes situations when the
speakers are mounted in a sealed enclosure, especially if
they are exposed to wash down. Using an enclosure with a
port or vent exposed to the outside environment may allow
water to collect and damage the speaker.
• You should select mounting locations that enable you to hear
sound from both speakers at the same time to achieve a
sound stage effect. To achieve this effect, you should not
mount the speakers side-by-side.
• When possible, you should select mounting locations where
the area behind each speaker is enclosed.
• You must select mounting locations that provide sufficient
clearance for the mounting depth of the speakers as
specified in the product specifications.
• For better bass performance, you should select mounting
locations that provide the appropriate space behind the
speaker according to the optimum enclosure design
requirements in the specifications section. Too small an area
restricts bass, and too large an area compromises bass
performance. Also, mounting a speaker close to an open
area (where sound from the back of the speaker has a very
short path to compete with sound from the front of the
speaker) produces the least bass.
• When a speaker is not exposed to the outside environment,
you can achieve a better bass performance using an
enclosure with a ported design.
• You can reference the Thiele Small (T/S) parameters in the
specifications section when designing a custom enclosure for
the speakers.
• You should select a flat mounting surface for the best seal.
• You should protect the speaker wires from sharp objects and
always use rubber grommets when wiring through panels.
• You should select mounting locations that avoid potential
obstacles, such as fuel and hydraulic lines and wiring.
• You should protect all terminals and connections from
grounding and from each other. Failure to do so could result
in permanent damage to the audio system and void the
product warranty.
• To avoid interference with a magnetic compass, you should
not mount the speakers closer to a compass than the
compass-safe distance value listed in the product
specifications.
• You must turn off the audio system before making any
connections to the source unit, amplifier, or speakers. Failure
to do so could result in permanent damage to the audio
system.
Mounting the Speakers
Before mounting the speakers, you must choose a location
following the guidelines above.
Before cutting the mounting surface you should verify that there
is enough clearance for the speaker behind the surface. Refer to
the specifications for clearance information.
2 Installation Instructions
NOTICE
Do not apply grease or lubricant to the screws when fastening
the speakers to the mounting surface. Grease or other lubricants
can cause damage to the speaker housing.
1Route the wires from the source to the speaker location,
away from sources of electrical interference.
2Trim the template and make sure it fits in the selected
location.
3Orient the template so that the FUSION logo is right-side up
on the template.
4Secure the template to the selected location.
5Using a rotary tool or jigsaw, cut the mounting surface along
the inside of the line on the template.
6Place the speaker in the cutout to test the fit.
7If necessary, use a file and sandpaper to refine the size of
the cutout.
8After the speaker fits correctly in the cutout, ensure the
mounting holes on the speaker line up with the pilot holes on
the template.
9If the mounting holes on the speaker do not line up, mark the
new hole locations.
10 Using an appropriately sized drill bit for the mounting surface
and screw type, drill the holes.
11 Remove the template from the mounting surface.
12 Connect the speaker wires À while observing polarity
( ).Speaker Wiring, page 3
13 If necessary, connect the LED wires ( ).LED Wiring, page 3
14 Place the speaker in the cutout.
15 Secure the speaker to the mounting surface using the
included screws Á.
NOTE: Do not over tighten the screws, especially if the
mounting surface is not flat.
16 With the speakers mounted, hold the grille with the FUSION
logo at the bottom, or at the 6 o'clock position.
17 Turn the grille counter-clockwise about 30 degrees, so the
FUSION logo is at the 5 o'clock position.
18 Place the grille on the speaker, and twist it clockwise to
secure it.
NOTE: Instead of twisting to install the grille, you can line it
up so the FUSION logo is at the 6 o'clock position and press
to snap it into place.
Speaker Wiring
When connecting the speakers to your stereo, observe these
considerations.
• Speaker wire is not included with the speakers. You should
use 18 AWG (0.82 mm2) speaker wire to connect the
speakers to the stereo.
• The leads on the speakers are terminated using male spade
connectors. You should use female spade connectors (not
included) to connect the speaker wire to the speaker leads
for the best connection.
• You can use this table to identify the polarity and spade-
connector sizes of the leads on the speaker.
Speaker wire color Speaker wire
polarity
Spade connector
size
White Positive (+) 6.3 mm
White with a black
stripe
Negative (-) 4.8 mm
LED Wiring
Connecting the LED Wires
You can control the color of the LEDs by connecting the LED
color wires to ground. You can splice the ground wire to multiple
LED wires to customize the LED color.
NOTE: This feature is available only on the sports model.
NOTE: Instead of connecting the LED wires for one dedicated
color, you can install a remote control to turn the LEDs on and
off, change the color, and create lighting effects. See your
FUSION dealer or for more www.fusionentertainment.com
information.
The black wire on the LED cable is terminated with a 4 mm
female bullet connector, and the color wires are terminated with
4 mm male bullet connectors. You can connect these to 4 mm
bullet connectors on your wires (not included), or remove the
bullet connectors to connect to the bare wires instead.
1Connect a positive wire to the black wire on the LED cable.
2Connect a ground wire to the wire on the LED cable
according to the preferred LED color.
LED Color LED Wire Color
Red Red
Green Green
Blue Blue
Yellow Red and green
Magenta Red and blue
Cyan Blue and green
White Red, green, and blue
3Route the positive and negative wires, and connect them to a
power source (Connecting the LED Wires to Power,
page 3).
Connecting the LED Wires to Power
NOTE: This feature is available on only the sports model.
You must connect all 12 Vdc wiring to the LEDs to a 3 A fuse at
the power-source end of the cable. You should connect the
positive (+) power wire to a 12 Vdc power source through an
isolator switch or circuit breaker to turn the LEDs on and off. You
can use the same isolator or circuit breaker controlling the
power supply to your stereo, which allows you to turn the LEDs
and the stereo on and off at the same time.
You should use 22 AWG (0.33 mm2) or thicker wire to connect
the LEDs to the battery.
1Route the positive power (+) and negative ground (-) wires
from the LED-wire connections to the battery.
2Connect the negative wire to the negative (-) battery terminal.
3Connect the positive wire to the positive (+) terminal through
a 3 A fuse and isolator switch or circuit breaker.
Speaker Information
True-Marine™ Products
True-Marine products are subjected to rigorous environmental
testing under harsh marine conditions to surpass industry
guidelines for marine products.
Installation Instructions 3

Produktspecifikationer

Varumärke: Fusion
Kategori: högtalare
Modell: XS-FL65SPGW

Behöver du hjälp?

Om du behöver hjälp med Fusion XS-FL65SPGW ställ en fråga nedan och andra användare kommer att svara dig


högtalare Fusion Manualer

Fusion

Fusion MS-EL602 Bruksanvisning

6 September 2024
Fusion

Fusion XS-FL65SPGW Bruksanvisning

4 September 2024
Fusion

Fusion SG-F65W Bruksanvisning

4 September 2024
Fusion

Fusion FM-F65RW Bruksanvisning

4 September 2024
Fusion

Fusion SG-F772W Bruksanvisning

4 September 2024
Fusion

Fusion SG-FT88SPC Bruksanvisning

2 September 2024
Fusion

Fusion SG-F652W Bruksanvisning

2 September 2024
Fusion

Fusion SG-FL65SPC Bruksanvisning

1 September 2024
Fusion

Fusion FM-F77SW Bruksanvisning

1 September 2024
Fusion

Fusion CS-FR6930 Bruksanvisning

1 September 2024

högtalare Manualer

Nyaste högtalare Manualer

Continental Edison

Continental Edison CELED53HP20V2B4 Bruksanvisning

27 Oktober 2024
Canton

Canton Vento 830.2 Bruksanvisning

27 Oktober 2024
Jamo

Jamo S7-25C Bruksanvisning

27 Oktober 2024
Bowers Wilkins

Bowers Wilkins 707 S2 Bruksanvisning

27 Oktober 2024
Monitor Audio

Monitor Audio Silver C150 Bruksanvisning

26 Oktober 2024
FBT

FBT MITUS 210M Bruksanvisning

26 Oktober 2024
CyberData Systems

CyberData Systems SIP 011398 Bruksanvisning

26 Oktober 2024
Lamax

Lamax PartyGo1 Play Bruksanvisning

26 Oktober 2024
IKEA

IKEA SYMFONISK 405.847.50 Bruksanvisning

26 Oktober 2024
IKEA

IKEA SYMFONISK 804.923.34 Bruksanvisning

26 Oktober 2024
