Signature Series Speakers Installation Instructions...........................................................................2
Instructions d'installation des haut-parleurs Signature Series........................................................... 6
Altoparlanti Signature Series Istruzioni di installazione................................................................... 10
Lautsprecher der Signature Series – Installationsanweisungen...................................................... 14
Instrucciones de instalación de los altavoces de la Signature Series..............................................19
Instruções de instalação dos alto-falantes da Signature Series...................................................... 23
Signature Series luidsprekers - installatie-instructies...................................................................... 27
Garmin®, the Garmin logo, and the Fusion
™
logo are trademarks of Garmin Ltd. or its subsidiaries, registered in the USA and other countries. Fusion and True-Marine
™
are trademarks of Garmin Ltd. or its
subsidiaries. These trademarks may not be used without the express permission of Garmin.
November 2014 190-01845-90_0APrinted in China
Signature Series Speakers Installation
Instructions
Important Safety Information
WARNING
Failure to follow these warnings and cautions could result in
personal injury, damage to the vessel, or poor product
performance.
See the guide in the Important Safety and Product Information
product box for product warnings and other important
information.
This device must be installed according to these instructions.
Disconnect the vessel's power supply before beginning to install
this product.
CAUTION
Audio systems can produce sound pressure levels exceeding
135 dB. Continuous exposure to sound pressure levels over
100 dB may cause permanent hearing loss. The volume is
typically too loud if you cannot hear people speaking around
you. Limit the amount of time you listen at high volume. If you
experience ringing in your ears or muffled speech, stop listening
and have your hearing checked.
Always wear safety goggles, ear protection, and a dust mask
when drilling, cutting, or sanding.
NOTICE
When drilling or cutting, always check what is on the opposite
side of the surface.
It is strongly recommended that you have your speaker system
installed by a professional installer to ensure optimum
performance.
You must read all installation instructions before beginning the
installation. If you experience difficulty during the installation, go
to for product support.www.fusionentertainment.com
What's In the Box
• 2 speakers
• 2 tinned, pre-terminated speaker wires (6 m)
• 12 Phillips stainless steel, 4.2 mm x 38 mm (8 gauge x 1.5
in.) mounting screws
• Mounting template
• 2 grills (Classic models only)
• 2 tinned LED connection cables (6 m) (Sports models only)
• Hex key (Sports models only)
Tools Needed
• Electric drill
• Drill bit (size varies based on surface material)
• Phillips screwdriver
• Wire strippers
• Crimping tool
• Electrical tape
• Appropriate saw or utility knife to cut surface material
NOTE: For customized installations, additional tools and
materials may be needed.
Mounting Considerations
Selecting the correct mounting location is critical to optimize the
performance of each speaker. Fusion
™
speakers are designed to
perform in the widest possible range of mounting locations, but
the more you plan the installation, the better the speakers'
sound will be.
• For the best performance, the speakers should not be
mounted low in the boat. Sound travels in the direction in
which the speakers are facing. When the speakers are
mounted low, the sound quality and volume are not ideal.
• If you intend to mount the speakers outside the boat, they
must be mounted in a location well above the waterline,
where they are not submerged. The speakers must be
mounted in a location where they will not be damaged by
docks, pilings, or other pieces of equipment. When mounted
correctly, these speakers are rated IP65 for protection in the
harsh marine environment from the front of the speaker.
Water exposure and damage to the rear of the speaker will
void the warranty. This includes when mounted in a sealed
enclosure, especially if they are exposed to wash down. A
port or vent may allow water to collect in the enclosure and
damage the speaker.
• The speaker mounting locations should enable you to hear
sound from both speakers, and from different directions, at
the same time to achieve a sound stage effect. To achieve
this effect, the speakers usually should not be mounted side-
by-side.
• For better bass performance, each speaker should be
mounted in an area that provides just enough room behind
the speaker. Too small an area restricts bass, and too large
an area compromises bass performance. Placing a speaker
close to an open area (where sound from the back of the
speaker has a very short path to compete with sound from
the front of the speaker) produces the least bass.
• When possible, the area behind each speaker should be
enclosed.
• The speaker mounting locations must provide sufficient
clearance for the mounting depth of the speakers as
specified in the product specifications.
• When a speaker is not exposed to the outside environment, a
better bass performance can be achieved using an enclosure
that has a ported design. See the optimum enclosure design
recommendations. Those recommendations specify volume
only, and for the ported option, an optimum port size and
length are also provided.
• You should select a flat mounting surface for the best seal.
• You should protect the speaker wires from sharp objects and
always use rubber grommets when wiring through panels.
• The mounting location must avoid potential obstacles, such
as fuel and hydraulic lines and wiring.
• You should protect all terminals and connections from
grounding and from each other. Failure to do so could result
in permanent damage to the audio system and void the
product warranty.
• To avoid interference with a magnetic compass, the speakers
should not be installed closer to a compass than the
compass-safe distance value listed in the product
specifications.
• The audio system must be turned off before making any
connections to the source unit, amplifier, or speakers. Failure
to do so could result in permanent damage to the audio
system.
Mounting the Speakers
Before mounting the speakers, you must choose a location
where there is enough clearance behind the mounting surface.
Refer to the side view drawings for clearance information.
Before mounting the speakers, you must choose a location
following the guidelines above.
1Route the wires from the source to the speaker location,
away from sources of electrical interference.
2Trim the template and make sure it fits in the selected
location.
2
3Orient the template with the Fusion logo at the bottom of the
template.
4Secure the template to the selected location.
5Using a drill bit appropriate for the mounting surface, drill a
hole inside the dashed line on the template to prepare the
mounting surface for cutting.
6Using a jigsaw or rotary tool, cut the mounting surface along
the inside of the line on the template.
7Place the speaker in the cutout to test the fit.
8If necessary, use a file and sandpaper to refine the size of
the cutout.
9After the speaker fits correctly in the cutout, ensure the
mounting holes on the speaker line up with the pilot holes on
the template.
10 If the mounting holes on the speaker do not line up, mark the
new hole locations.
11 Using an appropriately sized drill bit for the mounting surface
and screw type, drill the holes.
12 Remove the template from the mounting surface.
13 Connect the speaker wires while observing polarity.
14 Push the wire into a retaining clip to relieve the tension on the
wire.
15 If necessary, connect the LED wires to the Sports model
speakers (see the following section).
16 Place the speaker in the cutout.
17 Secure the speaker to the mounting surface using the
included screws.
NOTE: Do not over tighten the screws, especially if the
mounting surface is not flat.
For Classic model speakers, attach the grill to the speaker front.
Sports Model Speakers LED Wiring
Connecting the LED Wires to the Sports Model Speakers
NOTE: This feature is available only on the Sports model
speakers.
You can control the color of the LEDs by the polarity of the LED
wires.
1Using the hex key, loosen the screws on the wiring terminals
on the back of the speaker.
2Connect the black and red wires to the terminal according to
the preferred LED color.
Blue LED Black to negative (-)
Red to positive (+)
White LED Black to positive (+)
Red to negative (-)
3Using the hex key, tighten the screws on the wiring terminals.
4Push the wire into a retaining clip to relieve the tension on the
wire.
Connecting the Sports Model Speakers LED Wires to Power
NOTE: This feature is available only on the Sports model
speakers.
Before you can connect the LED wires to the speakers, you
must connect the LED wires to the power source.
All 12 Vdc wiring to the LEDs must be fused at the power-source
end of your cable using a 3 A fuse. The red power (+) wire
should be connected to a 12 Vdc source through an isolator
switch or circuit breaker to turn the speaker LEDs on and off.
You can use the same isolator or circuit breaker controlling the
supply to your stereo, which allows you to turn the LEDs and the
stereo on and off at the same time.
If it is necessary to extend the red and black wires included with
the speakers, you should use 20 AWG (0.5 mm
2) or thicker wire.
1Route the red power (+) and black ground (-) wires to the
battery and speaker.
2Connect the black wire to the negative (-) battery terminal.
3Connect the red wire to the positive (+) terminal through a 3
A fuse and isolator switch or circuit breaker.
Attaching the Grill to the Classic Model Speakers
NOTE: This feature is available only on the Classic model
speakers.
1With the speakers mounted, hold the grill with the Fusion
logo at the bottom, or at the 6 o'clock position.
2Turn the grill counter-clockwise about 10°, so the Fusion logo
is at the 5 o'clock position.
3Place the grill on the rim of the speaker.
4Twist the grill clockwise to secure it.
Speaker Information
True-Marine™
Products
True-Marine products are subjected to rigorous environmental
testing under harsh marine conditions to surpass industry
guidelines for marine products.
Any product that bears the True-Marine stamp of assurance has
been designed for simplicity of use and combines the most
advanced marine technologies to deliver an industry leading
entertainment experience. All True-Marine products are
supported by the Fusion 3-year worldwide limited consumer
warranty. You can be assured Fusion stands by its products and
takes pride in delivering True-Marine quality products for your
vessel.
Optional LED Voltage Regulator
You can use an LED voltage regulator (optional accessory SG-
VREGLED) to regulate the battery voltage supply to the LED
lights. You can use the voltage regulator if you notice the levels
of brightness changing when you are running your engine,
charging, or using battery power only. The voltage regulator can
power the LEDs on up to ten Signature Series speakers or
subwoofers; for example four pairs of speakers and two
subwoofers.
Registering Your Signature Series
Help us better support you by completing our online registration
today.
• Go to .www.fusionentertainment.com
• Keep the original sales receipt, or a photocopy, in a safe
place.
3

Produktspecifikationer

Varumärke: Fusion
Kategori: högtalare
Modell: SG-FL65SPC

Behöver du hjälp?

Om du behöver hjälp med Fusion SG-FL65SPC ställ en fråga nedan och andra användare kommer att svara dig


högtalare Fusion Manualer

Fusion

Fusion MS-EL602 Bruksanvisning

6 September 2024
Fusion

Fusion XS-FL65SPGW Bruksanvisning

4 September 2024
Fusion

Fusion SG-F65W Bruksanvisning

4 September 2024
Fusion

Fusion FM-F65RW Bruksanvisning

4 September 2024
Fusion

Fusion SG-F772W Bruksanvisning

4 September 2024
Fusion

Fusion SG-FT88SPC Bruksanvisning

2 September 2024
Fusion

Fusion SG-F652W Bruksanvisning

2 September 2024
Fusion

Fusion SG-FL65SPC Bruksanvisning

1 September 2024
Fusion

Fusion FM-F77SW Bruksanvisning

1 September 2024
Fusion

Fusion CS-FR6930 Bruksanvisning

1 September 2024

högtalare Manualer

Nyaste högtalare Manualer

Continental Edison

Continental Edison CELED53HP20V2B4 Bruksanvisning

27 Oktober 2024
Canton

Canton Vento 830.2 Bruksanvisning

27 Oktober 2024
Jamo

Jamo S7-25C Bruksanvisning

27 Oktober 2024
Bowers Wilkins

Bowers Wilkins 707 S2 Bruksanvisning

27 Oktober 2024
Monitor Audio

Monitor Audio Silver C150 Bruksanvisning

26 Oktober 2024
FBT

FBT MITUS 210M Bruksanvisning

26 Oktober 2024
CyberData Systems

CyberData Systems SIP 011398 Bruksanvisning

26 Oktober 2024
Lamax

Lamax PartyGo1 Play Bruksanvisning

26 Oktober 2024
IKEA

IKEA SYMFONISK 405.847.50 Bruksanvisning

26 Oktober 2024
IKEA

IKEA SYMFONISK 804.923.34 Bruksanvisning

26 Oktober 2024
