GV-RK1352 and GV-R1352 Card Reader
The GV-RK1352 and GV-R1352 are card readers designed to recognize identifications cards.
GV-RK1352 comes with keypad, allowing it to also recognize PIN codes. Featured with the
Wiegand and RS-485 outputs, the readers can be connected to any standard access control
panel. The readers are protected by a weather sealed and IP66 compliant housing for
outdoor use.
The content of this installation guide refers to the following readers:
• GV-RK1352 firmware V1.2
• GV-R1352 firmware V1.2
Packing List
GV-RK1352
1. GV-RK1352 Card Reader
2. Screw x 2
3. Screw Anchor x 2
4. Front Cover Plate x 2
Front View
GV-R1352
February 6, 2015
1
1. GV-R1352 Card Reader
2. Screw x 3
3. Screw Anchor x 2
4. Security Torx
Front View
1. Physical Descriptions
1.1 Electric Wire
GV-RK1352
Wire Color Function
Red DC 7.5 ~ 12 V
Black GND
Yellow Beeper
Orange Green LED
Light Red Red LED
Green Wiegand Data 0
White Wiegand Data 1
Blue RS-485 +
Light Blue RS-485 -
Rear View
GV-R1352
Wire Color Function
Red DC 7.5 ~ 12V
Black GND
Yellow Beeper
Orange Green LED
Light Red Red LED
Green Wiegand Data 0
White Wiegand Data 1
Blue RS-485 +
Light Blue RS-485 -
Gray N/A
Purple N/A
Brown N/A Rear View
February 6, 2015
2
1.2 Keypad (GV-RK1352 Only)
When accessing an entry using GV-RK1352, you can enter the door’s PIN code on the
keypad or present the card and then enter the card’s PIN code on the keypad to be granted
access. The access mode is defined on GV-ASManager.
1. 0~9 Number Keys: Press the number keys to enter the PIN code.
2. # Key: Press the # key to confirm the PIN code.
3. ﹡
﹡
﹡
﹡﹡Key: Press the ﹡key to cancel the PIN code.
1.3 LED Indicator and Beeper
In standby mode, the LED is blue. When a card is read, the LED flashes green and the
beeper beeps once.
The reader comes with external control wires for Green LED, Red LED and Beeper. You can
connect these control wires to a GV-AS Controller to change the default settings of the LED
and Beeper. For details on how to configure the settings, refer to 5. Changing the Settings of
Beeper and LED later in this installation guide.
Note: You can only connect the LED and beeper wires to GV-AS210 / 2110 / 400 / 410 /
4110 / 810 / 8110.
February 6, 2015
3
