User Manual
1
Thank you for purchasing this Phantom series iCAN. The iCAN Phantom is both :
(I) a professional analogue headphone amplier
(II) a fully-edged, high-end stereo preamplier
(III) an audiophile-grade energiser for electrostatic headphones
WARNING: The iCAN Phantom is VERY POWERFUL and can oer large amounts of sub-bass boost. As a starting point, always use the
lowest gain possible and start with the volume set low and set to OFF. iFi is not responsible for any ancillary equipment damage XBass
caused by the iCAN Phantom.
FEATURES
• The ultimate analogue headphone amp from world-leading head- manufacturer iFi Audio
• Also performs as a high-end stereo preamplier to connect to a power amp and speakers
• Pure Wave PRO fully dierential balanced circuit design delivers ultra-low distortion
• Two discrete input stages, switch between solid state and GE 5670 vacuum tubes in real time
• Remarkable power-up to 15,000mW to drive the toughest headphone loads with ease
• Delivers 14V in Unbalanced mode and 27V in Balanced mode
• Adjustable gain and load impedance plus iEMatch output attenuation to suit all headphone/IEM types
• Pro iESL energiser technology with six voltage settings for electrostatic headphones
• Capacitive battery power supply eliminates mains-borne noise from the audio signal
• Multi-level XSpace and XBass analogue processing modes for headphones and speakers
• Exemplary build quality, comprehensive connectivity and informative colour TFT display
2
Electrostatic Power LED
Electrostatic Headphone ON/OFF
Pro/Custom Bias ESL Headphone Output
Power/Mute/Input/Menu
Bias Memory Card Slot
AC Termination Adjustment
Operation Mode Selector
1.
2.
3.
4.
5.
6.
7.
Normal Bias ESL Headphone Output
Impedance Adjustment
8.
9.
Gain Selection
XBass Adjustment
Stereo Balanced XLR Headphone Output
Analogue Volume Control Dial
Operating Status LED
Balanced 4.4mm Headphone Output
Unbalanced 3.5mm Headphone Output
TFT Display
iEMatch Adjustment
Balanced XLR L/R , Stereo Unbalanced
6.3mm - and + Phase Output
XSpace Adjustment
14.
15.
16.
17.
18.
19.
20.
10.
11.
12
13.
P.4
P.4
P.4
P.4-8
P.9
P.9
P.10
P.15
P.16
P.16
P.16
P.17
P.17
P.17
P.11
P.11
P.11
P.12
P.12
P.13-15
2
1
5
6
3 16 19 20
7 94 14
15
17 1810 13
12118
