SRX5600 Services Gateway Getting
Started Guide
December 2013
Part Number: 530-055499
Revision 01
This document describes how to install the SRX5600 Services Gateway.
Contents About This Guide . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Step 1: Prepare the Site for SRX5600 Services Gateway Installation . . . . . . . . . . . 4
Rack-Mounting Requirements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Tools Required to Unpack and Prepare the SRX5600 Services Gateway for
Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Step 2: Install the Mounting Hardware in a Four-Post Rack or Cabinet or an
Open-Frame Rack . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Step 3: Install the Services Gateway . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Remove Components . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Install the Services Gateway Using a Lift . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Install the Services Gateway Without a Mechanical Lift . . . . . . . . . . . . . . . . . 12
Reinstall Components . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Step 4: Connect the Grounding Cable . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Step 5: Connect External Devices and Network Cables . . . . . . . . . . . . . . . . . . . . . 14
Connect to a Network for Out-of-Band Management . . . . . . . . . . . . . . . . . . . 14
Connect a Management Console . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Connect the Network Cables . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Step 6: Connect Power Cables . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Connect Power to an AC-Powered Services Gateway . . . . . . . . . . . . . . . . . . . 16
Connect Power to a DC-Powered Services Gateway . . . . . . . . . . . . . . . . . . . . 17
Step 7: Perform the Initial Software Configuration . . . . . . . . . . . . . . . . . . . . . . . . . 20
Enter Configuration Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
Configure User Accounts and Passwords . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
Configure System Attributes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
Commit the Configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
Safety Warnings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
1Copyright © 2013, Juniper Networks, Inc.
SRX5600 Services Gateway Compliance Statements for EMC
Requirements ..................................................26
Canada .......................................................26
European Community . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
Japan.........................................................26
United States ..................................................26
SRX Series Documentation and Release Notes . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
Requesting Technical Support . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
Revision History . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
Copyright © 2013, Juniper Networks, Inc.2
SRX5600 Services Gateway Getting Started Guide
About This Guide
This guide contains information that you need to install and configure the SRX5600
Services Gateway quickly. For complete installation instructions, see the SRX5600
Services Gateway Hardware Documentation at www.juniper.net/techpubs/.
WARNING: This guide contains a summary of safety warnings in “Safety
Warnings” on page 24. For a complete list of warnings for this device, including
translations, see the SRX5600 Services Gateway Hardware Documentation
at www.juniper.net/techpubs/.
The SRX5600 Services Gateway is a high-performance, highly scalable, carrier-class
security device with multiprocessor architecture. The services gateway is eight rack units
(RU) tall. Three services gateways can be stacked in a single floor-to-ceiling rack, for
increased port density per unit of floor space. The services gateway provides six slots
that can be populated with up to four Services Processing Cards (SPCs) and interface
cards and two Switch Control Boards (SCBs) in redundant fabric configurations. The
interface cards can be any of the following types:
•I/O cards (IOCs) have fixed ports on their front panels.
•Flex I/O cards (Flex IOCs) have two slots on their front panels for smaller cards called
port modules that add additional ports to the services gateway.
•Modular Port Concentrators (MPCs) have two slots on their front panels for smaller
cards called Modular Interface Cards (MICs) that add additional ports to the services
gateway.
The SRX5600 Services Gateway provides redundancy and resiliency. The hardware
system is fully redundant, including power supplies and SCBs.
By installing various combinations of interface cards and SPCs, you can tailor both the
number of ports and the maximum services processing capacity to suit your network.
Table 1 on page 3 describes the minimum system configuration for the SRX5600 Services
Gateway.
Table 1: Minimum System Configuraton
MinimumComponent
1SPC
1Interface card (IOC, Flex IOC, or MPC)
1SCB
1Routing Engine
3Copyright © 2013, Juniper Networks, Inc.
About This Guide
