SX .1 Series Amplifiers

Features

Low Impedance Operation Stable into 2 ohm

(SX650.1) or 1 ohm (SX1250.1) mono loads.

SORT Protection Circuitry (S Ohort circuit, ver-voltage,

Reverse polarity, hermal) Protects amplifier from accidentsT

and out of spec operation.

MOSFET Power Supply Provides high efficiency

operation.

PAST ( mp ignal Pre A S Transfer) Output RCA jacks to pass the

incoming signal to another amplifier or component.

Class D High efficiency Class D design for maximum output

power with minimal current draw.

Amp Strapping Allows you to combine two like models

together for double the power at double the impedance!

Low Pass Filter Fully adjustable digital crossover with

variable slope and crossover frequency. 30 Hz - 200 Hz in 1 Hz

increments. OFF - 48 dB per octave slope in 6 dB increments.

High Pass Filter Fully adjustable digital crossover with

variable slope and crossover frequency. 10 Hz - 60 Hz in 1 Hz

increments. OFF - 24 dB per octave slope in 6 dB increments.

KickEQ Fully adjustable single band digital parametric equal-

izer with variable Q (bandwidth), variable center frequency and

variable boost or cut. Q range .5 - 10 in .5 steps. Center

frequency 20 Hz - 200 Hz in 1 Hz steps. Boost or cut range +/-

18 dB.

Adjustable Phase The output phase (polarity) can be set

at 0 Degrees or 180 Degrees.

UltraMatch Gain Structure Digital input gain control

with five selectable gain ranges (1 volt, 2 volt, 4 volt, 8 volt, 16

volt) with 12 dB of adjustment in each range in .5 dB steps.

SickBay and On Board Diagnostics Various tools to

troubleshoot installation issues and check amp status.

Kompressor A 4-setting, user-selectable bass compressor

used to fatten up your sub bass. OFF, RED-LINE, CONTOUR and

ATTACK with +/- 24 dB of adjustment to compensate for

speaker size or listening style.

ISIS I S I S(pronounced eye-sis) ( ndicate tatus & nput ettings)

The user interface to view or adjust current settings and check

the status of your Kicker SX amplifier.

BLAST Port (B L A S Tass evel nd ignal ransfer) Provides

Remote Bass Level Control and control signal transfer

between multiple SX amplifiers.

EndKaps Cast aluminum, custom, removable covers to pro-

tect and hide all your wiring connections to the amplifier. Can

be prepped and painted any custom color you choose.

SASA (S A Shake tick A ) t So many more features...it is more

than you can Shake A Stick At. (It’s an Oklahoma thing!) Read

on to find out!

2SX .1 Series Amplifiers

Introduction

SX650.1 / SX1250.1

SX .1 Series

Amplifier

Owners Manual

Mono-Block Models:

Attention:

Please take a moment and record the information

asked for below in the provided area. It is also a good

idea to attach the original sales receipt or a copy of it to

this page for future reference

If for any reason you require service on this ampliﬁer

during the warranty period, you will need to provide this

information and a copy of the receipt to Kicker to vali-

date your warranty.

ALWAYS KEEP YOUR RECEIPT!

Dealer Where Purchased:

Purchase Date:

Amplifier Model Number:

Amplifier Serial Number:

Congratulations!

You have just purchased the latest in amplifier

technology to carry the famous KICKER name.

Your KICKER SX series amplifier employs the lat-

est in DSP signal processing to give you total

control over your sound. Like all KICKER prod-

ucts it is designed and built to give you years

of powerful and trouble-free performance.

This installation manual contains valuable infor-

mation on how to get the most out of your

new SX series amplifier.

Thanks for buying KICKER. Enjoy!
