VS VS-211X / -411X Quick Start
P/N:
2900- 301247QS
Rev:
3
Scan for full manual
VS VS-211X and -411X Quick Start Guide
This guide helps you install and use your VS-211X / VS-411X for the first time.
Go to www.kramerav.com/downloads/VS-411X to download the latest user manual and check if firmware
upgrades are available.
Step 1: Check in the bwhat’s ox
VS VS-211X / - 4K Auto Switcher411X
4 Rubber feet
1 Power adapter and cord
1 Quick start guide
Step 2: Get to know your - -411X VS 211X / VS
The terms HDMI, HDMI High-Denition Multimedia Interface, and the HDMI Logo are trademarks or registered trademarks of HDMI Licensing Administrator, Inc.
#
Feature
Function
1
PROG Micro USB Connector
Connect to upgrade the rmware.
2
SETUP 4-way DIP-Switches
Set the operation DIP-switches (see ). Setting the DIP-Switches
3
IN Buttons
Press to select an I input (button lights orange HDM ).
4
OUT LED
Lights green when an HDMI output is connected.
5
ON LED
Lights green when the device receives power.
6
HDMI Connectors ™IN
Connect to an HDMI source (2 for , 4 for ). VS-211X VS-411X
7
HDMI™ OUT Connector
Connect to an HDMI acceptor.
8
AUDIO OUT3.5mm Mini Jack
Connector
Connect to an balanced stereo audio acceptor. un
9
REMOTE IN Terminal block Connector
Connect to contact closure switches by momentary contact between the desired
pin and common GND pin to select an input.
10
5V DC Power Connector
Connect to the power supply and to the mains electricity.
Step 3: Install - VS 211X / VS- 411X
Install using one of the following methods: VS-211X / VS-411X
• Attach the rubber feet and place the unit on a at surface.
• Fasten a bracket (included) on each side of the unit and attach it to a at surface
(see
www.kramerav.com/downloads/VS-411X).
• Mount the unit in a rack using the recommended rack adapter
(see
www.kramerav.com/product/VS-411X).
• Ensure that the environment (e.g., maximum ambient temperature &
air ow) is compatible for the device.
• Avoid uneven mechanical loading.
• Appropriate consideration of equipment nameplate ratings should be
used for avoiding overloading of the circuits.
• Reliable earthing of rack-mounted equipment should be maintained.
• Maximum mounting height for the device is 2 meters.
Step 4: Connect the inputs and outputs
Always switch OFF the power on each device before connecting it to your . For best results, we recommend that you VS-211X
always use Kramer high-performance cables to connect AV equipment to the . and are identical VS-211X VS-211X VS-411X
except for the number of inputs.
Setting the DIP-Switches
DIP-switches 1, 2 and 3 are set to (down) by default and DIP-switch 4 is always set to OFF (up). ON
DIP-switch changes take eect immediately.
#
Feature
Dip-Switch Settings
1
Switching Mode
OFF (up) Manual mode. –
ON (down) Auto-switching mode. –
2
Auto-switching Mode
OFF (up) Priority switching mode: the device switches the source with the –
highest priority to the output.
ON (down) Last connected switching mode: the last detected active source is –
auto-switched to the output.
3
EDID lock
O (up) EDID Locked. –
On (down) EDID parameters are pass -through. –ed
4
Reserved for Factory Use
It is mandatory to keep set to OFF (up).
For optimum range and performance use the recommended Kramer cables available at www.kramerav.com/product/VS-411X
Step 5: Connect the power
Connect the power cord t / and plug it into the mains electricity. o VS-211X VS-411X
Safety Instructions (See www.kramerav.com for updated safety information).
Caution:
• For products with relay terminals and GPI\O ports, please refer to the permitted rating for an external connection, located next to the
terminal or in the User Manual.
• There are no operator serviceable parts inside the unit.
Warning:
• Use only the power cord that is supplied with the unit.
• Disconnect the power and unplug the unit from the wall before installing.
