K R A M E R E LECT R ONI C S LT D .
USER MANUAL
MODELS:
WP-580Tx r
HDMI Line Trans mitter
WP-580Rxr
HDMI Line Receiver
P/N: 2900-300087 Rev 4
WP WP-580Txr/ -580Rxr Contents–
i
Contents
1 Introduction 1
2 Getting Started 2
2.1 Achieving the Best Performance 2
2.2 Safety Instructions 2
2.3 Recycling Kramer Products 3
3 Overview 4
3.1 About HDBaseT™ Technology 5
3.2 Using Twisted Pair Cable 5
4 Defining the WP-580Txr HDMI Line Transmitter 6
5 Defining the WP-580Rxr HDMI Line Receiver 8
6 Connecting the WP-580Txr and WP-580Rxr 10
6.1 Wiring the RJ-45 Connectors 12
6.2 Grounding the Transmitter/Receiver 13
7 Technical Specifications 14
Figures
Figure 1: WP-580Txr HDMI Line Transmitter for the US and Decora® 6
Figure 2: WP-580Txr HDMI Line Transmitter for Europe (80mm/86mm) 7
Figure 3: WP-580Rxr HDMI Line Receiver for the US and Decora® 8
Figure 4: WP-580Rxr HDMI Line Receiver for Europe (80mm/86mm) 9
Figure 5: Connecting the WP-580Txr/WP-580Rxr Transmitter/Receiver Pair 11
Figure 6: TP PINOUT 12
Figure 7: Grounding Connection Components 13
