Sida 1/20
1
ENGLISH (Original instructions)
INSTRUCTION MANUAL
IMPORTANT: Read Before Using.
Cordless Multi Tool
DTM40
DTM50
012764
2
ENGLISH (Original instructions)
SPECIFICATIONS
Model DTM40 DTM50
Oscillation per minute 6,000 - 20,000 (min
-1)
Oscillation angle, left/right 1.6 ﾟ (3.2 ﾟ total)
Overall length 324 mm
Standard battery cartridge BL1430/
BL1440
BL1415*/
BL1415N*
BL1830/ BL1840/
BL1850
BL1815*/ BL1815N*/
BL1820*
without dust extraction attachment
1.9 kg 1.7 kg 2.0 kg 1.8 kg
Net weight
with dust extraction attachment
2.0 kg 1.8 kg 2.1 kg 1.9 kg
Rated voltage D.C. 14.4 V D.C. 18 V
* NOTE: For continuous operation, high capacity battery cartridge BL1430, BL1440, BL1830, BL1840 and BL1850 are recommended.
• Due to our continuing program of research and development, the specifications herein are subject to change without notice.
• Specifications and battery cartridge may differ from country to country.
• Weight, with battery cartridge, according to EPTA-Procedure 01/2003
END221-2
Symbols
The following show the symbols used for the equipment.
Be sure that you understand their meaning before use.
･ Read instruction manual.
･ Wear safety glasses.
･ Only for EU countries
Do not dispose of electric equipment or
battery pack together with household
waste material!
In observance of European Directive
2002/96/EC on waste electric and
electronic equipment, 2006/66/EC on
batteries and accumulators and waste
batteries and accumulators and their
implementation in accordance with
national laws, electric equipment and
battery pack that have reached the end
of their life must be collected separately
and returned to an environmentally
compatible recycling facility.
ENE080-1
Intended use
The tool is intended for sawing and cutting wood, plastic,
gypsum, non-ferrous metals, and fastening elements (e.
g. unhardened nails and staples). It is also intended for
working soft wall tiles, as well as dry sanding and
scraping of small surfaces. It is especially for working
close to edge and flush cutting.
ENG905-1
Noise
The typical A-weighted noise level determined according
to EN60745:
Work mode: Sanding
Sound pressure level (L
pA) : 78 dB (A)
Uncertainty (K) : 3 dB (A)
The noise level under working may exceed 80 dB (A).
Work mode: Cutting with plunge cut saw blade
Model DTM40
Sound pressure level (L
pA) : 82 dB (A)
Sound power level (LWA
) : 93 dB (A)
Uncertainty (K) : 3 dB (A)
Model DTM50
Sound pressure level (L
pA) : 84 dB (A)
Sound power level (LWA
) : 95 dB (A)
Uncertainty (K) : 3 dB (A)
Work mode: Cutting with segmental saw blade
Sound pressure level (L
pA) : 81 dB (A)
Sound power level (LWA
) : 92 dB (A)
Uncertainty (K) : 3 dB (A)
Work mode: Scraping
Model DTM40
Sound pressure level (L
pA) : 81 dB (A)
Sound power level (LWA
) : 92 dB (A)
Uncertainty (K) : 3 dB (A)
Model DTM50
Sound pressure level (L
pA) : 83 dB (A)
Sound power level (LWA
) : 94 dB (A)
Uncertainty (K) : 3 dB (A)
Wear ear protection
Cd
Ni-MH
Li-ion
3
ENG900-1
Vibration
The vibration total value (tri-axial vector sum) determined
according to EN60745:
Work mode: Sanding
Vibration emission (ah) : 2.5 m/s2 or less
Uncertainty (K) : 1.5 m/s2
Work mode: Cutting with plunge cut saw blade
Model DTM40
Vibration emission (ah) : 9.5 m/s2
Uncertainty (K) : 1.5 m/s2
Model DTM50
Vibration emission (ah) : 10.0 m/s2
Uncertainty (K) : 1.5 m/s2
Work mode: Cutting with segmental saw blade
Model DTM40
Vibration emission (ah) : 5.0 m/s2
Uncertainty (K) : 1.5 m/s2
Model DTM50
Vibration emission (ah) : 5.5 m/s2
Uncertainty (K) : 1.5 m/s2
Work mode: Scraping
Model DTM40
Vibration emission (ah) : 7.5 m/s2
Uncertainty (K) : 1.5 m/s2
Model DTM50
Vibration emission (ah) : 9.5 m/s2
Uncertainty (K) : 1.5 m/s2
ENG901-1
• The declared vibration emission value has been
measured in accordance with the standard test
method and may be used for comparing one tool
with another.
• The declared vibration emission value may also be
used in a preliminary assessment of exposure.
WARNING:
•
The vibration emission during actual use of the power
tool can differ from the declared emission value
depending on the ways in which the tool is used.
• Be sure to identify safety measures to protect the
operator that are based on an estimation of
exposure in the actual conditions of use (taking
account of all parts of the operating cycle such as
the times when the tool is switched off and when it
is running idle in addition to the trigger time).
ENH101-17
For European countries only
EC Declaration of Conformity
Makita declares that the following Machine(s):
Designation of Machine:
Cordless Multi Tool
Model No./ Type: DTM40, DTM50
Conforms to the following European Directives:
2006/42/EC
They are manufactured in accordance with the following
standard or standardized documents:
EN60745
The technical file in accordance with 2006/42/EC is
available from:
Makita, Jan-Baptist Vinkstraat 2, 3070, Belgium
31.12.2013
000331
Yasushi Fukaya
Director
Makita, Jan-Baptist Vinkstraat 2, 3070, Belgium
GEA006-2
General Power Tool Safety Warnings
WARNING Read all safety warnings and all
instructions.
Failure to follow the warnings and instructions
may result in electric shock, fire and/or serious injury.
Save all warnings and
instructions for future reference.
The term "power tool" in the warnings refers to your
mains-operated (corded) power tool or battery-operated
(cordless) power tool.
Work area safety
1. Keep work area clean and well lit. Cluttered or
dark areas invite accidents.
2. Do not operate power tools in explosive
atmospheres, such as in the presence of
flammable liquids, gases or dust. Power tools
create sparks which may ignite the dust or fumes.
3. Keep children and bystanders away while
operating a power tool. Distractions can cause
you to lose control.
Electrical safety
4. Power tool plugs must match the outlet. Never
modify the plug in any way. Do not use any
adapter plugs with earthed (grounded) power
tools. Unmodified plugs and matching outlets will
reduce risk of electric shock.
