Sida 1/3
1990 vehicles and older:
Audis and Volkswagens do not have a switched 12 volts source for the receiver. You can connect to a 12 volts switch source either of these ways:
1. Connect both the switched 12 volts and constant 12 volts of the receiver to the yellow wire on the adaptor. Note: Using this method will
require that the receiver is turned off manually. Otherwise, the receiver will remain on and can drain the battery.
2. Connect to a 12 volts switched source in the vehicle fuse panel.
1994-'98 Saab 900
1995-'98 Saab 9000
2001-'03 Mercedes ML320
1997-'02 Porsche Boxster
2002-'03 Land Rover Freelander
The yellow and red wires of this harness must be reversed for these vehicles. Yellow connects to ignition. Red connects to 12V constant
power.
Pre-1996 vehicles:
Your vehicle may use an amplified (non-motorized) antenna. Even though your antenna does not automatically retract, the wire of blue
the Crutchfield harness must be connected to the power antenna wire of the new receiver.
IMPORTANT NOTES
Before making any connections, please read the notes below that may apply to your vehicle.
Make wiring connections using instructions on the following pages.
Receiver Wiring Adaptor
120 70-1758
IMPORTANT
Before starting, compare items on your invoice with items
received. Thoroughly check packing materials. If an item
is missing, please call Crutchfield at 1-888-955-6000.
Copyright 2017 Crutchfield Corporation *120701758*
Revision 11/27/17
Receiver Wiring Adaptor
120 70-1758
STEP 1 -- MATCH & CONNECT WIRES
IMPORTANT
Before starting, compare items on your invoice with items
received. Thoroughly check packing materials. If an item
is missing, please call Crutchfield at 1-888-955-6000.
Copyright 2017 Crutchfield Corporation
Yellow - 12 Volts Constant Power
Red - 12 Volts Switched Power
White - Left Front Speaker Positive
Violet - Right Rear Speaker Positive
Green - Left Rear Speaker Positive
Gray - Right Front Speaker Positive
Gray/Black - Right Front Speaker Negative
White/Black - Left Front Speaker Negative
Black - Chassis Ground
Violet/Black - Right Rear Speaker Negative
Green/Black - Left Rear Speaker Negative
Orange/White - Illumination
Blue - Power Antenna
Match wires below to the matching function of each wire on your receiver (refer to instructions supplied with receiver). The wire colors of your
new receiver may, or may not, match the wire colors of the adaptor. Match adaptor and receiver wires by function, disregarding color.
Your receiver illumination wire could be Orange or Orange/White. As with other wires, match this wire to the illumination wire in this harness
by function, not by color. If your receiver does not have an illumination wire, tape off the illumination wire.
Individually tape off any unused wires.
Make final wiring connections following instructions on the next page.
A.
B.
C.
D.
1994-'98 Saab 900:
This wire is not used.
Cut and tape off both ends.
Page 2
120 70-1758
Page 3
STEP 2 -- CONTINUED
A. Strip wires back 1/2”.
B. Twist wires together and
insert in crimp cap.
C. Squeeze middle of cap
for tight connection.
Copyright 2017 Crutchfield Corporation
STEP 3 -- APPLICATION
D. Complete crimp connections
for all necessary wires.
E. Be sure to wrap any wires from
the Wiring Adaptor that are
not necessary (wires with no
match from the new receiver)
with electrical tape.
STEP 2 -- CRIMP CONNECTIONS
Tools & Parts
Required
Wire Stripper/Crimp Tool Crimp Caps
Unused Wire (tape over bare wires)
Receiver Wiring Adaptor
Generic Illustration
Generic Illustration
Receiver Wiring Adaptor Connections
A. When ready to install the
receiver, plug the wiring
Adaptor from the new receiver,
or receiver assembly into the
factory radio harness(es) in the
vehicle dash.
