INSTALLATION INSTRUCTIONS FOR PART 95-2004
Phillips Screwdriver Panel Removal Tool Small Flat Blade Screwdriver Cutting Tool
1-800-221-0932 www.metraonline.com
KIT FEATURES
© COPYRIGHT 2004 METRA ELECTRONICS CORPORATION
DDIN Head Unit Provision
ISO Stacked Head Unit Provision
( A) DDIN Brackets ( B) DDIN Trim Plate ( C) (4) Speed Clips ( 4) Phillips Head Screws
KIT COMPONENTS
TOOLS REQUIRED:
A
APPLICATIONS
Cadillac
1997-2001 Catera
1996-1999 Deville
(Column Shift Only)
B
95-2004
METRA. THE WORLD’S BEST KITS.
WIRING AND ANTENNA CONNECTIONS (Sold Separately)
HARNESS:
ANTENNA ADAPTER:
GMRC-03 - 1997-2002 Cadillac Interface W/O Onstar
GMOS-06 - 1997-2002 Cadillac Interface W/ Onstar
40-GM10 - GM Antenna Adapter
CD
TABLE OF CONTENTS
95-2004
Dash Disassembly
1997-2001 Cadillac Catera . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
1996-1999 Cadillac Deville
( Column Shift Only)
. . . . . . . . . . . . .
1
Kit Preparation
1997-2001 Cadillac Catera . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
1996-1999 Cadillac Deville
( Column Shift Only)
. . . . . . . . . . . . .
2
Kit Assembly
1997-2001 Cadillac Catera / 1996-1999 Cadillac Deville
( Column
Shift Only)
DDIN Head Unit Provision . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
ISO Stacked Head Unit Provision . . . . . . . . . . . . . . . . . . . . . . . . . 3
K
NOWLEDGE IS
P
OWER
Enhance your installation and fabrication skills by
enrolling in the most recognized and respected
mobile electronics school in our industry.
Log onto www.installerinstitute.com or call
800-354-6782 for more information and take steps
toward a better tomorrow.
Metra recommends using
MECP certified technicians.
95-2004
1
Disconnect the negative battery
terminal to prevent an accidental
short circuit.
1
Disconnect the negative battery
terminal to prevent an accidental
short circuit.
1
Remove (1) Phillips head screw from
inside the ashtray and remove ash-
tray.
(Figure A)
2
Remove screw covers from the radio
trim panel. Remove traction control
and hazard switch covers. Then
remove switches by depressing tabs
and pulling outward.
(Figure B)
3
Remove radio trim panel and unplug
any remaining harnesses from the
panel.
(Figure C)
4
5
Remove (2) Phillips head screws
securing the radio. Unplug and
remove the radio.
6
Remove (4) Phillips head screws
from behind covers and ashtray.
1997-2001 CADILLAC CATERA
1996-1999 CADILLAC DEVILLE
Unsnap and remove radio trim panel.
(Open glove box to access.)
(Figure A)
2
Pinch the side clips to disengage
radio. Unplug and remove radio.
3
DASH DISASSEMBLY
A
6:59
6:59
6:59
6:59
6:59
A
C
B
