METRA. The World’s best kits.™metraonline.com © COPYRIGHT 2004-2015 METRA ELECTRONICS CORPORATION
REV. 10/12/2015 INST95-7328
Installation instructions for part 95-7328
CAUTION!
Metra recommends disconnecting the negative bat
-
tery terminal before beginning any installation, unless the vehicle
manufacturer recommends against so. Please check with your local
Dealership for more information. All accessories, switches, climate
controls panels, and especially air bag indicator lights must be con-
nected before reconnecting the battery or cycling the ignition. Also,
do not remove the factory radio with the key in the on position, or the
vehicle running. It would be best to remove the key from the ignition
and then wait a few seconds before removing the factory radio.
• ISO DDIN radio provision
• A) ISO DDIN trim panel • B) ISO DDIN brackets
KIT FEATURES
KIT COMPONENTS
WIRING & ANTENNA CONNECTIONS (sold separately)
Wiring Harness: • 70-7302
Antenna Adapter: • Not required
• Panel removal tool • Phillips screwdriver
TOOLS REQUIRED
KIA Sorento 2007-09
95-7328
B
Dash Disassembly ................................................. 2
Kit Assembly
– ISO DDIN radio provision ...................................... 3
Table of Contents
A
95-7328
2
1. Unclip and remove the side trim
panels. (Figure A)
Note: Start at the bottom of the
panels.
2. Remove (2) Phillips head screws
securing the radio trim panel.
Unplug and remove panel.
(Figure B)
3. Remove (2) Phillips head screws
securing the vent panels, then
unclip and remove the (2) vent
panels. (Figure C)
4. Remove (4) Phillips screws
securing the radio. Unplug and
remove radio.
Continue to kit assembly
Dash Disassembly
(Figure B) (Figure C)
(Figure A)
95-7328
Kit Assembly
(Figure A) (Figure B)
ISO DDIN radio provision
1. Snap the ISO DDIN brackets to the
outside edge of the ISO DDIN trim
panel. (Figure A)
2. Slide the radio into the completed
assembly, and then secure it using
the screws supplied with the radio.
(Figure B)
3.
Locate the factory wiring harness
and antenna plug in the dash and
make all necessary connections to
the radio. Metra recommends using
the proper mating adapters from
Metra and/or AXXESS. Re-connect
the negative battery terminal and
test the radio for proper operation.
4. Reassemble the dash in reverse
order of disassembly.
3
