I N S TA L L AT I O N I N S T R U C T I O N S

95-7637

Attention! Let the vehicle sit with the key

out of the ignition for a few minutes before

removing the factory radio. When testing the

aftermarket equipment, ensure that all factory

equipment is connected before cycling the

key to ignition.

KIT FEATURES

• ISO DDIN radio provision †

• Pioneer modular DDIN radio provision †

• Painted with a gloss black face, silver trim, and a textured housing.

KIT COMPONENTS

• A) Radio housing (front) • B) Radio housing (rear) • C) Radio trim panel • D) Radio brackets • E) Pioneer adapter brackets

• F) #4 x 3/8” Phillips screws (4) • G) #6 x 3/8” Phillips screws (4) • H) Panel clips (3) TOOLS REQUIRED

• Panel removal tool • Phillips screwdriver

• 10mm socket wrench

TABLE OF CONTENTS

Dash Disassembly ..................................................2

Kit Assembly

– ISO DDIN radio provision ................................3-4

– Pioneer modular DDIN radio provision.........5-6

WIRING & ANTENNA CONNECTIONS

(sold separately)

Wiring Harness: 70-7552

Antenna Adapter: 40-NI12

A B C

F G

D E

Nissan Altima 2019-up

Visit for more detailed information about the product and up-to-date vehicle MetraOnline.com

speciﬁc applications

† This kit can only be used with an ISO DDIN radio with an “L” shaped chassis design, with the radio

chassis at the bottom of the screen. As of this writing, only the Alpine INE-W967HD (discontinued,

replaced by INE-W977HD), iLX-107, and iLX-207 have this design. Also, The Pioneer modular radios,

DMH-C2550NEX and DMH-C2500NEX, can also be used with the included adapter brackets.

1.800.221.0932

MetraOnline.com

1. Unclip and remove the trim panel

behind the radio. There are (4) clips

securing this panel to the dash. Use

caution as the front of the trim panel

can easily be damaged. (Figure A)

2. Remove (4) 10mm screws securing the

radio. Take note that the lower radio

brackets are angled inward, hiding the

bottom (2) screws from being easily

seen. Slide the radio out, then unplug

and remove the radio. (Figure B)

Continue to Kit Assembly

(Figure A) (Figure B)

DASH DISASSEMBLY

REV. 6/3/2019 INST95-7637 3

KIT ASSEMBLY

ISO DDIN radio provision

1. Attach (3) provided onto the panel clips

radio housing (front). (Figure A)

2. Snap the radio housing (front) to the

radio housing (rear), then secure using

(4) #4 x 3/8” Phillips screws provided

(Figure B)

3. radio brackets Secure the to the radio

housing using (4) #6 x 3/8” Phillips

screws provided. (Figure C)

Continued on the next page

(Figure A) (Figure B) (Figure C)
